2 Product Introduction

2.1 Camera Introduction

PROVISION-ISR's new series of cameras have
adopted a high performance CMOS image sensor
which provides HD resolution and supports high
resolution video output. The cameras support video
transmission distance of around 400M base on Rg59
standard coaxial cable. This series can support AHD/
TVI/CVI/CVBS 960H analog output.

2.2 Product Features

● Coaxial Cable with BNC Connector
● DIP Switch
● Auto Day/Night (ICR)
● BLC / HLC
● 2D/3D NR
● AHD/TVI/CVI/CVBS Signal Selectable (by jumper)
4
3 Menu Setup
AHD/TVI: Click on "Iris+" button from the DVR's PTZ
interface to call the OSD Menu. Use the PTZ interface to
scroll through the menu and "Iris+" to confirm.
CVI: Click " ►" button from the DVR's PTZ interface, then
click " " and press "Enter" to call the OSD Menu.
4 Product Installation

4.1 General Notes

1. Make sure the unit is powered off before installation.
2. Check that power supply voltage complies with the
camera requirement to prevent damage to the camera.
3. The installation and maintenance of this product
should be done by a professional. Please do not remove
or modify the camera in any way.
5
