Installation

Before you connect the probe to your instrument, read the following Operating considerations and Overview sections to
understand the operating characteristics and sequence of events necessary to properly install the probe and adapters.
CAUTION: To avoid ESD damage to the probe, always use an antistatic wrist strap (provided with your probe), and
work at a static-approved workstation when you handle the probe.

Operating considerations

Table 1: P7700 Series TriMode probes

Characteristic
Input Voltage
Temperature
Humidity
Altitude
Pollution Degree
P7700 Series TriMode™ Probes
Description Specification
TekFlex solder-in tips
Dynamic range 2.5 Vpp (single-ended)
5.0 Vpp (differential
input)
Operating voltage ±5.25 V
window
Offset voltage range -4 V to +4 V
Maximum non- -15 V to +15 V (tip attached or detached)
destructive input voltage
Operating Probe compensation box: 0 °C to 45 °C (32 °F to 113 °F)
Probe cable, solder tips, and P77292MM adapter: -35 °C to 85 °C (-31 °F to
185 °F); Minimum Airflow required 46°C to 85°C (114.8 °F to 185 °F)
Non-operating Probe compensation box: -20 °C to 60 °Cg (-4 °F to 140 °F)
Probe cable, solder tips, and P77292MM adapter: -35 °C to 85 °C (-31 °F to
185 °F)
Operating Probe Compensation Box, Cable, Tips, and SMA adapter: 20% to 80%
Relative Humidity (%RH) at up to 45°C non-condensing
Non-operating Probe Compensation Box, Cable, Tips, and P77292MM adapter: 10% to
90% (Relative Humidity), non-condensing
Non-operating Probe Compensation Box, Cable, Tips, and SMA adapter: 12,000 meters
(39,370 feet)
2, Indoor use only
P77BRWSR P77C292MM adapter
6.0 Vpp (single-ended) 1.2 Vpp (single-ended)
12.0 Vpp (differential 2.0 Vpp (differential
input) input)
±10.0 V ±4.0 V
-10 V to +10 V -4 V to +4 V
-5 V to +5 V
