- Page 1 EN.IO.APREGN Revision 02.A.002 SEPTEMBER 2020 USER’S MANUAL SMART DIFFERENTIAL PRESSURE TRANSMITTER for low ranges APRE-2000GN APLISENS S.A., 03-192 Warsaw, Morelowa 7 St. tel. +48 22 814 07 77; fax +48 22 814 07 78 www.aplisens.com, e-mail: export@aplisens.com...
- Page 2 possible mechanical impacts, excessive shocks and vibration; excessive temperature fluctuation; water vapour condensation, dusting, icing. Changes made to the manufacturing of products may be introduced before the paper version of the manual is updated. The up-to-date manuals are available on the manufacturer's website: www.aplisens.com.
-
Page 3: Table Of Contents
EN.IO.APREGN TABLE OF CONTENTS 1. INTRODUCTION ..................5 1.1. Purpose of the document ....................... 5 1.2. Trademarks ........................... 5 1.3. Definitions and abbreviations ....................5 1.4. Transmitter set range ......................6 2. SAFETY ...................... 7 3. TRANSPORT AND STORAGE ..............8 3.1. - Page 4 Figure 3. APRE-2000GN differential pressure transmitter – dimensions........... 10 Figure 4. APRE-2000GN differential pressure transmitter – mounting method........11 Figure 5. Connection of the APRE-2000GN transmitter and communicator or modem..... 12 Figure 6. Display information fields....................14 Figure 7.
-
Page 5: Introduction
1.1. Purpose of the document The subject of manual is smart differential pressure transmitters APRE-2000GN in standard version. The manual contains data, tips and general recommendations for safe installation and operation of the transmitters, as well as troubleshooting in case of possible failure. -
Page 6: Transmitter Set Range
PL.IO.APREGN “Upper Saturation Limit” – upper limit of the A/D transmitter processing range. The upper limit saturation point of A/D transmitter is on the pressure/differential pressure scale above the UPL point and is associated with the maximum pressure at which the analogue-digital pressure measurement transmitter reaches the upper limit of the processing capacity. -
Page 7: Safety
EN.IO.APREGN SAFETY The installation and start-up of the device and any activities related to operation shall be carried out after thorough examination of the contents of user’s manual and the instruc- tions related thereto; installation and maintenance should be carried out by qualified staff having the required authorizations to install electrical and measuring devices;... -
Page 8: Transport And Storage
GUARANTEE General terms and conditions of guarantee are available on the manufacturer's website: www.aplisens.com/ogolne_warunki_gwarancji The guarantee shall be repealed if the device is used against its intended use, failure to comply with user’s manual or interference with the structure of the device. -
Page 9: Identification
APLISENS S.A. 03-192 Warsaw Morelowa 7 St. Poland 5.2. Transmitter identification Each transmitter APRE-2000GN is equipped with a nameplate showing the following data. Figure 2. APRE-2000GN transmitter nameplate. Logo and name of manufacturer. CE mark. Product code. Transmitter type. Transmitter serial number. -
Page 10: Construction
6.1. Transmitter housing and dimensions The APRE-2000GN transmitter housing is made of polycarbonate – PC or ABS and consists of a housing body and a transparent cover to ensure the readability of the LCD display. The housing body is equipped with pressure connections for plastic tubes Ø6x1 and electrical con- nection. -
Page 11: Installation
This effect can be reduced by leading the impulse tubes side by side. When assembling transmitter mounting accessories, information about connecting pressure elements such as: reductive, nests, valves, reducer clamps, signal tubes – offered by APLISENS – may be help- ful. Data on this subject are contained in catalogue. -
Page 12: Electrical Connection
Failure to provide proper connection of the transmitter may result in danger. Connect the differential pressure transmitter APRE-2000GN according to fig. 5. Figure 5. Connection of the APRE-2000GN transmitter and communicator or modem. Communicator or modem electrical connections. In order to enable communication by connecting a communicator, modem or converter to the trans- mitter’s terminals, make sure that the resistance Ro seen from the transmitter’s terminals towards the... -
Page 13: Transmitter Power Supply
EN.IO.APREGN 8.2. Transmitter power supply 8.2.1. Transmitter supply voltage Power cables may be live. There is a risk of electric shock. Table 2. Permissible transmitter supply voltages. Version Minimum supply voltage Maximum supply voltage Standard 10 V DC 55 V DC 8.2.2. -
Page 14: Operation
EN.IO.APREGN OPERATION 9.1. Local LCD display The LCD has three primary information fields identified in the figure below as LCD1, LCD2, LCD3. Figure 6. Display information fields. LCD1 field: [mA] - value (milliamperes) of process current in line 4...20 mA, proportional to the measured pres- sure. - Page 15 EN.IO.APREGN message “ovEr” will be displayed. The image will blink to attract the operator’s attention. The diagnostic alarm mode will be enabled depending on the settings I_AL < 3.650 mA or I_AL > 21.500 mA. Additionally, common status PV_OUT_OF LIMITS and status PV_HIGH_LIMITED in the Sensor Block will be set, which can be read out via HART commu- nication;...
