  • Page 1 Operators and Technicians Manual PSA-66-001N PSA-66-ST PERATORS AND ECHNICIANS ANUAL PSA-66-ST RS232 Interface PSA-66-001N Netplex Interface INDUSTRIAL, DIRECT THERMAL GAMING / LOTTERY MACHINE VOUCHER PRINTER...
  • Page 2 Operators and Technicians Manual PSA-66-001N PSA-66-ST IMPORTANT NOTES REGARDING THIS MANUAL • These specifications subject change without notice and may not completely and correctly document the operation of this product. Copyright © 2003 Futurelogic, Inc. UM-STO-C Revision C...

  • Page 3: Table Of Contents

    Operators and Technicians Manual PSA-66-001N PSA-66-ST ABLE OF ONTENTS PRODUCT OVERVIEW ..........................6 PSA-66-ST PSA-66-001N H .................... 6 IGHLIGHTS OPERATOR INTERFACE ........................... 7 ....................7 PERATOR ONTROLS AND NDICATORS ........................8 RINTER ENSOR UNCTIONS ............................8 APER OADING ........................... 10...
  • Page 4 Operators and Technicians Manual PSA-66-001N PSA-66-ST List of Tables ........................10 ABLE EZEL ISPLAY TATUS ....................10 ABLE EYPAD TATUS EPORTING ......................... 19 ABLE RONT EZEL ......................... 20 ABLE RONT EZEL ....................21 ABLE ETPLEX RINTER ABLE ......................... 22 ABLE...
  • Page 5 Operators and Technicians Manual PSA-66-001N PSA-66-ST List of Figures ........................7 IGURE PERATOR ONTROLS ....................12 IGURE AMPLE ONFIGURATION ICKET PSA-66-001N F ....................19 IGURE RONT EZEL PSA-66-001N B ....................20 IGURE RINTER PSA-66-001N C ................... 21 IGURE ABLE ONNECTOR PSA-66-ST F ......................

  • Page 6: Product Overview

    PRODUCT OVERVIEW PSA-66-ST and PSA-66-001N Highlights The PSA-66-ST refers to both the PSA-66-ST and PSA-66-001N versions and is an advanced thermal printer capable of creating high quality complicated output with a minimum of development and effort on the part of the user. The printer module supports both serial and a Netplex current loop interface to allow it to operate in any standard slot machine on the market.

  • Page 7: Operator Interface

    Operators and Technicians Manual PSA-66-001N PSA-66-ST OPERATOR INTERFACE Operator Controls and Indicators The printer is equipped with 2 status indicators and 2 operator controls to allow the operator to know the status of the printer at all times. The status indicators are: •...

  • Page 8: Printer Sensor Functions

    Operators and Technicians Manual PSA-66-001N PSA-66-ST Printer Sensor Functions There are 6 primary sensor functions on the PSA-66-ST printer: • Paper out • Paper level low • Paper taken • Paper jam • Printer platen engaged • Printer opened These sensors work in conjunction with the game firmware to provide reliable trouble-free operation. Any error conditions as a result of these sensors will be indicated by the front bezel light and keypad LEDs.
  • Page 9 Operators and Technicians Manual PSA-66-001N PSA-66-ST Follow these steps to load paper: Pull open the printer drawer until the paper tray is completely accessible. Place the paper stack in the printer as indicated by the band around the stack and the label in the bottom of the paper tray.

  • Page 10: Bezel Operation

    Operators and Technicians Manual PSA-66-001N PSA-66-ST Bezel Operation The front bezel display allows the operator to determine the state of the printer on the casino floor, at a distance, without disturbing the game. The table below lists the various conditions which the bezel indicates.

  • Page 11: Paper Feed Operation

    Operators and Technicians Manual PSA-66-001N PSA-66-ST :. This condition results when the printer is in an over temperature condition. If the EMPERATURE RROR printer is operating in an environment where the ambient temperature is roughly room temperature, this error would most likely be the result of a hardware problem. The printer will automatically resume operation after the detected head temperature reaches legal operation limits.

  • Page 12: Clearing A Paper Jam

    Operators and Technicians Manual PSA-66-001N PSA-66-ST Figure 2-2 Sample Configuration Ticket Model: PSA-66-ST Firmware: 2.4.0.0.0 Model number and software version COMMUNICATION Interface: serial Baud Rate: 19200 Data Bits: System communications setup Parity: NONE Handshaking: HARDWARE PRINT CONTROL Darkness Control: +00%...
  • Page 13 Operators and Technicians Manual PSA-66-001N PSA-66-ST DO NOT: • Ever allow a screw driver or other probing object to come into contact with the printer; this can cause permanent damage Undo the mechanism fastening screw at the top of the printer plate at the front of the printer: 1 –...

