4.6 Connection

Connection as shown in the figure below

4.7 OSD Control

The OSD control is available by CoC (Control over
Coax). If your AHD/TVI/CVI DVR supports this function*,
use the DVR's PTZ interface to press on "Iris+" or "
to open the OSD menu. Navigate through the OSD
menu using the PTZ direction arrows.
* Notice: CoC function works no more than 200M by RG59 coaxial cable
* All of Provision-ISR's DVRs support CoC Starting from version 3.4.4
8

4.8 OSD Menu Scheme:

Main Menu
Lens
Exposure
White Balance
Day & Night
"
Adjust
Second Menu Third Menu
Manual 1~20
Mode
DC
Iris Speed
Shutter
0~15
AGC
Brightness 0~100
D-WDR Off / On
BLC / Off
Backlight
ATW
AWC -> Set
Ext D->N (Delay)
N->D (Delay)
Auto D->N (AGC)
D->N (Delay)
N->D (AGC)
N->D (Delay)
Color
IR Smart
B/W
NR 2DNR
3DNR
Sharpness
