SMART Sympodium ID250 Quick Reference

Quick Reference
Sympodium ID250 Interactive Pen Display
Use the Sympodium® interactive pen display and the powerful features of SMART Board™ software to control and
write over computer applications.
The Interactive Pen Display
The pen display has three sets of buttons and indicators: a row of display control buttons, which fine tune display
properties; a group of pen-tool buttons; and a set of function buttons. The tethered pen is like a mouse, because it
allows you to control your applications, but it also enables you to write or draw in digital ink over any application.
Interactive
display
Function buttons
Battery-free
tethered pen
Checking the Status of the Interactive Pen Display
The power indicator glows blue when the unit is receiving power and a video signal. If it glows orange, ensure that
your computer is turned on and that the cable is correctly connected to the pen display and the computer.
The status indicator turns blue when the tethered pen touches the screen. If it doesn't turn blue, make sure that
the USB cable is connected to the pen display and the computer, and ensure that SMART Board software is running
on the computer.
Function Buttons
The function buttons provide quick access to
the most frequently used features of SMART
Board software. Press a function button to
launch the On-Screen Keyboard, the Floating
Tools toolbar or the Capture toolbar. Open
Notebook™ software to help you organize,
save and share notes. You can also press a
function button to make your next pen contact
a right mouse-click.
Pen-Tool Buttons
Use the pen-tool buttons to select a digital ink
color, erase digital ink or return the pen to
cursor mode.
Launches
Notebook
software
Makes next
pen contact a
right-click
Launches
On-Screen
Keyboard
Select digital
ink colors
Power button
Status and power
indicators
Display control
buttons
Pen-tool buttons
Launches
Floating Tools
Launches
Capture
toolbar
Returns pen to
mouse mode
Erases digital
ink
