2 Product Introduction

2.1 Camera Introduction

PROVISION-ISR's new series of cameras have
adopted a high performance CMOS image sensor,
which provides mega pixel resolution and supports HD
video. Moreover, it supports monitoring signals coaxial
transmission. Transmission distance can reach more
than 200M based on Rg59 coaxial cable. The series
can support all HD analog resolutions: AHD/TVI/CVI
as well as CVBS 960H output.

2.2 Product Features

● Coaxial cable with BNC connector
● DIP Switch for output selection
● Auto Day/Night (ICR)
● BLC
● 3D-DNR
● Super High Resolution Lens
● AHD/TVI/CVI/CVBS Signal Selectable
● PAL/NTSC (System Selectable by DIP switch)*
4
3 Menu Setup
AHD/TVI: Click on "Iris+" button from the DVR's PTZ
interface to call the OSD Menu. Use the PTZ interface to
scroll through the menu and "Iris+" to confirm.
CVI: Click " ►" button from the DVR's PTZ interface,
then click " " and press "Enter" to call the OSD Menu.
4 Product Installation

4.1 General Notes

1. Make sure the unit is powered off before installation.
2. Check power supply voltage consistent with the
electric voltage to prevent voltage unworthy, resulting in
damage to the device.
3. Do not use in environment conditions exceeding the
specified temperature and humidity.
4. The installation and maintenance of this product
should be done by a professional. Please do not remove
or modify the camera in any way.
5
