DTR.APC.APR.ALW.03
(ENG)
APLISENS
MANUFACTURE OF PRESSURE TRANSMITTERS
AND CONTROL INSTRUMENTS
USER'S MANUAL
SMART PRESSURE TRANSMITTER
type: APC-2000ALW
SMART DIFFERENTIAL PRESSURE TRANSMITTER
type: APR-2000ALW, APR-2200ALW, APR-2000GALW
SMART LEVEL PROBE
type: APR-2000YALW
SMART LEVEL TRANSMITTER APC-2000ALW/L...
SMART DENSITY TRANSMITTER APR-2200ALW/D
Edition E6
WARSAW MAY 2018
APLISENS S. A. 03-192 Warszawa, ul. Morelowa 7
tel. +48 22 814 07 77; fax +48 22 814 07 78
www.aplisens.pl, e-mail: aplisens@aplisens.pl

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APR-2000ALW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aplisens APR-2000ALW

Summary of Contents for Aplisens APR-2000ALW

  • Page 1 SMART LEVEL PROBE type: APR-2000YALW SMART LEVEL TRANSMITTER APC-2000ALW/L… SMART DENSITY TRANSMITTER APR-2200ALW/D Edition E6 WARSAW MAY 2018 APLISENS S. A. 03-192 Warszawa, ul. Morelowa 7 tel. +48 22 814 07 77; fax +48 22 814 07 78 www.aplisens.pl, e-mail: aplisens@aplisens.pl...
  • Page 2 Installation of intrinsically safe versions should be performed with particular care, in accordance with the regulations and standards applicable to that type of installation Changes in the production of transmitters may precede a paper updating for the user. The current user manuals are available at http. www.aplisens.pl...

  • Page 3: Table Of Contents

    5.1. APC..., APR... C ........................28 OMMON PARAMETERS 5.2. APC-2000ALW M ............... 29 EASUREMENT RANGES AND METROLOGICAL PARAMETERS 5.3. APR-2000ALW, APR-2200ALW M ........31 EASUREMENT RANGES AND METROLOGICAL PARAMETERS 5.4. APR–2000GALW, M .............. 33 EASUREMENT RANGES AND METROLOGICAL PARAMETERS 5.5. APR–2000YALW. M ...............
  • Page 4 TYPE CONNECTOR WITH FLUSH DIAPHRAGM WITH THREAD G1/2” G1”....................... 60 . 9. P ROCESS CONNECTIONS . 10. APR-2000ALW ........61 DIFFERENTIAL PRESSURE TRANSMITTER WITH TYPE VENTED COVERS . 11. APR-2000ALW )..61 DIFFERENTIAL PRESSURE TRANSMITTER WITH A SINGLE DIRECT DIAPHRAGM SEAL EXAMPLE .

  • Page 5: Appendix Exd.atex

    Exd VERSION in accordance with ATEX directive 1. Introduction 1.1. This “Appendix Exd.ATEX” applies to transmitters of types APC-2000ALW/XX, APR-2000ALW/XX, APR-2200ALW/XX, APR-2000GALW/XX and APR-2000YALW/XX in Exd versions only, marked on the rating plate as shown in p.3 and denoted Exd in the Product Certificate.
  • Page 6 Appendix Exd.ATEX. (ENG) Items b), c), d) are available on www.aplisens.pl 5. Power supply and exploitation of transmitters. 5.1. The transmitter connecting should be made after introduction with present instruction content. Electrically transmitter should be connected according to scheme at p.6 Appendix Exd.ATEX.
  • Page 7 Because of the transmitter damage possibility, the ambient temperature should not be allowed to become higher than 80ºC, even when there is no explosion risk. 6. The electrical connection way of transmitter’s series: APC-2000ALW/XX, APR-2000ALW/XX, APR-2200ALW/XX, APR-2000GALW/XX and APR-2000YALW/XX in Exd version Fig. 2.
  • Page 8 DTR.APC.APR.ALW.03 (ENG) Appendix Exd.ATEX Table 1. Permitted cable glands Type Producer Screw Feature Other marking No of certificate 501/423 HAWKE M20x1.5 Exd IIC dimension OS, O, A Baseefa 06 ATEX 0056X 501/421 HAWKE M20x1.5 Exd IIC dimension OS, O, A Baseefa 06 ATEX 0056X ICG 623 HAWKE...

