CSSN MagShell 900 Specifications

MagShell 900
Manual swipe, bi-directional magnetic reader, conforms to ISO
7810, 7811, AAMVA, JIS & DMV format, All ISO tracks supported.
Communicates with a host computer or other terminal via a
standard Universal Serial Bus (USB) interface
Features
Buzzer and LED indicator
Read and convert RS232 magnetic data
Bi-Directional
All ISO tracks supported
(USB) interface, no external power required
Fully portable
Small footprint
Technical specifications
Interface
Scanner Weight
Dimensions (LxWxH)
Power consumption
Operating Voltage
Certifications
ISO
Electrical
Power +5VDC ± 10% from USB port
Consumption 98mA max. in normal
condition
Communication Standard RS232 to USB
Mechanical
Body material ABS 04V-0
Dimension 3.94"/100mm L x 1.1"/28mm
H x 1.33"/34mm W
Weight 20 oz / 210gr.
Connection USB series "A" plugs
Handling Manual, swipe, bi-directional
Method
© 2005 All rights reserved to CSSN card scanning solutions
USB Full Speed (1.1)
20 oz / 210gr.
3.94"/100mm L x 1.1"/28mm H x 1.33"/34mm W
USB powered ( 2.0 W @ 5Vdc)
+5VDC +/- 10%, 110mA max
CE, FCC, UL, cUL
ISO track 1, 2 and 3, 7810, 7811, AAMVA, JIS & DMV format
Performance
Read card
Coercive force
Read speed
Read error
rate
Environment
Operation
Storage
Agency
approval
(1)
ISO 7810, 7811/1-6/AAMVA, custom data
Read 300-4000, Ce Magnetic Card
STD card Jitter ± 15%
5-55 ps 5-50 ps
<0.5%
0
-10 to 55 C, 10 to 90% Humidity
0
-30 to 70 C, 10 to 90% Humidity
FCC/CE class A UL, cUL
Amp 60%
5-50 ps
