Service Manual
PV722i /PV722E

3.8 Power Management

This monitor will meet the low power specification, Including USA governmental requirements
for Energy Star, the NUTEK standard and the VESA DPMS standard which detected the Hori. /Vert.
sync signal from host CPU.
A dual color (green/amber) LED is located on the front bezel to indicate the power management states.
Sync
On 57W max. (LKC17SS2CC03)
Off
Once "Esc" or "△ " or "▽ " key initiates under power saving condition, the audio function can be
woken up
and the power consumption can not be the above definition.
Note1 : USB Hub under power saving mode (or all ports aren't connected to any device), audio
module is
operating at no audio signal input.
Power consumption
≦ 4W (Note 1)
Power management Picture Recovery time
ON
Off
-22-
C T X
C T X
C T X
LED Color
- Green
Amber
≦ 3 sec