  • Page 9: Appendix Exd.iecex

    Exd VERSION in accordance with IECEx certificate 1. Introduction 1.1. This “Appendix Exd.IECEx” applies to transmitters of types APC-2000ALW/XX, APR-2000ALW/XX, APR-2200ALW/XX, APR-2000GALW/XX and APR-2000YALW/XX in Exd versions only, marked on the rating plate as shown in p.3 and denoted Exd in the Product Certificate.
  • Page 10 Appendix Exd.IECEx. (ENG) Items b), c) are available on www.aplisens.pl 5. Power supply and exploitation of transmitters 5.1. The transmitter connecting should be made after introduction with present instruction content. Electrically transmitter should be connected according to scheme at p.6 Appendix Exd.IECEx.
  • Page 11 In danger zone don’t unscrew transmitter covers and don’t change the display position or its back lighting. 6. The electrical connection way of transmitter’s series: APC-2000ALW/XX, APR-2000ALW/XX, APR-2200ALW/XX, APR-2000GALW/XX and APR-2000YALW/XX in Exd version  According to the p.6 DTR.APC.APR.ALW.03(ENG) Appendix Exd.ATEX.

  • Page 12: Appendix Exi.atex

    DTR.APC.APR.ALW.03 (ENG) III. APPENDIX Exi.ATEX APC–2000ALW PRESSURE TRANSMITTER, 1453 APR–2000ALW, APR–2200ALW, APR–2000GALW, DIFFERENTIAL PRESSURE TRANSMITTERS, APR–2000YALW LEVEL PROBE, APC–2000ALW/L LEVEL TANSMITTER APR-2200ALW/D DENSITY TRANSMITTER Ex VERSION in accordance with ATEX directive 1. Introduction 1.1. This “Appendix Exi.ATEX” applies to transmitters of types APC–2000ALW, APR–2000ALW, APR–2200ALW, APR–2000GALW, APC–2000ALW/L, APR–2200ALW/D and APR–2000YALW in Ex versions only, marked on the rating plate as shown in p.2.2 and denoted Ex in the Product Certificate.
  • Page 13 Appendix Exi.ATEX. (ENG) Items b), c), d) are available on www.aplisens.pl 5. Permitted input parameters (based on data from the FTZÚ 08 ATEX 0020X certificate, and certification documentation) The transmitters should be powered via the associated power feeding and measurement devices provided with the relevant intrinsic-safe certificates.
  • Page 14 DTR.APC.APR.ALW.03 (ENG) Appendix Exi.ATEX If Uo < then parameters Uq, Io, Po are interrelated as follows: – Uo) Uo(U Uq = Rw = Po = for Uo ≤ 1/2U 5.4. For power supply with a rectangular output characteristic -40ºC  Ta  80ºC and T5 Ui = 24V Ii = 25mA Pi = 0,6W -40ºC ...
  • Page 15 DTR.APC.APR.ALW.03 (ENG) Appendix Exi.ATEX 6. How to connect Ex transmitters APC…, APR… The transmitter and other devices in the measuring loop should be connected in accordance with the intrinsic-safety and explosion-safety regulations and the conditions for use in dangerous areas. Failure to observe the intrinsic-safety regulations can cause explosion and the resulting hazard to people.