- Page 16 EN.IO.APREGN LCD2VR menu for selection of the type of measurement displayed on LCD2. LCD2DP menu for selecting position of comma / decimal point. FACTOR return to factory values menu. RECALL option of return to factory settings. Factory pressure/differential pressure calibrations, zero setpoints of pressure and current will be restored.
-
Page 17: Local Buttons
EXIT message. This signals entering into the MENU navigation mode. 9.3. Local configuration of setpoint APRE-2000GN transmitter enables local configuration of some of the most common setpoints via local buttons and local LCD display. 9.4. Navigation in local setpoints MENU The MENU can be accessed by pressing and holding any of the buttons for at least 4 seconds. - Page 18 EN.IO.APREGN Revision.02.A.002...
-
Page 19: Remote Configuration Of Setpoints (Hart 5/Hart 7)
Aplisens S.A. KAP-03, KAP-03Ex communicator (HART 5 only); communicators from other companies, including those using DDL and DTM libraries; PC computers equipped with HART modem (e.g. HART/USB converter by Aplisens S.A.) with Windows7 or Windows10 operating system with installed Raport 2;... -
Page 20: Start-Up
10.1. Alarm configuration Transmitter APRE-2000GN has a developed internal diagnostics, which monitors the work of elec- tronic circuits, process and environmental parameters. Diagnosed dangerous states or malfunctions of the internal transmitter systems result in setting the alarm current depending on the configuration I_AL <... -
Page 21: Configuration Of Operating Mode
EN.IO.APREGN The transmitter diagnostics continually tests the environmental parameters: temperature of the pressure measurement structure sensor; temperature of the ADC transducer converting the electric signal from the pressure sensor to the digital value of measurement; temperature of the CPU structure (transmitter's main microcontroller). If alarms from 2, 3 and 4 process variable (temperatures) are enabled, when the transmitter operating temperature lim- its are exceeded, the diagnostics will trigger an alarm depending on the settings AL_L <... -
Page 22: Correction Of Impact Of Transmitter Mounting Position On Site - Pressure Reset
EN.IO.APREGN LCD display configuration parameters; setting of the settings change lock password. 10.3. Correction of impact of transmitter mounting position on site – pressure re- Once the transmitter is mounted in a target location, it must be reset. This operation will eliminate the possible influence of the mounting position on the indication of pressure/differential pressure. -
Page 23: Maintenance
EN.IO.APREGN MAINTENANCE 11.1. Periodic inspections Periodic inspections shall be carried out in accordance with applicable standards. During the inspec- tion, the condition of the pressure (absence of loosened elements and leaks) and electrical (check of connections reliability and condition of gaskets and glands) connectors. Check the processing charac- teristics by performing the operations specific for the CALIBRATION and possibly CONFIGURATION procedure.
