- Page 1 Compaq Ultra SCSI Adapter For OpenVMS™ VAX™ Installation and User’s Guide Part Number: EK-KZMCA-IN. V01...
- Page 2 Compaq Ultra SCSI Adapter For OpenVMS™ VAX™ Installation and User’s Guide Part Number: EK-KZMCA-IN. V01 July 21, 1999 Revision/Update Information: This is a new manual. Compaq Computer Corporation Maynard, Massachusetts...
- Page 3 No responsibility is assumed for the use or reliability of software or equipment that is not supplied by Compaq Computer, Inc. or its affiliated companies.
- Page 4 FCC NOTICE Warning! This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Achtung! Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei Betrieb dieses Gerätes Rundfunkstörungen auftreten, in welchen Fällen der Benutzer für entsprechende Gegenmaßnahmen verantwortlich ist.
- Page 5 FCC Declaration of Conformity The IntraServer Technology, Inc. ITIpci Ultra SCSI adapter, model numbers 5xxx comply with the requirements of FCC part 15, class A as defined under paragraph 2.909 of these rules. This declaration covers products identified with ITI 5140U-V1, ITI 5140U- V2, ITI 5140U-V3, ITI 5140U-V4 and ITI 5140U-V5 on the product label.
-
Page 6: Table Of Contents
Table of Contents Introduction __________________________________ 9 VAX™-SCSI Hardware Covered by This Guide ______ 9 Software Covered by This Guide ___________________ 9 Documentation Organization _____________________ 10 Adapter Specification__________________________ 11 Overview ______________________________________ 11 Required Software ______________________________ 11 Required VMS Patches ______________________________ 12 Restrictions ____________________________________ 13 Performance ___________________________________ 13 Adapter Installation ___________________________ 14... - Page 7 Configuration Restrictions __________________________ 27 Compaq VAX™-SCSI Installation Procedure_____________ 27 Cable Routing Example ____________________________ 28 Installing the DS-KZCCA-CB adapter ________________ 29 DS-KZCCA-DB Installation Procedure__________________ 30 Removing System Cover ___________________________ 30 Removing Enclosure Access Cover ___________________ 30 Option Locations _________________________________ 31 Compaq VAX™-SCSI Installation Procedure___________ 31...
- Page 8 Altitude: ________________________________________ 45 Mechanical (Operating): ___________________________ 45 Mechanical (Non-Operating) (Transport/Storage): _______ 46 Flammability: ____________________________________ 46 Functional Requirements/Features: ___________________ 46 Software: _______________________________________ 46 Reliability: ______________________________________ 46 Federal Communications Commission and international Agencies: _______________________________________ 47 PACKAGING AND SHIPPING:_______________________ 47 Glossary of Terms ____________________________ 48 List of Figures__________________________________ 49 List of Tables __________________________________ 49...
-
Page 9: Introduction
This manual will serve as a step by step guide during the installation of your VAX-SCSI host adapter in your computer. VAX™-SCSI Hardware Covered by This Guide This guide covers the installation and operation of Compaq’s complete line of VAX™-SCSI Ultra SCSI adapters as follows: DS-KZCCA-AB Ultra Wide SCSI Differential Adapter for: VAX™... -
Page 10: Documentation Organization
Documentation Organization This manual is organized into the following sections: Adapter Specification Adapter Configuration BIOS and Firmware Configuration Software Drivers Configuration Utilities... -
Page 11: Adapter Specification
Adapter Specification Overview The Compaq VAX™-SCSI Wide Ultra SCSI Host is based on the LSI 53C875 SCSI controller chip. This chip includes the following: Onboard RISC processor Internal 512Byte FIFO Internal 4Kbyte Script RAM One interrupt per I/O scripts IntraServer’s SCSI script implementation on the Symbios (LSI Logic) 53C875 SCSI processor offloads the CPU to deliver higher efficiency and lower CPU utlization. -
Page 12: Required Vms Patches
Check for the latest patch information for your version of VMS at the following There are some required VMS patches required to certain versions of VMS required to run the Compaq VAX-SCSI option. These are found on the support web site at: http://ftp.service.digital.com/patches/public/vms/vax/... -
Page 13: Restrictions
Cannot be used with the KZQSA 5140-V5 Performance Compaq’s VAX SCSI adapters bring state of the art Ultra SCSI disks and tapes to the VAX architecture, and significantly increase the I/O throughput available. For single block, sequential I/O (512 bytes) the Compaq adapters are capable of doing 5000 I/Os per second, running OpenVMS to Ultra SCSI disks. -