  • Page 16: Appendix Exi.iecex

    DTR.APC.APR.ALW.03 (ENG) IV. APPENDIX Exi.IECEx APC–2000ALW PRESSURE TRANSMITTER, APR–2000ALW, APR–2200ALW, APR–2000GALW, DIFFERENTIAL PRESSURE TRANSMITTERS, APR–2000YALW LEVEL PROBE, APC–2000ALW/L LEVEL TANSMITTER APR-2200ALW/D DENSITY TRANSMITTER Ex VERSION in accordance with IECEx certificate 1. Introduction 1.1. This “Appendix Exi.IECEx” applies to transmitters of types APC–2000ALW, APR–2000ALW, APR–2200ALW, APR–2000GALW, APC–2000ALW/L, APR–2200ALW/D and APR–2000YALW in Ex versions only, marked on the rating plate as shown in p.2.2 and denoted Ex in the Product Certificate.
  • Page 17 Appendix Exi.IECEx. (ENG) Items b), c) are available on www.aplisens.pl 5. Permitted input parameters (based on data from the IECEx FTZÚ 14.0026X certificate, and certification documentation) The transmitters should be powered via the associated power feeding and measurement devices provided with the relevant intrinsic-safe certificates.
  • Page 18 DTR.APC.APR.ALW.03 (ENG) Appendix Exi.IECEx 5.3. For power supply with a rectangular output characteristic -40ºC  Ta  80ºC and T5 Ui = 24V Ii = 25mA Pi = 0,6W -40ºC  Ta  80 º Ui = 24V Ii = 50mA Pi = 1,2W C and T5, The supply of power from a source with a rectangular characteristic means that the voltage of the Ex power...

  • Page 19: V. Appendix Mid

    DTR.APC.APR.ALW.03 (ENG) Appendix MID APPENDIX MID APC-2000ALW PRESSURE TRANSMITTERS, 1453 GAUGE and ABSOLUTE, APPLICATIONS ACCORDANCE IN EN 12405-1:2005+A2:2010 STANDARD INTRODUCTION 1.1. The "MID Appendix" applies only to the APC-2000ALW absolute / relative transmitters applications where they are as instruments for use in/as measuring devices (MI-002 gas) in accordance with the EN 12405-1:2005 +A2:2010 standard harmonized to Measuring Instruments Directive (MID) 2014/32, and the OIML R140:2007 recommendations.
  • Page 20 Declaration of Conformity - on request; User's Manual; Copies of certificates - on request; Calibration certificate - on request. Items: b, c, d can be found at: www.aplisens.pl APC-2000ALW for MID applications. Technical parameters 13.5* ÷ 28V DC Transmitter supply (Usup) for Exi versions 13.5* ÷45V DC...
  • Page 21 Transmitters in the MID version are equipped with one of the following types of Aplisens pressure ports: M, P, G1/2 G1/4, GP, R1/2, 1/2NPT (see p.5.2.4 DTR.APC.APR.ALW.03(ENG)). Pressure connection type, which designation given is the type of transmitter, the purchaser should agree with the manufacturer.
  • Page 22 DTR.APC.APR.ALW.03 (ENG) Appendix MID For electrical connection should be use twisted pair cable; shielded or not shielded, flexible, with diameter 5mm ≤  ≤ 9mm, complies to ATEX standards. Example of the type of cable is shown below. Producer Technokabel LAPPKABEL ®...
  • Page 23 DTR.APC.APR.ALW.03 (ENG) Appendix MID 6.2. Measurement error (according to EN12405-1:2005+A2:2010) in relation to the measured value:  at the rated temperature range (-25 ÷ 55ºC) ≤ 0.5%  ≤ 0.2% at reference conditions ≤ 0.5% 6.3. Long term stability / 5 years The manufacturer recommends a vertical mount transmitter APC-2000ALW during the pressure measurements in MID applications.
  • Page 24 PC with Windows XP or higher, with at least 512 MB of RAM;  Report 2 APLISENS software. A computer with a converter must be connected to the transmitter as shown in Figure 2a or 2c for the load resistance Ro <240 , see User's Manual DTR.APC.APR.ALW.03(ENG) p.16. Drawings. After starting Report 2 program read data from the transmitter.

  • Page 25: Vi. Appendix Sil

    DTR.APC.APR.ALW.03 (ENG) VI. APPENDIX SIL Preparation of transmitter for operation in functional safety systems. This document applies only to APC-2000ALW or APR-2000APR transmitters in N and Ex versions with hardware version 3.0 and software version >=3.4. The transmitter should be connected to a computer, operating with Windows XP, 7, 8, 10 OS, to configure it using HART communication before target installation.
  • Page 26 DTR.APC.APR.ALW.03 (ENG) Set alarm current mode to “High” (>21.5 mA) or “Low” (<3.7 mA), depending on PLC configuration, in the “Specific parameters” tab. Note: During configuration of PLC response to alarm signal from the transmitter, take into account that regardless of “High” or “Low” setting some critical alarms from the transmitter can be signalled always by “Low”...
  • Page 27 DTR.APC.APR.ALW.03 (ENG) 6. User should change password for unlocking/locking settings changes in the transmitter in the "Write protection" --> "Change password" tab. Allowed characters are: digits 0-9 and letters A,B,C,D,E,F. Factory set password: 00 00 00 00. 7. Set "Write protect" to "Blocked” in the “Write protection” tab to prevent change of settings using HART communication.

