The Specification of PV722i
1. SCOPE
This specification defines the design and performance requirements for the 17" SXGA TFT LCD display
monitor."PV722i "
There are 3 models of " PV722i" in each own's project code.
Project Code: The common features of the 3 models of "PV722i" are listed in the following table:
Feature Description
1 Universal input AC/DC Adaptor
2 Digital Visual interface (DVI-D) TMDS 1 Ch 165MHz
3 Analog RGB interface (VGA ) 30~80KHz, 59~75Hz, 135MHz
4 17" SXGA 1280*1024 multi-view-angle (MVA), TFT LCD panel
5
Function keys * 6 : Power On/Off, ESC, △ (up), ▽ (down), (enter),signal source
Direct Acess function keys : △ for
6
7 Green/Amber LED indicator for power on/power saving
8 Plug & play support with DDC2B protocol installed.
9 Power saving mode compliant with Energy Star
10 OSD (on screen display) MENU operation
10.1 Brightness adjustment
10.2 Contrast adjustment
10.3 Auto tune function (VGA)
10.4 Color selection
10.5 Image adjustment
10.6 Position adjustment
10.7 Language selection
10.8 Reset function
10.9 Source selection (DVI/VGA)
11 OSD information of input status
12 Panel Rotation function for Portrait Graphic Application
The differential features of the 3 models of PV722i are listed in the following table
Feature
ISO 13406-2 View Direction Class
Audio Modual (speaker*2,Stero earphone jack)
Direct "ESC" key for Audio mute
Volume Adjustment(OSD)
2. INPUT REQUIREMENTS
2.1 Input Power
2.1.1. Power Source
2.1.2. Power Consumption
contrast function, ▽ for
Model
Project (ISO13406-2
LKC17SS2CC
Pixel Faults Class
110 Vac, 240 Vac, + -10%, 50/60 Hz (48W,2.5ψ plug)
1.PV722I model with Audio (LKC17SS2CC01)
Normal operating mode
Power saving mode
a. Audio module is operating at full power(max)
b. Audio module is operating at no signal input (max) : ≦ 5W
Power switch off
-3-
brightness function
PV722i PV722i
(ISO13406-2
Class Ⅱ ) Class Ⅱ , 0 pixel Fault)
LKC17SS0CC
Ⅱ Ⅱ
Ⅱ Ⅰ
No No
No No
No No
: ≦ 43W
: ≦ 3W (PC off)
Service Manual
PV722i/PV722E
PV722i
(ISO13406-2
Class Ⅱ + Audio)
LKC17SS2CC01
Ⅱ
Ⅱ
Yes
Yes
Yes
: ≦ 9W
