Fast EtherWORKS/PMC
Adapter
User Information
Order Number: EK-DE520-IG. C01
March 1999
This manual describes the Fast EtherWORKS/PMC
Adapter module, part number DE520-AA, AB, AC.
Revision/Update Information:
Compaq Computer Corporation
Houston, Texas
This is an updated
manual.

Advertisement

Table of Contents
loading

Summary of Contents for Compaq DE520-AA

  • Page 1 Fast EtherWORKS/PMC Adapter User Information Order Number: EK-DE520-IG. C01 March 1999 This manual describes the Fast EtherWORKS/PMC Adapter module, part number DE520-AA, AB, AC. This is an updated Revision/Update Information: manual. Compaq Computer Corporation Houston, Texas...
  • Page 2 Compaq Computer Corporation. © 1995, 1999 Digital Equipment Corporation. All rights reserved. Printed in U.S.A. Compaq, the Compaq logo, and the Digital logo registered in U.S. Patent and Trademark Office. DEC, DECchip, DECconnect, DIGITAL, and EtherWORKS are trademarks of Compaq Computer Corporation.
  • Page 3 FCC NOTICE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules.
  • Page 5: Table Of Contents

    Contents About This Manual ......1 Introduction Features ........1–1 Connector and LEDs .
  • Page 6 Connector Pinning—Front Panel RJ-45 (AA and AC Variants Only) ....... B–4 Connector Pinning—Rear I/O J4 Connector (AB Variant Only) .
  • Page 7: About This Manual

    To install the module, you need to understand the basic concepts and uses of Ethernet networks and be familiar with your system. For customer support in the U.S., call 1-800-354-9000. For customer support outside of the U.S., contact the nearest Compaq Customer Support Center.
  • Page 8 Manual Conventions This manual uses the following conventions: Convention Description Note A note contains information of special importance. Caution A caution contains information to prevent damage to the equipment. Part number A number in a black circle in text refers to the corresponding number in an accompanying illustration.
  • Page 9: Introduction

    For information about the Fast Ethernet technology, see Appendix C. The DE520 Adapter is available in three versions: • DE520-AA, PMC with an unshielded Adapter Cable • DE520-AB, PMC with P14 Connector I/O •...
  • Page 10 20 Mb/s and 200 Mb/s • Compliance with PCI revision 2.0 and 2.1 of the PCI Local Bus Specification • Compliance with FCC Class A and CISPR-22 Class A • Lifetime warranty with return of the warranty registration card to Compaq 1–2...
  • Page 11: Block Diagram Of The Pmc Adapter Module

    Figure 1–1 shows a block diagram of the PMC Adapter module. Figure 1–1 Block Diagram of the PMC Adapter Module 100-Mb/s Physical Interface 10/100-Mb/s DECchip Magnetics, PCI Bus RJ45 21140 Network Port, and Switch 10-Mb/s Physical Interface Serial LJ-04213A.AI4 1–3...
  • Page 12: Connector And Leds

    Connector and LEDs Figure 1–2 shows the connector and LEDs on the PMC Adapter module; Table 1–1 describes these components. Figure 1–2 Connector and LEDs MLO-011725 Table 1–1 Descriptions of Connector and LEDs Component Description Network connector The RJ-45 connector is a low-profile connector, requiring the module’s cable to connect to UTP Category 3, 4, or 5 cable.
  • Page 13: Warranty And Technical Support

    Turn-around time for a replacement is typically two days in the U.S. OEMs are responsible for returning the defective part. Compaq pays for the cost of shipping the replacement parts. If you are outside the United States, in countries where Compaq has direct diagnostic support...
  • Page 14 At the same time, a replacement product will be ordered. Turn-around time for a replacement is typically five days. OEMs are responsible for returning the defective part. Compaq pays for the cost of shipping the replacement parts.
  • Page 15: Installation

    Compaq recommends using a grounded antistatic wrist strap and a grounded work surface when handling any modules. Notify your carrier immediately if there is any shipping damage. If the kit is incomplete, contact your reseller or authorized Compaq distributor. 2–1...
  • Page 16: Contents Of Shipping Package

    The kit contains the following items as shown in Figure 2–1: EK-DE520-IG This manual 99-06557-00 An antistatic bag containing the PMC Adapter module 17-04307-01 A 1-meter unshielded cable designed for the DE520- AA module 17-04842-01 A 1-meter shielded cable designed for the DE520-AC module Figure 2–1 Contents of Shipping Package ML011722...
  • Page 17: Preparing To Install The Pmc Adapter Module

    Preparing to Install the PMC Adapter Module To prepare your system for installing the module: 1. Perform an orderly shutdown of the operating system. When the console prompt appears, shut off the power. Caution Make sure you turn off power to the computer before you insert or remove the module to avoid permanent damage to the module or computer circuitry.
  • Page 18: Installing The Pmc Adapter Module

    Installing the PMC Adapter Module Use the following procedure to install the module: 1. Remove the screws from the standoffs on the module and set aside for use later in this procedure. 2. Insert the module’s bezel into the cutout on the front panel of the motherboard , as shown in Figure 2–2.
  • Page 19: Connecting To The Network (Aa And Ac Variants Only)

    Connecting to the Network (AA and AC Variants Only) Note For automatic speed selection to work correctly, make sure you connect the module to the network before you load any device drivers. To connect the Fast EtherWORKS/PMC Adapter module to the network: 1.
  • Page 20: Connecting To The Network

