Installing the Adapters
4. Place the adapter into the slot. Carefully press the adapter into the slot until the
adapter seats firmly (the switch clicks into a locked position when the adapter is
seated). The indicator lights change as follows:
• The bottom indicator light next to (or above) the slot changes from amber to
off.
• The top indicator light changes to green.
• The hot swap LED on the adapter turns blue while the adapter is inserted.
5. Perform one of the following:
• If the LED turns off, the adapter is inserted and has been configured; continue
with step 7.
• If the LED stays blue after the adapter is inserted, continue with step 8.
6. Enter the cfgadm command to verify that the system recognizes the adapter and
that the adapter is not configured.
In the following example, the shaded row indicates that the adapter has been
installed in slot 4. "Disconnected" in the Receptacle column indicates the adapter
is not configured.
Ap_Id
N0.IB6
N0.IB8
N0.SB0
N0.SB2
c0
pcisch0:sg6slot2
pcisch0:sg6slot3
pcisc1:sg6slot0
pcisch2:sg6slot4
pcisch2:sg6slot5
pcisch3:sg6slot1
7. Enter the
In the following example, the adapter is configured for slot 4:
cfgadm -c configure pcisch2:sg6slot4
2–4
Type
CPCI_I/O_bo
unknown
CPU_Board
CPU_Board
scsi-bus
stpcipci/fhs
unknown
unknown
unknown
unknown
unknown
cfgadm -c configure slot path
FCA2257C cPCI Host Bus Adapter for Sun Solaris Installation Guide
Receptacle Occupant
connected configured
empty unconfigured
connected configured
connected configured
connected configured
connected configured
empty unconfigured
empty unconfigured
disconnected unconfigured
connected unconfigured
empty unconfigured
command to configure the adapter.