  • Page 28: Features, Installation And Maintenance Of Transmitters

    Humidity: B, Vibrations: B, EMC: B, Enclosure: C. 1.7. The APC-2000ALW, APR-2000ALW transmitters are also made in a version which complies with the PED Pressure Directive, meet the requirements for category IV, and then carry additional markings as in p. 4.3.

  • Page 29: Applications And Main Features

    (current loop). The use of smart electronics enables regulation of the zero point, the measurement range, damping, radical conversion characteristic and other functions using an Aplisens KAP communicator or from a PC using a HART/RS232 or HART/USB/ Converter and Aplisens “Raport 2” configuration software. 4. IDENTIFYING MARKS. ORDERING PROCEDURE 4.1.

  • Page 30: Technical Data

    4÷20mA. For this purpose: KAP-03, KAP-03Ex communicator, HART/RS232 converter or HART/USB Converter (APLISENS) or another converter, PC computer and Raport 2 programme can be used. Resistance of power supply cables or resistors for communication, and output resistance of the power supply can lead to voltage drops on the way from the power supply to transmitter terminals.

  • Page 31: Apc-2000Alw Measurement Ranges And Metrological Parameters

    DTR.APC.APR.ALW.03 (ENG) Electronics casing High pressure cast of aluminium alloy, lacquered with chemical -resistant oxide enamel, colour yellow (RAL 1003) or 1.4401 (316) Materials for APC… APR… transmitters with diaphragm seals are described in Diaphragm Seals Data Sheets. 5.1.3. Enclosure ingress protection IP 66,67 according to EN 60529 IP 65 according to EN 60529 with PD connector...
  • Page 32 DTR.APC.APR.ALW.03 (ENG) 5.2.2. Permitted environmental conditions -40º ÷ 85ºC (for PED version in accordance with p.5.2.4) Operating temperature range Operating temperature range for intrinsic-safe versions in accordance with Appendix Exi.ATEX or Appendix Exi.IECEx. Operating temperature range for flame-proof versions in accordance with Appendix Exd.ATEX or Appendix Exd.IECEx.

  • Page 33: Apr-2000Alw, Apr-2200Alw Measurement Ranges And Metrological Parameters

    For measurements of density or phase boundaries (in the sugar and chemical industries and in refineries) the vertical spacing of the diaphragm seals can be larger. 5.3.3. APR-2000ALW, APR-2200ALW. Permitted environmental conditions -25º ÷ 85ºC (for PED version in accordance with p.5.3.5) Operating temperature range -40º...
  • Page 34 APR-2000ALW – C-type connector to mount together with a valve manifold see Fig.10, available for PED version. APR-2000ALW, with single direct diaphragm seal – as in the example (Fig.11) or with other diaphragm seals in accordance with “DIAPHRAGM SEALS” catalogue cards.

  • Page 35: Apr-2000Galw, Measurement Ranges And Metrological Parameters

    0.1 % / 10bar * zeroing in static pressure conditions with zero differential pressure eliminates this error; Medium density range – up to 1.1 g/cm 3 – (standard version) – over 1.1 g/cm 3 – (special version by arrangement with Aplisens...

  • Page 36: Apc-2000Alw/L

    DTR.APC.APR.ALW.03 (ENG) 5.6. APC–2000ALW/L…. Measurement ranges and metrological parameters 5.6.1. APC–2000ALW/L…level transmitter. Measurement ranges. N Nominal range (FSO) 0...20m H 0...10m H 0...2.5m H Minimum set range 2m H 1m H 0.5m H Overpressure limit 0...200m H 0...100m H 0...25m H 5.6.2.

