Service Manual
PV722i /PV722E

12. PARTS LIST

ITEM PART NUMBER
1 AC1720-D01
2 DC1720-A03
3 EC1720-A01
4 TC1720-D01
5 10A17-0C0A
6 0800055367
7 0820094311
8 SSBASE-418
9 SZADPT-030P SUB-Z ASSY ADAPTER 48W(For PV722i)
10 SZADPT-101B SUB-Z ASSY ADAPTER 60W(For PV722E)
11 0400739300
12 0510148800
13 0510149800
14 0670455000
15 0670456000
16 0670349500
17 0670452600
18 05Z0001900
19 05Z0002900
20 AS00AV-009
21 AS0USB-001
DESCRIPTION
MAIN PCBA
POWER PCBA
INTERFACE A/V PCBA 17 INCH
INVERTER PCBA(CMO)
LCD TFT 1280*1024(M170E4-L02)
CABINET BACK
CABINET FRONT
SUB ASSY BASE
CARTON 553*260*580
HOLDER (R)
HOLDER (L)
LABEL CARTON (For PV722i)
LABEL CARTON (For PV722i)
LABEL CARTON (For PV722E)
LABEL CARTON (For PV722E)
PLASTIC HANDLE BAR
PLASTIC CLAP BOARD
SMART MEDIUM
PV722E)
ACCESSORIES USB MODEL (FOR PV722E)
-38-
