Table of Contents
Precautions ................................................................................... 2
About the Product ......................................................................... 3
Package Overview ....................................................................... 4
Product Overview ......................................................................... 5
Start Your Installation .................................................................... 7
Front Bezel Controls ..................................................................... 10
How to Use the OSD Menus ........................................................ 12
On-Screen Display Menus ........................................................... 13
Troubleshooting ............................................................................ 16
Product Dimensions ..................................................................... 17
Compatibility Modes ..................................................................... 18
Pivot Function (Optional) .............................................................. 19
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CTX PV511
Summary of Contents for CTX PV511
-
Page 1: Table Of Contents
English Table of Contents Usage Notice Precautions ... 2 Introduction About the Product ... 3 Package Overview ... 4 Installation Product Overview ... 5 Start Your Installation ... 7 User Controls Front Bezel Controls ... 10 How to Use the OSD Menus ... 12 On-Screen Display Menus ... -
Page 2: Usage Notice
English Usage Notice To prevent the risk of fire or shock hazards, do not Warning- expose this product to rain or moisture. Please do not open or disassemble the product as this Warning- may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recom- mended in this user’s manual to maximize the life of your unit. -
Page 3: Introduction
Introduction About the Product Having a 15.1” inch flat panel screen with an active, thin-film transistor (TFT) liquid crystal display (LCD) , this product also demon- strates following outstanding features. Direct analog RGB input 15.1” diagonal screen size 16.7 million displayable colors 1024 x 768 resolution XGA/ SVGA/ VGA/ VESA/ Mac/ NEC PC-98 compatible 24~60kHz horizontal scan... -
Page 4: Package Overview
English Package Overview Power Adapter LCD Display Power Cord VGA Signal Cable USB Upstream Cable Warranty Card User’s Manual Installation Diskette Pivot ® Software Mac Mutliform NEC PC-98 ( for DDC1/2B) (optional) Adapter (optional) Adapter (optional) -
Page 5: Installation
Installation Product Overview Main Unit Stand Rear View LCD Display User Controls Power Cable Management Device English... -
Page 6: Connection Ports
English Connection Ports Display Rear Connectors Display Input-B Display Input-A DC Power-In Display Stand Back USB Hub Ports 4 USB Downstream Ports USB Upstream Port... -
Page 7: Start Your Installation
Start Your Installation Connecting the Display To setup this display, please refer to the following figure and procedures. 1. Be sure all equipment is off. 2. Connect the VGA signal cable from display input-A or display input-B connector to the 15-pin connector of your host computer and tighten the screws. - Page 8 English USB Hub Port Descriptions USB Downstream Ports These four USB ports are available for connecting USB type peripheral devices such as keyboard, mouse, printer and so on. USB Upstream Port This Port is for connecting the USB Upstream cable to computer’s or other hub’s USB port.
- Page 9 Cable Management 1. Route the cables through the cable management device. 2. Connect the cables to their respective connectors on the back panel of the display. Cable Management Device English...
-
Page 10: User Controls
English User Controls Front Bezel Controls No./ Icon Control MENU Menu button SELECT/AUTO Select/Auto Brightness Minus/Minus 1. Decreases the brightness of Brightness Plus/Plus Function To pop up the OSD menus. Select - To select the adjust- ment items from OSD menus. Auto - To activate the “Auto Adjustment”... - Page 11 Power Switch Power LED Switches on/off the power of the LCD display. 1. Green indicates the display is turned on. 2. Amber indicates the display in power-saving mode. English...
-
Page 12: How To Use The Osd Menus
English How to Use the OSD Menus 1. Press the “Menu” button to pop up the on-screen menu and to select be- tween three Main Menus. 2. Choose the adjustment items by pressing the “Select/Auto” button. 3. Adjust the value of the adjustment items by pressing the “ ” or “ ” button. -
Page 13: On-Screen Display Menus
English On-Screen Display Menus First OSD Menu: Main Menu Page 1 Contrast Adjusts the contrast of the display image. Re-Scaling When the input resolution is less than 1024 x 768, the “re-scaling” allows user to choose the “original resolution”, “1:1 re-scaling” or “full screen” image. -
Page 14: Horizontal Position
English Second OSD Menu: Horizontal Position Changes the horizontal position of the image. Vertical Position Changes the vertical position of the image. Frequency Changes the display data frequency to match the frequency of your graphic card. When you are experiencing vertical flickering bar, use this function to make an adjustment. -
Page 15: Display Mode
Third OSD Menu: Display Mode Shows the display resolution, vertical refresh, and horizontal scan of the current mode. OSD Off-Time Adjusts the time period for the OSD menus to disappear. Language Chooses the language you need. There are English, French, German, Spanish, and Italian for your choices. -
Page 16: Appendices Troubleshooting
English Appendices Troubleshooting If you are experiencing trouble with the LCD display, refer to the follows. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. Check that all the I/O and power connectors are correctly and well connected as described in the “... -
Page 17: Product Dimensions
English Product Dimensions 395mm/15.5” 407.7mm/16” Front View 235mm/9.2” Side View 77mm/3” Top View... -
Page 18: Compatibility Modes
English Compatibility Modes Mode I BM & VES A VG A I BM & VES A VG A I BM & VES A VG A I BM & VES A VG A I BM & VES A VG A I BM & VES A VG A VES A S VG A VES A S VG A VES A S VG A... -
Page 19: Pivot Function (Optional)
English Pivot Function (Optional) Mechanically, the monitor can be rotated 90 degrees from a landscape state to a portrait state. You need to buy a pivot software to enable your display image to also have 90 degrees rotation. To Use the Pivot Function: ®...