  • Page 37: Apc ... Apr ... E Nvironmental Parameters

    DTR.APC.APR.ALW.03 (ENG) 5.7.3. APR–2200ALW/D. Metrological parameters.  ± 0,1% for the nominal range Accuracy  ± 0,3% for the range 0 ÷ 10% FSO  0,1% / 2 years (for the nominal range) Long term stability Error due to supply voltage changes 0,002%(FSO)/1V <...

  • Page 38: Construction

    DTR.APC.APR.ALW.03 (ENG) 6. CONSTRUCTION 6.1. Principle of measurement. Electronic system construction The electrical signal from the sensor which is proportional to the pressure is sent to a digital analog input and converted to a digital signal. The digital signal is transmitted through optoelectronic galvanic barrier to conditioning module.

  • Page 39: Place Of Installation

    DTR.APC.APR.ALW.03 (ENG) 7. PLACE OF INSTALLATION 7.1. General recommendations 7.1.1. The smart pressure transmitter and differential pressure transmitter can be installed both indoors and outdoors. It is recommended that transmitters intended for outdoor use be placed in a box or under cover. 7.1.2.

  • Page 40: Mechanical Vibration Shocks. Corrosive Media

    DTR.APC.APR.ALW.03 (ENG) 7.5. Mechanical Vibration shocks. Corrosive Media 7.5.1. Transmitters should correctly work with vibrations with amplitudes to 1.6 mm and accelerations to 4g. If strong vibrations are carried via the pressure line and disturb of measuring, use should be made of elastic pulse lines or transmitters with a remote diaphragm seal.

  • Page 41: Apr... I Nstallation And Connections

    The transmitter sensor is immersed in measured medium. The sensor can be hung on the power cable by using a Aplisens SG handle , but especially in the case of long cables, or if are opportunities of hooking protruding elements when the cable is pulling up, it is recommended that the sensor suspended on a steel rope using the sensor lug.

  • Page 42: Electrical Connection

    (see the table, column 3). Also external protective devices may be used, e.g. the UZ-2 Aplisens system, or others. When the transmission lines are long, it is advantageous to use one protective device near the transmitter (or inside it), and another near entry points to other devices used in conjunction with it.

  • Page 43: Earthing

    The transmitter may also be calibrated, by taking readings with the input pressure controlled using a standard device. These process and zero-point adjustments are called “Calibration”. 10.2.4. Configuration and Calibration of the transmitter are carried out using an Aplisens KAP communicator, certain HART communicators or a PC with HART/RS232 converter and Aplisens “Raport 2” software.
  • Page 44 DTR.APC.APR.ALW.03 (ENG) 10.2.5. TRANSMITTER CONFIGURATION WITH USING ITS BUTTONS AND LOCAL MENU 10.2.5.1. Local menu - structure. Local configuration of transmitters. If the option of local configuration is active, operator can change transmitter set using buttons being below display. The access to buttons will get after unscrewing the display cover. Then we can also change the display position (see Fig.
  • Page 45 DTR.APC.APR.ALW.03 (ENG)
  • Page 46 DTR.APC.APR.ALW.03 (ENG) The selected unit should be confirmed by pressing [◙]. After approval the parameter transmitter will confirm the party of command by the "DONE" or report the error number. The "← BACK" cause goes up one level. Descriptions: Local Menu Submenu Notice Return from the local Menu to the normal operation of the transmitter...
  • Page 47 DTR.APC.APR.ALW.03 (ENG) Set the decimal point position on LCD2. In a situation where the value provided to display on the display LCD2 cannot be displayed properly LCD2DP due to the position of the decimal point, this is indicated by displaying the four flashing dots •...
  • Page 48 DTR.APC.APR.ALW.03 (ENG) 10.2.6. View local LCD display Changes of the display options in local MENU are possible using buttons, or remote way using communicator, or the PC software. If it is necessary the display switching off is also possible. The display switching of function is possible with using communicator or PC software only.
  • Page 49 DTR.APC.APR.ALW.03 (ENG) 10.2.8. Configuration of the APR-2200ALW transmitters to measure the level, density of liquid and phase boundary Configuration of the APR-2200ALW transmitters to measure the level of liquid in a tank. KAP-03 Configuration of the APR-2200ALW transmitters to measure density of liquids.
  • Page 50 DTR.APC.APR.ALW.03 (ENG) KAP-03...
  • Page 51 DTR.APC.APR.ALW.03 (ENG) 10.2.9. Configuration of the APR-2000YALW smart level probes Mechanical installation On the flange of the tank Upper equalization hole Lower equalization hole Diaphragm seal unit 10.2.10. Configuration of the APR- 2000ALW transmitters for the flow measurements with the orifice plate. It is important to proper placement of the transmitter depending on the type of measured medium, otherwise it may negative impact on the measurement.
  • Page 52 Set the square root output transmitter signal and the cutoff point [in % FS]; remotely using computer and Aplisens Raport 2 software according with p. 10.2.4 or locally with transmitter buttons (up to 1% only) according to p. 10.2.5 of the Manual.

