Table 4-4 Netplex Power/Comm Port Pin-Out; Table 4-5 12 Pin Netplex Base Port Pins - FutureLogic PSA-66-ST2 Technician Manual

Table 4-5 lists the pin-out of the 12 pin base port. The Modulated +24VDC pin has the same
function as the bezel port pin.
Note: The Bezel port on the rear of the printer is identical in function and
characteristics to the one on the front of the printer.
© 2002 – 2007 FutureLogic, Incorporated. All Rights Reserved.
Table 4-4 Netplex Power/COMM Port Pin-out
Pin Function
1 MRESET
2 Netplex TXD
3 +13V
4 Netplex RXD
5 NETGND
6 +25VDC
7 BGND
8 No Connect
Table 4-5 12 Pin Netplex Base Port Pins
Pin
1 BGND (+24V Return)
2 NETPLEX RXD
3 +13VDC
4 SWITCHED +24VDC
5 No Connect
6 MRESET
7 NETPLEX TXD
8 +24VDC
9 No Connect
10 RX2
11 TX2
12 AGND
*I/O viewed from the printer
Operators and Technicians Manual
I/O*
I
I
-
O
-
-
-
-
Function
MNL Page 13 of 52 12/07/2007
MNL-000003 REV.N
