PR711FL User's Manual
U s e r ' s
M a n u a l
P R 7 1 1 F L
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Monitor PR711FL and is the answer not in the manual?

Questions and answers

Related Manuals for CTX Monitor PR711FL

Summary of Contents for CTX Monitor PR711FL

  • Page 1 PR711FL User’s Manual U s e r ’ s M a n u a l P R 7 1 1 F L...

  • Page 2: Table Of Contents

    PR711FL User’s Manual Table of Contents 1. Safety Instructions 3 2. Recommendation for Optimum Performance 3. Introduction 4. Installation 5. Controls and Adjustments 6. Trouble Shooting 7. Energy Declaration 8. Specification 9. Reference Information...

  • Page 3: Safety Instructions

    Safety Instructions FCC Statement his equipment has been tested to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 4 2. Do not place the monitor or other heavy objects on the power cord. A damaged power cord can cause fires or electrical shock. 3. Keep the monitor away from high-capacity transformers, electric motors and other strong magnetic fields. 4. Do not connect to any voltage or frequency beyond the range specified on the back of the monitor.

  • Page 5: Recommendation For Optimum Performance

    Recommendation for Optimum Performance our monitor will provide the best results if you follow these recommendations: 1. Do not use your monitor against a bright background or where sunlight or other light sources will shine directly on the screen. 2. Place the monitor just below eye level (10° -15°) for optimum viewing. 3.

  • Page 6: Introduction

    Introduction he monitor is a multiple frequency high-resolution color monitor for IBM compatible PC's or Macintosh and workstation systems. The monitor is equipped with microprocessor based intelligence and multiple frequency scanning capability, allowing it to provide maximum compatibility for various system platforms. he monitor uses the latest screen technology including a 0.24mm AG FD Trinitron®...

  • Page 7: Installation

    Installation Unpacking our color monitor package should contain the following items: Color monitor with tilt/swivel base (with Signal cable) Power cord User's Guide / Driver CD System Setup 1. Turn off the system and all attached peripherals. 2. Carefully turn the monitor upside down. PR711FL User’s Manual...
  • Page 8 PR711FL User’s Manual Remove the Tilt/Swivel Base 1. Squeeze and hold the latches. 2. Pull the tilt/swivel base to the rear of the monitor and lift to remove the base. Installing the Tilt/Swivel Base 1. Align the base with the slots on the bottom of the monitor and insert the tilt/swivel base into the slots.

  • Page 9: Controls And Adjustments

    PR711FL User’s Manual Controls and Adjustments nce installation is complete, refer to this section for useful tips on how to use your monitor controls and make adjustments to match your personal preferences. The following indicators, controls and adjustments, including On-Screen Displays (OSD), are accessible from the front of your monitor: Front Panel Controls 1.
  • Page 10 PR711FL User’s Manual 4. Up " " button To adjust the selected OSD function or the contrast directly. 5. Down " " button To adjust the selected OSD function or the brightness directly. 6. "ESC" button To close the OSD manual and to escape function. How to Make On-Screen Display (OSD) Adjustments n-Screen Displays are called up from the front panel controls as noted above.
  • Page 11 PR711FL User’s Manual A. Status To display existing timing data of resolution and frequency. B. Picture a. Press " " or " " to select Vertical and Horizontal position, Vertical and Horizontal size. b. Press " " to process. c. Press " " or " " to preferred picture. C.
  • Page 12 PR711FL User’s Manual D. Color a. Press " " or " " to select various white color temperature standard. b. In User item, presses " " to confirm action color adjustment. c. Press " " or " " to select Red, Green and Blue then press "Enter"...
  • Page 13 PR711FL User’s Manual E-2. Converage a. Press " " or " " to select Horizontal or Vertical convergence adjustment. b. Press " " to proceed. Caution: 1. If moire reduction is overdone, picture quality, i.e. focus and vertical line stability will both be effected.
  • Page 14 PR711FL User’s Manual Confirm the Recall action by pressing the " " or cancel the action by pressing the "ESC". G. Language Press " " or " " to select the Language for OSD only. (2) Contrast/Brightness: When OSD is off, " " or " " will be adjust contrast or brightness.

  • Page 15: Trouble Shooting

    Trouble Shooting otify your supervisor or contact your service personal when: • Power cords are frayed or damaged. • Liquid is spilled into the monitor. • The monitor does not operate normally when operating instructions are observed. • The monitor has been dropped or the cabinet has been damaged. eview this list of trouble-shooting tips before contacting an authorized service center.
  • Page 16 Signal Out of range. Display image is not centered or is too small or too large. Image is scrolling or is unstable Picture is fuzzy or color looks blotchy. Picture bounces or a wave pattern is present. PR711FL User’s Manual Readjust the signal based on spec.
  • Page 17 Edges of display are curved inward or outward. No Plug & Play. ur monitor is build-in FD Trinitron® CRT. This CRT is sensitive to shocks and vibrations that may occur during transportation. Following are some adjustment tips when below mentioned symptoms occur.
  • Page 18 Black fine vertical lines are visible on the screen. Shock and vibration may cause the aperture grille misaligned, which results few fine black vertical lines across the screen PR711FL User’s Manual Degaussing the screen. Tap lightly (do not hit) the side of the monitor. If above mentioned remedies do not work, please do the following: 1.Display full white window or wallpaper...

  • Page 19: Energy Declaration

    Energy Declaration his monitor is equipped with a function for saving energy, which supports the VESA Display Power Management Signaling (DPMS) standard. This means that the monitor must be connected to a computer, which also supports the VESA DPMS standard to fulfill the requirements of the NUTEK specification 803299/94/96.

  • Page 20: Specification

    Specification Color Picture Tube AG Pitch Input Signal Scan Frequency Max. Resolution Display Colors Pixel Rate Plug & Play Power Supply Power Consumption Dimensions Weight Environment Consideration Note: Specifications are subject to change without notice. PR711FL User’s Manual 43.1 cm / 17" (16" viewable screen size) diagonal measurement, 90 degree deflection, FD Trinitron®...

  • Page 21: Reference Information

    Reference Information his color monitor supports multiple operating platforms such as IBM compatible and Macintosh family computers. This section provides you with detailed information on pin assignment of the D-Sub connector and the preset timing chart of the prevailing video standards.

  • Page 22: Preset Timing Chart

    Preset Timing Chart Note: This monitor is equipped with a microprocessor which allows the user to set his own preferred mode(s) beyond those standard mode listed below. To reduce visual tiredness and eyestrain, it is recommended to choose the highest refresh modes available.
