NC3131 Fast Ethernet Server Adapter Specifications

Specification
Network Controller Chipset
Data Transfer Method
Standards Supported
Dimensions
Connector
Distance
Interrupts Supported
Temperature Range
Relative Humidity
Agency Approvals
Power Requirement
Data Transmission Rate
Table C-1
NC3131 Fast Ethernet Server Adapter Specifications
Description
Intel 82558 MAC/PHY
64-bit/66MHz PCI, compatible with 64-bit/33MHz or 32-bit/33MHz Bus
Master DMA
IEEE 802.3x, 802.3u,802.3ab, 802.3ad (static configuration mode only),
802.1p, and 802.1Q
7.4 x 5.0 inches (L x W), 18.8 cm x 12.7 cm (including bracket)
See Table C-8
100 meters (328 feet)
Automatically configured
Operating: 0° C to 55° C / 32° F to 131° F
Storage: -65° C to 85° C / -85° F to 185° F
Operating: 10% to 90%
Storage: 5% to 95%
■ FCC Class B
■ VCCI Class B
■ BSMI Class A
■ CISPR 22 Class B
■ EN60950
1050 mA @ 5V max
10/100 (Full- and Half-duplex)
Appendix
Specifications
■ EN 55022 Class B
■ EN55024
■ UL
■ Canada UL
■ ICES-003 Class B
C