  • Page 53: Alarms

    DTR.APC.APR.ALW.03 (ENG) APR-2000ALW transmitter analog output signal with setting cutoff point in n%. The device configuration example: Transmitter configuration parameters  0…100 kPa Basic range  0…50 kPa Set range  Cutoff 5% of the set range Assemble the measuring system in accordance with Figure 2 and run Raport2 according to IO.RAPORT2: ...
  • Page 54 DTR.APC.APR.ALW.03 (ENG) Example: Exceeding the basic range of the pressure by more than 50% is signaled on the display using the OVER 'ouEr' UNDER 'undEr' message. The alarm in case of exceeding the range of pressure in the transmitter in MID version is described in the MID annex.

  • Page 55: Inspections And Spare Parts

    DTR.APC.APR.ALW.03 (ENG) 11. INSPECTIONS AND SPARE PARTS 11.1. Periodic service Periodic inspections should be made in accordance with the regulations to which the user is subject. During inspection, the pressure connectors should be checked for loose connections and leaks, the electrical connectors should be checked with regard to tightness and the state of the gaskets, cable glands, and the diaphragm seals should be checked for tarnishing and corrosion.

  • Page 56: Additional Information

    DTR.APC.APR.ALW.03 (ENG) 15. ADDITIONAL INFORMATION The manufacturer reserves the right to make constructional and technological changes which do not lower the quality of the transmitters. 15.1. Related documents IO.KAP-03.02 – Communicator User’s Manual. IO.RAPORT 2 – “Raport 2” software and HART/RS232 converter User’s Manual. DTR.HB.01 –...

  • Page 57: Transmitters

    DTR.APC.APR.ALW.03 (ENG) Fig. 2. Electrical connections for APC..., APR... transmitters: Fig.2a. The link of transmitter and communicator or converter to current line by the switch box (in case of the resistance in current loop is higher than 240Ω). Communicator or converter connection to the transmitter’s terminals In order to enable local communication by connecting a communicator or converter to the transmitter’s terminals, make sure that the resistance Ro from the transmitter’s terminals to the power supply source lies within the range of 240÷1100 ...
  • Page 58 DTR.APC.APR.ALW.03 (ENG) Fig.2c. The link of transmitter and communicator or converter to <SIGNAL+> <TEST+> transmitter terminals in case of the resistance in current loop is smaller than 240Ω. Fig.2d. The link of transmitter and communicator or converter to <SIGNAL+> <SIGNAL-> transmitter terminals in case of the resistance in current loop is smaller than 240Ω.

  • Page 59: Smart Pressure Transmitter

    DTR.APC.APR.ALW.03 (ENG) Fig. 3. APC-2000ALW smart pressure transmitter. Fig. 4. APC..., APR..display rotation possibility, configuration buttons.

  • Page 60: Mid

    DTR.APC.APR.ALW.03 (ENG) ±180 with 90 pitch unscrew the Configuration display cover buttons and casing display screws Move the electronic unit from transmitter casing, take up the upper part of the casing with display from the catch and revolve its to left or to right to the display setting at needed position.
  • Page 61 DTR.APC.APR.ALW.03 (ENG) Fig.6a. M-type connector Fig.6b. Socket for M-type connector with M20x1.5 thread min.15 diaphragm seal Fig.7a. P-type connector Fig.7b. Socket for P-type connector with M20x1.5 thread min.15 diaphragm seal Fig.8a. CM30x2-type connector Fig.8b. Socket for Fig.8c. Socket for with flush diaphragm CM30x2-type CM30x2-type connector with M30x2 thread,...

