Adapter Specifications; Cpci Adapter Specifications - Compaq StorageWorks FCA2257C Installation Manual

Specifications

Adapter Specifications

Table B–2 lists the cPCI adapter specifications
Table B–2: cPCI Adapter Specifications
Type
Host bus
Fibre Channel
specifications
Central processing
unit (CPU)
RAM
NVRAM
Flash
Onboard DMA
Connectors
Form factor
Operating power
B–2
Conforms to PCI Local Bus Specification, Revision 2.1
Bus type: fiber optic media
Bus transfer rate: 100 MBps maximum at half duplex
200 MBps maximum at full duplex
Interface chip: SP2200A/33 (two)
Single-chip design that includes a RISC processor, Fibre
Channel protocol manager, DMA controller, and 1-Gb
transceivers
128K bytes of SRAM for each ISP2200A/33
256 bytes for each ISP2200A/33, field programmable
512K bytes of flash ROM, field programmable
Three independent DMA channels: two data and one
command. Integrated frame buffer FIFOs (4K-byte receive
and 4K-byte transmit) for each data channel.
SC-style connector that supports non-OFC, multimode
fiber optic cabling using 1 fiber optic transceiver module.
16.0 cm x 10.0 cm (6.3" x 3.9")
Less than 15 watts
FCA2257C cPCI Host Bus Adapter for Sun Solaris Installation Guide
.
Specification
