Configuring the Program

SAVING OPTIONS

Once an image is imported, it can be saved to a file or to the clipboard. Images can be
saved in two ways:
Manual save: The image is saved to the hard disk or to the clipboard as soon as the user
clicks on the Save button or immediately after the scanning, depending on user settings.
Automatic save: The image is saved to the hard disk in a predefined directory. Saving can
be performed as soon as scanning is complete, or when the next card scanning starts.

IMAGE MANUAL SAVE

The scanned image can be saved manually either to a file on the hard disk, or to the
clipboard. You select the file destination as follows:
Save to clipboard: To save the scanned image to the clipboard, check the 'Save to
clipboard' checkbox (See Figure 2 page 14).
Note that the Save button in the main screen now displays a clipboard icon.
Save to file: To save the scanned image to a file, check the 'Save to file' checkbox (See
Figure 2 page 14).
Note that the Save button in the main screen now displays a diskette icon.
Scan scheme: Select the desired saving scheme (single side, double side or two sides on the
same image. If the later is selected, you can specify the image layout by clicking on the
orientation button (Side A above B or B above A).
Default save type: Once
which the file will be saved, by using the
seven image file formats: BMP, JPG, PCX, PNG, TIFF, TGA, PSD.

IMAGE AUTO SAVE

Image auto save is particularly useful for large batch scanning jobs. This option enables
chain-feeding the scanner while image saving is done automatically without user
interference.
Scan scheme: Select the desired saving scheme (single side, double sided, or two sides on
the same image. If the later is selected, you can specify the image layout by clicking on the
orientation button (Side A above B or B above A).
Save immediately after scan - Checking the checkbox titled 'Save immediately after scan'
will save the image and data immediately after the scan is done.
If the 'Save immediately after scan' checkbox is unchecked, the saving will occur on the
next scan job (in the automatic saving option) or when the user clicks on the Save button (in
the manual saving option).
Once the 'Auto save' checkbox is checked, the 'File naming and type' button is enabled,
and clicking on it opens the 'AutoSave file naming' configuration dialog:
IdScan User Manual version 9.0
is selected, you can set the default file format in
Save to File
Default save type
©
Card Scanning Solutions, all rights reserved
Automation tab
dropdown list. idScan supports
58