Page 14: Adapter Installation
Adapter Installation Termination Compaq VAX™-SCSI Ultra SCSI Host adapters include on-board Differential SCSI drivers and termination. The Comapq adapter is always at the end of the SCSI chain, and therefore always must terminate the SCSI bus. An external SCSI Connector and cabling is provided for connection to external SCSI devices. -
Page 15: Installing The Vax-Scsi Host Adapter
Once you have completed these general procedures, skip to the section below that best describes your system type and configuration. Before you begin installing your Compaq VAX™-SCSI UltraSCSI adapter, you must follow the steps below: Back up your files Follow the instructions in your software documentation to do a complete backup of your system and user disks. -
Page 16: Ds-Kzcca-Ab Installation Procedure
DS-KZCCA-AB Installation Procedure Use this installation procedure if your system type is VAX4000™-100, - 100A, -105A, -106A, or MicroVAX3100™-85, -90, -95 or -96. Removing System Cover After the system has been shut down, and power has been removed from the system, remove the system cover or access panel to gain access to the processor module. -
Page 17: Option Locations Vax4000™ And Microvax3100
DS-KZCCA-AB Configuration Restrictions You can not have the Compaq VAX™-SCSI option in your system at the same time as the asynchronous communications option. If this option is in your system, it must be removed if you want to run the Compaq adapter. -
Page 18: Ds-Kzcca-Ab Installation Procedure
DS-KZCCA-AB Installation Procedure The table below provides an overview of the VAX™-SCSI installation procedure. The remainder of this section explains each step in more detail. Touch the TOUCH HERE space or a metal piece on the top of the power supply Remove the I/O filler plate Remove the asynchronous communication adapter (if present) Install the internal SCSI cable on the VAX™-SCSI module... -
Page 19: Routing The Internal Cables
Attach the I/O bulkhead to the cutout at the rear of the system, with the screws provided. Be careful to route the cable in a way that will not interfere with other system components or the system cover. Routing the Internal Cables Figure 4: Routing the internal cables. -
Page 20: I/O Bulkhead Installed
I/O bulkhead installed Figure 5: I/O Bulkhead installed Replace the system cover, and all external cables. -
Page 21: Ds-Kzcca-Bb Installation Procedure
DS-KZCCA-BB Installation Procedure Use this installation procedure if your system type is a Vaxstation 4000-90, - 90A, or –96. Removing the VAXStation System Cover After the system has been shut down, and power has been removed from the system, remove the system cover or access panel to gain access to the processor module. -
Page 22: Option Locations Vaxstation
VAX™-SCSI option. Configuration Restrictions You can not have the Compaq VAX SCSI option in your system at the same time as the TURBO channel adapter. If this adapter is in your system, it must be removed if you want to run the Compaq adapter. -
Page 23: Installing The Ds-Kzcca-Bb Vax™-Scsi Adapter
Remove the filler plate Temporarily remove the graphics board (if applicable) Remove the TURBOchannel adapter if one is present. This adapter can NOT co-exist with the Compaq VAX™-SCSI adapter. Install the internal SCSI cable on the VAX™-SCSI module Install the VAX™-SCSI module in your system, by aligning the connector on the side of the module with the receptacle on the CPU board. -
Page 24: Attaching The I/O Bulkhead And Internal Scsi Cable
Replace the graphics board if one was removed Re-attach any SCSI cables which were removed 10. Attach the I/O bulkhead to the cutout at the rear of the system, with the screws provided. Be careful to route the cable in a way that will not interfere with other system components or the system cover. -
Page 25: Ds-Kzcca-Cb Installation Procedure
DS-KZCCA-CB Installation Procedure Use this installation procedure if your system type is VAX4000-500A, - 505A, -600A, -700A or –705A. Removing System Cover After the system has been shut down, and power has been removed from the system, open the lower system door. Using a phillips head screwdriver, release the CPU access cover by turning the retaining screws ¼... -
Page 26: Removing The Cpu Access Cover
Locate the CPU module within your system enclosure. You will need to remove the CPU module from the system in order to install your Compaq VAX™-SCSI option. Consult your system documentation for details of this... -
Page 27: Configuration Restrictions
