2 Product Introduction

2.1 Camera Introduction

PROVISION-ISR's new cameras series has adopted
CMOS image sensor with high performance, which
provides mega pixel resolution and supports HD video.
It supports coaxial transmission that can reach more
than 300M, based on 75-3 coaxial cable. The series
supports both AHD/CVBS 960H output and real-time
video transmission.

2.2 Product Features

● Coaxial cable with BNC connector
● Auto Day/Night (ICR)
● Auto Defog, HBLC, BLC
● Digital WDR, 2D/3D NR
● Motion Detection, Privacy Mask
● AHD/CVBS Signal Selectable from OSD
AHD-960H: Press left 5 seconds;
960H-AHD: Press right 5 seconds;
PAL-NTSC: Press down 5 seconds to switch
between PAL&NTSC
4

3 Menu Setup

Press "MENU" button to enter the main MENU, press
"UP" and "DOWN" to select menu, press "LEFT" and
"RIGHT" to choose or set the corresponding function.
To enter submenu press "MENU" again. Set up Save
and exit.

4 Product Installation

4.1 General Notes

1. Make sure the unit is powered off before installation.
2. Check if power supply voltage is consistent with
electric voltage to prevent damages to the device.
3. Do not use in environments exceeding temperature
limitations, and maintain good ventilation to prevent
risk of fire or electric shock.
4. The installation and maintenance of this product
should be professional, please do not in any way
remove or modify the equipment; only use the
5
