Adapter Features
• Complies with the following Fibre Channel standards:
— Second Generation Fibre Channel Physical and Signaling Interface
(FC-PH-2), Revision 7.4
— Third Generation Fibre Channel Physical and Signaling Interface (FC-PH-3),
Revision 9.2
— Fibre Channel-Arbitrated Loop (FC-AL-2), Revision 5.4
— Fibre Channel Fabric Loop Attachment (FC-FLA), Revision 2.7
— Fibre Channel Generic Services 2 (FC-GS-2), Revision 5.3
— Fibre Channel Switched Fabric (FC-SW), Revision 3.3
• Complies with U.S. and international safety and emissions standards
Figure 1–1 shows the cPCI adapter.
Figure 1–1: cPCI Adapter
1–2
Note: The serial number is on the back.
J1
J2
Release Button
Switch
FCA2257C cPCI Host Bus Adapter for Sun Solaris Installation Guide
