5
Insert the ink tank into the empty slot
on the printhead. Press down gently on
the ink tank until an audible click is heard.
• Make sure the ink tank is the correct color for
the slot.
6
Close the scanning unit until it locks into place.
Maintaining the printhead
After you have printed the nozzle check pattern and checked the state of the nozzle, clean
the printhead and align it.
NOTE
• Before doing the following, open the scanning unit, press "PUSH" on the ink tanks and check that they
are securely inserted. Check how much ink is left and if there is none, replace the ink tank (
Flowchart of printhead maintenance
Print the nozzle check pattern (
This pattern allows you to check if the ink is coming out of the printhead nozzles
correctly and if the printhead is aligned.
The ink is not coming out correctly.
Step 2
Perform normal printhead cleaning
(<HEAD CLEANING> setting) (
If there is no improvement.
Step 3
Perform deep printhead cleaning (<HEAD
REFRESHING> setting) (
NOTE
• If the problem is still not solved
If you have followed steps 1 to 3 above and there is no improvement, the printhead may be damaged.
Contact the Canon Customer Care Center.
Chapter 10
Step 1
p. 10-6).
Align the printhead (
p. 10-6).
p. 10-6).
The printhead is misaligned.
Step 2
p. 10-7).
Maintenance
p. 10-4).
10
10-5
