SMART Podium ID422w Quick Start Manual

Using The Smart Podium
I I

Introduction

n n t t r r o o d d u u c c t t i i o o n n
You can provide your audience with an interactive experience by
connecting your SMART Podium interactive pen display to a computer
and projector. Engage and involve your audience as you write over your
favorite applications with digital ink, access websites or multimedia
content, and save your digital ink notes to share with others.
Use this guide to learn:
• About SMART Podium features
• How to use the SMART Podium
• How to customize the pen button settings
• How to customize the function button settings
• Where to find additional resources
Feature overview Fe e a a t t u u re e o o ve e rvie

Interactive Screen

The interactive screen works with your computer and
SMART Board™ software to create an interactive environment. Control
your computer with the tethered pen and write over any application with
digital ink.

Pen Tool Buttons

The pen tool buttons are a quick and easy way to select
different digital ink colors and the eraser tool.

Function Buttons

The customizable function buttons provide shortcuts to
frequently used SMART Notebook and SMART Board software tools
such as the SMART Keyboard, the Screen Capture toolbar and the
SMART Technologies SMART Technologies
e w
interactive pen display ID422w
Feature overview ( Feature overview (cont.)
orientation screen. You can also use the Right-Click button to make your
next pen contact a right-click.

Display Control Buttons

The SMART Podium automatically adjusts the image on the
interactive pen display, but in some situations you might need to
manually confi gure the display settings. Use the On-Screen Display (OSD)
controls to confi gure the display settings. The display control buttons are
located on the top of the frame.

Power and Status Indicators

The power indicator shows whether power is reaching the
interactive pen display. If the power indicator glows amber, ensure that
your computer is turned on and that the video cable is properly
connected to the interactive pen display and the computer.
The status indicator shows whether the pen is interacting with
the display. If the status indicator does not glow green when you touch
the pen to the interactive display, ensure that the USB cable is properly
connected to the interactive pen display and the computer, and that
SMART Board drivers are running.

Tethered Pen

The tethered pen is your mouse. Use the tethered pen on the
interactive display to control and manipulate items on your screen, and
write and erase in digital ink. Use the pen side switch to perform two
programmable, frequently used functions. Store the pen in the
compartment on top of the interactive pen display.
SMART Podium
( ( ( ( cont.) ) ) ) )
September 2009 September 2009