  • Page 62: M30 Xthread G1/2" And G1

    DTR.APC.APR.ALW.03 (ENG) 24,5 -0.5 14,5 min. Fig.9b. Socket for G1/2-type connector. Fig.9a. G1/2 -type connector with G1/2" thread, 21,5 -0,2 min.10,5 Sealing: teflon 21,2 x 24,4 x 1,7 O-ring 15x2 20,5 -0,1 27-6kt. Fig.9c. CG1/2 -type connector Fig.9d. Socket for with flush diaphragm CG1/2 - type connector with G1/2"...

  • Page 63: Ctype Vented Covers

    DTR.APC.APR.ALW.03 (ENG) Fig. 10. APR-2000ALW differential pressure transmitter with C type vented covers. S-T type tube flanged diaphragm seal S-P type flush flanged diaphragm seal Fig. 11. APR-2000ALW differential pressure transmitter with a single direct diaphragm seal (example).
  • Page 64 DTR.APC.APR.ALW.03 (ENG)  Assembly Kit ("Mounting bracket 25" made by APLISENS) for fitting differential pressure transmitters  with P-type connector on a 25 pipe see catalogue cards "Fitting accessories". Fig. 12. Example: how to install the APR-2200ALW transmitters with remote diaphragm.

  • Page 65: 2" Pipe

    Fig. 13. Example: how to install the APR-2000ALW transmitter on a vertical or horizontal pipe. Fastener C2 for fitting differential pressure transmitters with a valve manifold to a 2” pipe see catalogue cards „Fitting accessories” Fig. 14. Example: how to install the APR-2000ALW transmitter with a valve manifold to a 2” pipe.

  • Page 66: (Examples)

    DTR.APC.APR.ALW.03 (ENG) Fig. 15. APR-2200ALW differential pressure transmitter with two remote diaphragm seals (examples). Fig. 16. APR-2200ALW differential pressure transmitter with direct and remote diaphragm seal (examples).

  • Page 67: Transmitter

    DTR.APC.APR.ALW.03 (ENG) Fastening on a pipe Fastening to a wall Fig. 17. Example: how to install the APC..., APR... transmitter.
  • Page 68 DTR.APC.APR.ALW.03 (ENG) Fig. 18. APR-2000GALW smart differential pressure transmitter for low ranges. a) APR-2000GALW transmitter – industrial version with C type process connector to mount together with a valve manifold or weldable impulse line connectors. b) APR-2000GALW transmitter – economical version with PCV type process connector. c) APR-2000GALW transmitter –...
  • Page 69 DTR.APC.APR.ALW.03 (ENG) Fig. 19. APR–2000YALW smart level probe for pressure tanks.

  • Page 70: Transmitters

    DTR.APC.APR.ALW.03 (ENG) Fig. 20. The explosion - proof joints of APC..., APR... transmitters. Lock the cover tight by unbolting the screw WARNING- CIRCUIT IS ALIVE Fig. 21. How to lead the casing of APC..., APR... transmitters.

  • Page 71: Smart Level Transmitters

    DTR.APC.APR.ALW.03 (ENG) Fig. 22. APC–2000ALW/LSG… smart level transmitters.
  • Page 72 DTR.APC.APR.ALW.03 (ENG) Fig. 23. APC–2000ALW/LM & APC–2000ALW/LSP smart pressure or level transmitters.
  • Page 73 DTR.APC.APR.ALW.03 (ENG) Fig. 24. APR–2200ALW/D… smart hydrostatic density transmitter - example...
  • Page 74 DTR.APC.APR.ALW.03 (ENG) Fig. 25. Additional equipment for fitting of pressure transmitters. Edition n° Date Description Added appendix SIL. 01-2017 Added note in point 5.2.5. Correction of norms. Editorial corrections 03-2017 Added the figure to the 8th point of instruction. The abs. 1-7 MPa measuring range was added for 07-2017 the converters according to MID.