    Figure 2–3 Connecting to the Network ML011724 3. Observe the module’s LED . The green LED lights and stays lit when the module is connected to the network device properly. If you observe any other indication, see Table 2–1 to isolate and correct the problem.
  • Page 21: Isolating Network Connection Faults

    Table 2–1 Isolating Network Connection Faults Symptom Probable Cause Action LED cycles Faulty cable Replace the cable. repeatedly from between the module solid amber (for 50 and concentrator seconds), then to (Link Error solid green for a Rate threshold period of time, and exceeded).
  • Page 22: Verifying The Pmc Adapter On The Network

    Table 2–1 (Cont.) Isolating Network Connection Faults Symptom Probable Cause Action Faulty module. Connect a loopback connector: use one side of a BN24E cable for the ST connector and use PN 12-35619-03, with the module cable, for the UTP connector. Observe the result: If the port LED for the connector changes to solid green, a problem exists...
  • Page 23: A Problem Solving

    Disconnect the module’s cable from the module. module is preventing Turn your system off, reseat the module, then turn your system from your system on again. If the problem persists, operating correctly. contact your system administrator or authorized Compaq distributor. (continued on next page) A–1...
  • Page 24 Table A–1 (Cont.) Fault Isolation By Symptom Possible Cause Recommended Action A conflict exists with another module: • IRQ settings are • Check the module’s settings in the incorrect. Installation utility. • PMC slot is not • Check that the slot is enabled. enabled for bus mastering.
  • Page 25: B General Information

    General Information This appendix provides general system specifications and cabling requirements for the Fast EtherWORKS/PMC Adapter module. Physical Description The PMC Adapter module is a PMC that uses the 32-bit PCI bus connector. The module measures 149 mm by 74 mm, and is constructed using four-layer circuit board technology with two signal layers and two power/ground layers.
  • Page 26: Leds

    LEDs The LEDs are used to indicate the status of the module and its connector. These LEDs are visible on the module’s front panel (at the back of your system). During diagnostics, the module’s Activity LED blinks once, then remains lit. Once the network software and device driver(s) are loaded, the LEDs reflect status.
  • Page 27: Operating Environment

    Caution When you add adapter modules to your computer, verify that the combined power (wattage) required for the modules does not exceed the power supply rating. Refer to your computer documentation for this information. Operating Environment Table B–3 lists the recommended operating environment specifications for the PMC Adapter module.
  • Page 28: Connector Pinning-Front Panel Rj-45 (Aa And Ac Variants Only

    Connector Pinning—Front Panel RJ-45 (AA and AC Variants Only) The 10BASE-T and 100BASE-TX twisted-pair network connectors share the same signal pins, as shown in Figure B–1. Pin Number Signal Name Transmit + Transmit - Receive + Ground Ground Receive - Ground Ground Figure B–1 RJ-45 Connector (Front View)
  • Page 29: Connector Pinning-Rear I/O J4 Connector (Ab Variant Only

    Connector Pinning—Rear I/O J4 Connector (AB Variant Only) The 10BASE-T and 100BASE-TX twisted-pair network connectors share the same signal pins, as shown in Figure B–2. Pin Number Signal Name Transmit - Transmit + Ground Ground Receive - Receive + No charge Ground Ground B–5...
  • Page 30: J4 Connector (Top View

    Figure B–2 J4 Connector (Top View) ML014602 B–6...
  • Page 31: Cabling Requirements

    Cabling Requirements Use one of the following cable types, or its equivalent based on the module variant, to connect the PMC Adapter module’s cable to the network. The AA variant uses unshielded cables and the AC variant requires shielded cables. The maximum length supported by the Ethernet is 100 meters of cable for both speeds.
  • Page 33: C Fast Ethernet Technology

    Fast Ethernet Technology The increased performance and capacity of personal computers along with the availability of cost-effective, high-resolution peripherals have fueled the development of high-performance, data-intensive applications such as graphical user interfaces, computer-aided engineering, computer-aided training, groupware, image processing, document management, network resource libraries, and multimedia. The effective utilization of these new, high-performance systems at the desktop demands new low-cost, high-performance LAN interface technologies.
  • Page 34: Advantages Of Fast Ethernet

    Advantages of Fast Ethernet Key advantages of the Fast Ethernet are: • High performance • Standards-based technology • Cost-effective migration • Vendor support High Performance One of the compelling reasons to choose Fast Ethernet for workgroups is the ability to handle both the aggregate demands of multiple LAN users and the peak traffic created by today’s high-performance PCs and sophisticated bandwidth-intensive applications.
  • Page 35: Cost-Effective Migration

    Cost-Effective Migration The seamless compatibility between 10BASE-T and 100BASE-T allows easy migration to high-speed connects. Migration is simple and economical in many important areas: • LAN cabling—100BASE-T media specifications (100BASE-TX, 100BASE-FX, and 100BASE-T4) enable Fast Ethernet to run on the most common Ethernet wiring, including Categories 3, 4, and 5 unshielded twisted-pair (UTP), shielded twisted-pair (STP), and fiber.
  • Page 36 Summary Although not all users require 100 Mb/s network performance to the desktop today, many LAN-intensive applications already push the limits of existing 10 Mb/s LANs, and can benefit from 100 Mb/s technology now. Emerging data-intensive applications and technologies (such as multimedia, groupware, imaging, and client- server databases) make 100 Mb/s networking a critical part of most LANs.
