2 Product Introduction

2.1 Camera Introduction

PROVISION-ISR's new series of cameras are adopted
CMOS image sensor with high performance, which
provides mega pixel resolution and supports HD video.
Moreover, it supports monitoring signals coaxial
transmission. Transmission distance can reach more
than 300M based on 75-3 coaxial cable. The series
can support both AHD/CVBS 960H output as well as
realize high speed, long distance and real time video
transmission.

2.2 Product Features

● 1/3" 1.3M CMOS Sensor
● AHD 720P 25fps/30fps
● AHD, CVBS format output
● Low Illumination, 0.01LUX@(F1.2, AGC ON)
● Auto White balance
● Auto Eletronic Shutter
● Auto Gain Control
● 2DNR
4

3 Product Installation

3.1 General Notes

1. Make sure the unit is powered off before installation.
2. Check power supply voltage consistent with the
electric voltage to prevent voltage unworthy, resulting in
damage to the device.
3. Do not use in the environment beyond the boundaries
of the temperature, and maintain good ventilation to
prevent the rain in order to reduce the risk of fire or
electric shock.
4. The installation and maintenance of this product
should be professional, please do not in any way to
remove or modify the equipment; can only use the
required accessories of manufacturers. Problems
caused by unauthorized repair are at your own risk.
