GETEST
5�2�- GETEST Probe
Operating temperature
Storage temperature
Maximum Altitude
Installation category
Connection
Dimensions
Packaging
Weight
Enclosure
Safety requirements for electrical equipment for measurement, control and laboratory use
- Part 031: Safety requirements for hand-held probe assemblies for electrical measurement
and test
Instructions Manual
Environmental features
Mechanical features
Standard
481.15
Figure 18: GETEST Probe dimensions�
5 ºC ... 40 ºC
5 ºC ... 40 ºC
2000 m
CAT II 600 V PD3
Banana type 4 mm
Figure 18
690 x 210 x 85 mm
2.2 kg. (Couple)
Stainless steel and EPDM
UNE-EN 61010-031
27