Configuration Restrictions You can not have the Compaq VAX™-SCSI option in your system at the same time as the KZQSA Q-Bus SCSI adapter. If this module is in your system, it must be removed if you want to run the VAX-SCSI adapter. -
Page 28: Cable Routing Example
Cable Routing Example Figure 11 Routing the Cables Install the VAX™-SCSI module in your system, by aligning the connector on the back of the module with the receptacle on the CPU board. When you are certain the connectors are aligned, gently apply pressure directly above the connector until the connectors seat. -
Page 29: Installing The Ds-Kzcca-Cb Adapter
Installing the DS-KZCCA-CB adapter Figure 12: Installing the DS-KZCCA-CB VAX™-SCSI Adapter Connect the internal SCSI I/O cable you routed from the I/O bulkhead in step 4, above. Replace the CPU module by gently sliding it into the backplane, and operating the retaining levers. -
Page 30: Ds-Kzcca-Db Installation Procedure
DS-KZCCA-DB Installation Procedure Use this installation procedure if your system type is VAX™4000-108, MicroVAX™3100-88 or MicroVAX™-98. Removing System Cover After the system has been shut down, and power has been removed from the system, remove the system cover by releasing the retaining screws. Locate the I/O option slots, and remove one of the blank I/O panels. -
Page 31: Option Locations
I/O expansion slots Figure 14: Option Locations Locate the options listed above within your system enclosure. You may need to temporarily remove one or more options in order to install your Compaq VAX™-SCSI option. Compaq VAX™-SCSI Installation Procedure The table below provides an overview of the VAX™-SCSI installation procedure. -
Page 32: Installing The Ds-Kzcca-Db Adapter
Note: Refer to the diagram below Installing the DS-KZCCA-DB adapter Figure 15: Installing the DS-KZCCA-DB VAX™-SCSI Adapter Replace the system cover, and all external cables. -
Page 33: Configuring The Scsi Bus
On a 16 bit (WIDE) VAX™-SCSI bus, each device must have a unique SCSI ID from 0 - 7. The Compaq VAX™-SCSI adapter defaults to ID 7. All other devices on the bus should be given IDs from 0 – 6. Refer to the documentation for each of your devices for the method of setting the SCSI ID for that device. -
Page 34: Cabling Scsi Devices
Most problems encountered during the initial installation of a SCSI system can be traced to improper or low quality cabling and termination. Compaq carries a complete line of high quality SCSI cables which are compatible with Compaq’s VAX™-SCSI adapters, which can be ordered to meet the... -
Page 35: Connecting External Scsi Devices
Connecting External SCSI Devices Optional cables are available from Compaq for all external devices. See the cable selection table in this guide to determine the correct cable for your application. Apply these rules for IDs and termination: Only the end device on the bus (last device on the cable) should have termination enabled The VAX™-SCSI adapter ALWAYS provides termination... -
Page 36: Device Drivers For Openvms
Device Drivers for OpenVMS™ IntraServer’s OpenVMS™ driver enables the use of Ultra SCSI Differential disks, tapes and RAID enclosures, such as Compaq’s StorageWorks line of disk enclosures, to maximize the VAX™ system’s I/O throughput and storage capacity. IntraServer’s OpenVMS™ drivers are optimized for... -
Page 37: Installation
Installation Existing System Installation Before starting, please check the installation floppy, CD-ROM or Tape for a readme.txt file, which may contain any changes or additions to the installation procedure that occurred after the printing of this manual. Information can also be found at IntraServer’s Web Page, at http://www.intraserver.com. -
Page 38: Vmsinstal.com Installation Example
VMSINSTAL.COM Installation Example The following installation session is provided as an example. Your session may differ based you’re your system configuration. Before starting, you must have a complete current backup of your system disk. LAB9-> @vmsinstal OpenVMS AXP Software Product Installation Procedure It is 15-MAR-1999 at 16:53. - Page 39 time, answer NO to the following question: * Do you want this procedure to automatically start the drivers? [YES]? In order to start the IntraServer SCSI support on this system SYS$SYSTEM:CONFIG_PCI must be run each time the system boots. IntraServer recommends that CONFIG_PCI is run from the SYS$MANGER:SYCONFIG.COM procedure so that your SCSI devices made available during the normal boot process.
- Page 40 IntraServer support for SCSI Logical Units (DKW101, DKW102...) is Optional, because some older SCSI devices do not support LUNs. * Do you want to support SCSI Logical Units? [NO]? y IntraServer VAX SCSI adapters default to a port letter of "W" and therefore devices will be named as follows: Device Name SCSI ID...