  • Page 14: Servicing The Printer

    Operators and Technicians Manual PSA-66-001N PSA-66-ST 3 SERVICING THE PRINTER Should the printer require service outside of the game, the sliding module which includes the majority of electronics may be easily removed and replaced. This chapter covers the sliding module removal operation.
  • Page 15 Operators and Technicians Manual PSA-66-001N PSA-66-ST Slide the unit open until it locks in the open position. 2 – slide the unit open until it locks If you can access the ribbon cable which attaches the sliding module to the stationary module, go to the next step.
  • Page 16 Operators and Technicians Manual PSA-66-001N PSA-66-ST Release the ribbon cable by spreading the finger latches at the rear of the unit: 3 – release the finger latches to eject the ribbon cable Be sure to note that the black end of the ribbon cable connects to the rear daughter board (Gray end of cable connects to main controller.
  • Page 17 Operators and Technicians Manual PSA-66-001N PSA-66-ST Press in the release lever under the front of the sliding module to release the sliding printer module. The will release the locking mechanism and the unit may now be pulled completely out of the stationary module.

  • Page 18: Removing The Inner Module Ports

    Operators and Technicians Manual PSA-66-001N PSA-66-ST 4 PORTS Introduction This section details the connector pin outs on the PSA-66-ST printer. There are actually two versions of the PSA-66-ST printer by part number are: PSA-66-001N Netplex Printer PSA-66-ST RS232 Printer This section is divided into two sub-sections, one for each version of the printer.

  • Page 19: Psa-66-001N Netplex Printer

    This table below lists information on the bezel port. The bezel port is for driving a printer front action alert light built into the front bezel. Table 4-1 Front Bezel Port Pins FUNCTION Modulated +24VDC No connect Figure 4-1 PSA-66-001N Front Bezel Port UM-STO-C Revision C...

  • Page 20: Table 4-2 Front Bezel Port Pins

    Manual PSA-66-001N PSA-66-ST PSA-66-001N Netplex Version Base Port Connector: Molex 39-30-1100 Mate: Molex 39-01-2100 Table 4-2 Front Bezel Port Pins FUNCTION MRESET Netplex TX +13V Netplex RX +24VDC +24VDC Modulated +24VDC Figure 4-2 PSA-66-001N Base Printer Port UM-STO-C Revision C...

  • Page 21: Table 4-3 Netplex Printer Cable Pin Out

    PSA-66-001N Netplex Version Netplex Port Connector: Molex 39-01-2081 Mate: Molex 39-01-2080 Table 4-3 Netplex FUNCTION I/O* Printer Cable Pin Out MRESET Netplex TX +13V Netplex RX +24VDC BGND NO CONNECT Figure 4-3 PSA-66-001N Cable Connector Pin Out UM-STO-C Revision C...

  • Page 22: Psa-66-St Rs232 Printer

    Operators and Technicians Manual PSA-66-001N PSA-66-ST PSA-66-ST PSA-66-ST RS232 Printer RS232 Version Bezel Port Connector: Molex 39-01-4032 Mate: Molex 39-01-4030 The table below lists information on the bezel port. The bezel port is for driving a printer front action alert light built into the front bezel.

  • Page 23: Table 4-5 Rs232 Printer Base Port Pin Out

    Operators and Technicians Manual PSA-66-001N PSA-66-ST PSA-66-ST RS232 Version Base Port Connector: Molex 39-30-1400 Mate: Molex 39-01-2140 Table 4-5 RS232 Printer Base Port Pin Out FUNCTION MRESET Netplex TXD +12 VDC (RS232 optional) Netplex RXD +24 VDC +24 VDC Modulated +24VDC...

  • Page 24: Table 4-7 Rs232 Cable Port Pin Out

    Operators and Technicians Manual PSA-66-001N PSA-66-ST PSA-66-ST RS232 Version RS232 Cable Port Connector: Molex 39-01-2121 Mate: Molex 39-01-2120 Table 4-6 RS232 Cable Port Pin Out FUNCTION I/O* MRESET +12 VDC (optional) +24VDC +24VDC NO CONNECT NO CONNECT Figure 4-6 PSA-66-ST RS232 Unit RS232 Cable Pin Out...

  • Page 25: Table 4-8 Psa-66-St Rs232 10 Position Dip Switch Settings

    Operators and Technicians Manual PSA-66-001N PSA-66-ST PSA-66-ST RS232 Version The printer has a set of 10 dip switches which appear through an access slot on the bottom of the stationary module. The dip switches are used to select the communications protocol. The switches must be set according to the table below.

