Measurement Computing P-Series Instruction Manual page 15

Instruction Manual
-Single step polling-
Activate
-Baud rate mode-
Activate
Baud rate activation
2400 Baud
Baud rate activation
9600 Baud
Exit
-Zero setting mode-
Activate for single axis
version
Exit
-Zero setting mode-
Activate for dual axis
version
Exit
MEAS Deutschland GmbH
Hauert 13, D-44227 Dortmund, Germany
P-Series Inclinometer
"m" "M!"
"x=xxx.xxx"
"y=yyy.yyy"
"h" "H!"
"H?"
"0" CR,LF
"B?"
"1" CR,LF
"B?"
"e" "E!"
"n" "N!"
"N?"
"x" "Offset=x"
"B?"
"n" "N!"
"N?"
"x" CR,LF
"Offset=0"
"B?"
"e" "E!"
"n" "N!"
"N?"
"x" CR,LF
"Offset=x"
"B?"
"y" CR,LF
"Offset=y"
"B?"
"n" "N!"
"N?"
"x" CR,LF
"Offset=0"
"B?"
"y" CR,LF
"Offset=0"
"B?"
"e" "E!"
www.meas-spec.com
15 of 16
July 2014
This command is used to display one
measurement value. This command must be
replay if another value is needed. To change this
mode, start with setup mode.
This command is used to activate the baud rate
mode to change the baud rate.
Input acknowledgment with enter.
2400 Baud (default value)
Input acknowledgment with enter to change into
9600 Baud
To closed the baud rate mode, press `e´ to go
into running mode or go to another step.
This command is used to activate zero setting
mode to safe the currently position of the unit.
Offset in 1/1000°, x = value
Notice:
The zero point can be set only if the current
angle is between –5°< x <+5°.
The command is ignored if the angle is outside
the afore mentioned range.
The connection to zero can be cancelled by
repeatedly inputting the command `n`,
factory default.
To closed the zero setting mode, press `e´ to go
into running mode or go to another step.
This command is used to activate zero setting
mode to safe the currently position of the unit.
Offset in 1/1000°,
x = x-axis value
y = y-axis value
Notice:
The zero point can be set only if the current
angle is between
–5°< x,y <+5°.
The command is ignored if the angle is outside
the afore mentioned range.
The connection to zero can be cancelled by
repeatedly inputting the command `n`,
factory default.
To closed the zero setting mode, press `e´ to go
into running mode or go to another step.