-
Page 41: Testing Your Installation
* Do you want to run CLUSTERING on the FAST (100Mb/sec) ethernet port?[NO]? y ************************************************************** The interactive part of the installation is over. There are no more operator questions. ************************************************************** Providing the files for Version V5.5 Placing files in their final destinations... Installing files for VMS V5.5-2H4... - Page 42 $show device dk Will display all dk (SCSI ) type devices on your system. Note that your SYS$MANAGER:SYCONFIG.COM file has been modified, by including the command $mc config_pci, which will scan the PCI devices on your system, and make them available for use. If SYS$MANAGER:SYCONFIG.COM is changed by any other application, you will need to re-install this kit.
-
Page 43: Appendix A: Specifications
Appendix A: Specifications Mechanical Specifications (DS-KZCCA- Physical Dimensions: 3.1 inches wide X 7.9 inches long Connector and Jumper Configuration Drawing: GA ROM CDAL/ 53C875 PCI GA SCSI 21140A Terminators RJ45 ULTRA-DIFF SCSI Figure 16: Connecor and Jumper Positions (DS-KZCCA-AB) Mechanical Specifications (DS-KZCCA-BB) Physical Dimensions: 3.7 inches wide X 12.3 inches long... -
Page 44: Connector And Jumper Configuration Drawing
Connector and Jumper Configuration Drawing: GA ROM 21140A 53C875 CDAL/ PCI GA RJ45 CDAL CONNECTOR Figure 17: Connecor and Jumper Positions (DS-KZCCA-BB) Mechanical Specifications (DS-KZCCA-CB) Physical Dimensions: 3.4 inches wide X 9 inches long Connector and Jumper Configuration Drawing: ULTRA-DIFF SCSI CDAL RJ45 CONNECTOR... -
Page 45: Electrical Requirements
Electrical Requirements Power Requirements (Typical): Voltage +_ 5% Amps Watts 2.25 12 W +3.3 Environmental The modules are designed to operate in a Class A environment and shall meet all functional requirements of this specification when operating in the environment listed below. Temperature Range (Operating): 0 C to +55 C Relative Humidity Range (Operating):... -
Page 46: Mechanical (Non-Operating) (Transport/Storage)
Vibration (Sinusoidal): 5-30Hz, 0.1270mm;30-250Hz, 5m/s2: 30-250Hz, 10m/s2 (Over Stress) Shock: 100m/s2, 10ms, ½ sine The module depends on proper enclosure mounting and isolation to remain properly seated during mechanical stress. Mechanical (Non-Operating) (Transport/Storage): Vibration (Random): 2.15 grams @ 10-250Hz (packaged) Packaged Drop Test: Packaged Drop Tests from 72.6 cm height on all six sides The module depends on proper enclosure mounting and... -
Page 47: Federal Communications Commission And International Agencies
MTBF = Mean-Time-between-Failures MCBF = Mean-Cycles-Before-Failure MTTR = Mean-Time-To-Repair Federal Communications Commission and international Agencies: Agency Qualifications Class A FCC Part 15, Subpart Docket 20780 for Class A Devices CISPR-22 Class 1 EN55022 Class A, Radiated and Conducted Emissions EN50082-1 Class 1, Immunity Requirements Approved to VBG93, VDE 0837 STD-C22.2 No. -
Page 48: Glossary Of Terms
Glossary of Terms The following terms are used throughout this guide. Term Meaning Notes SCSI Small Computer Storage Interconnect Wide SCSI 16 Bit SCSI FAST SCSI SCSI clocked at 10 MHz 10 Mbytes/sec 8 bit, 20 Mbytes/sec 16 bit Ultra SCSI SCSI clocked at 20 MHz 20 Mbytes/sec 8 bit, 40 Mbytes/sec 16 bit... -
Page 49: List Of Figures
List of Figures Figure 1: Removing the system cover _____________________________16 Figure 2: VAX4000 and MicroVAX3100 Option Locations_____________17 Figure 3 Installing the VAX-SCSI module__________________________18 Figure 4: Routing the internal cables. _____________________________19 Figure 5: I/O Bulkhead installed _________________________________20 Figure 6: Accessing the VAXStation CPU _________________________21 Figure 7: Vaxstation Option Locations ____________________________22 Figure 8: Installing the DS-KZCCA-BB VAX™-SCSI Adapter__________23 Figure 9: DS-KZCCA-BB I/O bulkhead Installed ____________________24...