  • Page 26: Sensor Operation

    Operators and Technicians Manual PSA-66-001N PSA-66-ST 5 SENSOR OPERATION Paper Out Sensor The paper out sensor is located within the pivoting printer head module and is used to terminate the print operation when paper has run completely out, and for proper form registration. The PSA-66-ST will cease printing and feeding operations once a paper out condition is detected.

  • Page 27: Appendix A - General Specifications

    Operators and Technicians Manual PSA-66-001N PSA-66-ST 6 APPENDIX – General Specifications Table 6-1 General Specifications General Specifications PRINTER Dimensions 114mm width x 286mm depth x 68mm height* Weight 7 lbs Power requirements 24VDC @ 2.0A avg. (4.0A peak with 60% gaming ticket)
  • Page 28 Operators and Technicians Manual PSA-66-001N PSA-66-ST General Specifications PRINT MODES Printer languages TCL page description language Subset of ESCP2 printer language Page mode Full page mode printing (simultaneous 4 orientation printing: 0º, 90º, 180º, 270º) Line and box draw printer resident...

  • Page 29: Appendix B - Paper

    7 APPENDIX – PAPER Please contact your sales representative for more information on approved papers. Use Only Approved Paper in the PSA-66-ST and PSA-66-001N Printers. Use of improper paper may cause damage to the device and will void the printer’s warranty.

  • Page 30: Appendix C - Printer Part Numbers

    Operators and Technicians Manual PSA-66-001N PSA-66-ST 8 APPENDIX – PRINTER PART NUMBERS Table 8-1 Printer Order P/N’s DESCRIPTION PART NUMBER PRINTER, NETPLEX* PSA-66-001N PRINTER, RS232 PSA-66-ST PRINTER, TRAY, 200TKTS PSA-66-200-TRAY PRINTER, TRAY, 400TKTS PSA-66-400-TRAY PRINTER, TRAY, 600TKTS PSA-66-600-TRAY PRINTER, TRAY, 1000 TKTS...

  • Page 31: Appendix D - Spare Parts

    Operators and Technicians Manual PSA-66-001N PSA-66-ST 9 APPENDIX – SPARE PARTS For ordering spare parts, refer to the drawings and tables below. Table 9-1 Spares P/N' s Printer DESCRIPTION PART NUMBER STATIONARY UNIT, CHASSIS ONLY ASSEMBLY SPK-66-ST-01 SLIDING UNIT, CHASSIS ONLY ASSEMBLY...
  • Page 32 Operators and Technicians Manual PSA-66-001N PSA-66-ST Bezels DESCRIPTION PART NUMBER BEZEL ASSEMBLY 17” UPRIGHT PSA-66-ST-652241 BEZEL SLANT (BEZEL ONLY) PSA-66-ST-646021 BEZEL ASSEMBLY SLANT PSA-66-ST-646023 BEZEL VISION UPRIGHT & SLANT (BEZEL ONLY) PSA-66-ST-581405 BRACKET, BEZEL, 17” UPRIGHT PSA-66-ST-626289 BRACKET, LED, VISION UPRIGHT...
  • Page 33 Operators and Technicians Manual PSA-66-001N PSA-66-ST UM-STO-C Revision C...
  • Page 34 Operators and Technicians Manual PSA-66-001N PSA-66-ST " " ! "#" "#&"' &( ! "#" UM-STO-C Revision C...
  • Page 35 Operators and Technicians Manual PSA-66-001N PSA-66-ST UM-STO-C Revision C...

  • Page 36: Appendix E - Bezels

    Operators and Technicians Manual PSA-66-001N PSA-66-ST 10 APPENDIX – BEZELS The bezel systems shown in this section are designed to bolt to the 4 M3 holes on the front chassis plate of the printer and their descriptions given below. PRIGHT...
  • Page 37 Operators and Technicians Manual PSA-66-001N PSA-66-ST PSA-66-ST-646021 S LANT AND EZEL PSA-66-ST-646023 S LANT EZEL UM-STO-C Revision C...
  • Page 38 Operators and Technicians Manual PSA-66-001N PSA-66-ST PSA-66-ST-581405 U PRIGHT AND LANT UIDE EZEL PSA-66-ST-626289 U PRIGHT EZEL RACKET UM-STO-C Revision C...
  • Page 39 Operators and Technicians Manual PSA-66-001N PSA-66-ST PSA-66-ST-626292 U PRIGHT RACKET PSA-66-ST-751226 U LED B PRIGHT OARD UM-STO-C Revision C...
  • Page 40 Operators and Technicians Manual PSA-66-001N PSA-66-ST ACKNOWLEDGEMENTS Netplex is a proprietary hardware interface and protocol which is the property of International Game Technology Corporation. TCL Printer Language is a proprietary copyrighted language which is the property of Futurelogic, Inc. UM-STO-C Revision C...
