Loading Paper

Generally, the only printer service required is to load new paper stacks. Use the automatic
paper-loading feature to simplify this process to two steps: putting the paper stack into the
Paper Tray and feeding the paper to the Paper Loading Slot of the printer.
To load paper:
1. Pull open the Printer Drawer until the Paper Tray is completely accessible.
2. Place the paper stack in the printer as indicated by the band around the stack and the
label on the bottom of the Paper Tray.
Tip: To prevent a new paper stack from sticking together, fan out the paper after you
take off the band.
3. Feed the paper into the Paper Loading Slot and release it once the motor engages and the
printer takes hold of the paper.
The printer automatically pulls through a form or two, leaving it registered at the top of
a form.
4. Remove any excess ticket from the printer.

Feeding Paper

The printer is designed to run with black mark indexed paper.
Use the FEED button to feed paper into printer. Press the FEED button to advance the paper
to the top of the next form.
© 2002 – 2007 FutureLogic, Incorporated. All Rights Reserved.
Figure 2-2
Figure 2-3 Feed Paper into Paper Loading Slot
Operators and Technicians Manual
Load a Paper Stack
