GETEST
The thermo-magnetic switch and the safety key are independent devices, and act directly on the
mains supply (switch) or on the output current (safety key). In this way, even in the unlikely failure of
software / hardware, these two devices allow to avoid the current injection.
11�- Once the test is completed, on the Results screen of the application, all the results can be
consulted .
Figure 6
Figure 6: Results screen
12� The results obtained can be saved to a file, to do this click on the adjustment switch, and
access the Files section ( ).
Figure 7
Figure 7: Save the results in a File�
16
