  • Page 1 PV510 User’s Manual U s e r ’ s M a n u a l P V 5 1 0...

  • Page 2: Table Of Contents

    PV510 User’s Manual Table of Contents 1. Important Safety Instructions 2. Introduction 3. Recommended Use of the Monitor 4. Controls and Adjustments 5. Energy Declaration 6. Trouble Shooting 7. Technical Information 8. Product Overview Specifications...

  • Page 3: Important Safety Instructions

    Important Safety Instructions FCC Statement his equipment has been tested to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 4 The main problem, as far as computers and other electronics equipment are concerned, is that environmentally harmful substances are used both in the products and during their manufacture. Since it is not so far possible to satisfactorily recycle the majority of electronics equipment, most of these potentially damaging substances sooner or later enter nature.
  • Page 5 Flame retardants are present in printed circuit boards, cables, wires, casings and housings. There purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances.

  • Page 6: Safety Precautions

    This manual should be retained for future reference. 1. To clean the LCD Monitor screen make sure the Monitor is in the power off mode. Unplug the Monitor from its power source before cleaning it. Stand away from the LCD Monitor and spray cleaning solution onto a rag.
  • Page 7 Servicing of any nature should only be performed by an authorised technician. 6. Safe storage of the LCD Monitor is in a range of minus 20 to plus 65 degrees Celsius. Storing your LCD Monitor outside this range could result in permanent damage.

  • Page 8: Introduction

    PV510 User’s Manual Introduction Product Description ongratulations on purchasing this new generation monitor. Your LCD monitor incorporates high quality display into a small lightweight module. It has power- saving capabilities and emits no X-ray radiation. he features are: • 15" TFT Liquid Crystal Display •...

  • Page 9: Package Overview

    User's Guide / Driver CD Power Cord Power Adapter VGA Signal Cable CAUTION Keep the shipping carton in case the need arises to store or transport the unit. Let the LCD lie on its face when you put it into the carton.
  • Page 10 PV510 User’s Manual Installation & Remove 1-1. Installing the Portrait...
  • Page 11 PV510 User’s Manual 1-2. Remove the Portrait...
  • Page 12 PV510 User’s Manual 2-1. Installing the Wall Mount Adapter*...
  • Page 13 PV510 User’s Manual 2-2. Remove the Wall Mount Adapter* * The Wall Mount Adapter is a optional item.

  • Page 14: Recommended Use Of The Monitor

    Use the type of power indicated on the marking label. Plugs Do not remove any of the prongs of the monitor's three-pronged power plug. Disconnect the power plug from the AC outlet if you are not going to use it for an indefinite period of time. Power cords Use the proper power cord with correct attachment plug type.
  • Page 15 PV510 User’s Manual Do not allow anything to rest on the power cord. Do not locate this product where persons will walk on the cord. Environment Place the monitor on a flat level surface. Place the monitor in a well-ventilated place.

  • Page 16: Controls And Adjustments

    Controls and Adjustments nce you have installed this monitor with your system, please read the instructions in this section, they give you some guidelines on how to use the monitor more efficiently. And lead you through the various functions of the user controls and explain how to adjust the monitor to your personal preference.
  • Page 17 " to confirm your selected function. Brightness Press the " " button to enter the brightness, and press the " " or " " button to increase or decrease the brightness level, then press " ESC" button to exit. Contrast Press the "...
  • Page 18 ADVANCE AUTO TUNE PATTERN PROGRAM USING GUIDE • As some VGA Card doesn't match the VESA standard. It can't out-put 0.7 V p-p VESA standard. Therefore, we need "ADVANCE AUTO TUNE PATTERN PROGRAM" to modify the parameters of monitor to match different output level of VGA card.
  • Page 19 User Mode • Press " " button to enter User mode. • Press the " " or " " button to select the R/G/B gain, then press " " button to proceed. • Finally, press "ESC" button to leave this function.
  • Page 20 PV510 User’s Manual • Size: Press the " " or " " button to adjust the width of the screen to a maximum. • Phase: Press the " " or " " button to reduce the noise on the screen.
  • Page 21 PV510 User’s Manual Image Position or OSD Position • H - Position: Press the " " or " " button to reposition of the picture or the OSD window to the right or left. • V - Position: Press the" " button to moves the picture or the OSD window upwards and "...

  • Page 22: Energy Declaration

    803299/94/96. The time settings for switching to a power saving mode are adjusted from the system unit by software. From the first indication of inactivity to power saving position A2 the total time must not be set to more than 70 minutes.

  • Page 23: Trouble Shooting

    PV510 User’s Manual Trouble Shooting f you are experiencing trouble with the LCD display refer to the following. If the problem persists please contact your local dealer or our service center. Check if the monitor is turned on. The monitor does not...
  • Page 24 "Unsupported Mode " message. No Signal Input The "No Signal Input" message indicates that the cable may not be plugged property into the host system. WARNING: Do not disassemble the monitor. Contact your dealer if needed.

  • Page 25: Technical Information

    Compatibility his LCD monitor supports multiple operating platforms such as IBM compatible computers. This section provides you with detailed information on pin assignment of the D-Sub connector and the preset timing chart of the prevailing video standards. Pin Assignments Male Mini D-15 Connector...

  • Page 26: Video Modes

    PV510 User’s Manual Video Modes Horizontal Refresh Resolution VCLK(MHz) Frequency Rate Standard (KHz) (Hz) 640*350 25.175 31.470 70.000 IBM VGA 720*400 28.322 31.469 70.000 IBM VGA 640*480 25.175 31.470 59.940 IBM VGA 640*480 30.240 37.861 72.000 VESA 640*480 31.500 37.500 75.000...

  • Page 27: Product Overview

    PV510 User’s Manual Product Overview Pivot Function You can turn the LCD panel right 90 degree for particular viewing. Front View (unit: mm)
  • Page 28 PV510 User’s Manual Side View (unit: mm) For viewing clarity, you can tilt the LCD panel forward (up to 5 degrees) or backward (up to 20 degrees) Rear View (unit: mm)

  • Page 29: Specifications

    Auto-Tune, Brightness, Contrast, Color, Quality, Position, Language, Recall Sub-menu Size, Phase, Focus, Dither, Text/Graphics, Image Position, OSD Position Analog 0.7V peak to peak separate TTL Positive or Input signal Negative Power Supply 100~240 VAC, 50/60 Hz (automatically) Plug & Play VESA DDC 1/2B [ Dimension &...
  • Page 30 PV510 User’s Manual [ Operating Environment ] Temperature 5°C ~ 35°C Humidity 20% ~ 80% (non-condensing) Altitude 10,000ft [ Storage Environment ] Temperature -20°C ~ 60°C Humidity 10% ~ 90% (non-condensing) Altitude 40,000ft Note: Specifications are subject to change without notice...
