OW N E R 'S M A N U A L
WARNI NG:
I f the information in this manual is not follow ed exactly, a
fire or explosion may result causing property damage, personal injury
or loss of life. Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
C# 4001609
CERTI FI ED TO/ CERTI FI É AUX: ANSI Z21.88 / CSA2.33 / CSA 2.17
50-3737
Version Française: www.enviro.com/fr.html

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Westley and is the answer not in the manual?

Questions and answers

Related Manuals for Enviro Westley

Summary of Contents for Enviro Westley

  • Page 1 Installation and service must be performed by a qualified installer, service agency or the gas supplier. C# 4001609 CERTI FI ED TO/ CERTI FI É AUX: ANSI Z21.88 / CSA2.33 / CSA 2.17 50-3737 Version Française: www.enviro.com/fr.html...

  • Page 2: Safety Precautions

    Safety Precautions WARNI NG: FI RE OR EXPLOSI ON HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - WHAT TO DO I F YOU SMELL GAS •...
  • Page 3 • Do not abuse the glass by striking it or slamming the door NEVER ALLOW CHILDREN shut. TO TOUCH GLASS. If the Westley unit is pulled out of its installation, and • A barrier designed to reduce the risk of burns from the the vent-air intake system is disconnected for any reason,...

  • Page 4: Table Of Contents

    Table of Contents Safety Precautions......................2 Table of Contents......................4 Codes And Approvals....................5 Specifications......................6 Dimensions.....................6 Rating Label Location..................6 Operating I nstructions....................7 Lighting I nstructions..................7 Air Shutter......................8 Normal Sounds During Operation................8 Tr an sm i t t er................. 9 Initializing the System for the First Time.............11 Switching to Continuous Pilot ................11...

  • Page 5: Codes And Approvals

    After the unit has gone through the first burn, turn the unit off including the pilot, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local ENVIRO dealer.

  • Page 6: Specifications

    25 15/16" [40.5 cm] [65.9 cm] 27 1/2" [69.9 cm] 19 9/16" [49.7 cm] Figure 1. Westley Dimensions & L ating abeL ighting nstRuctions ocation The rating label and lighting instructions are located on a plate hanging on the back of of the unit.

  • Page 7: Operating Instructions

    Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNI NG: I F YOU DO NOT FOLLOW THESE I NSTRUCTI ONS EXACTLY A FI RE OR EXPLOSI ON MAY RESULT, CAUSI NG PROPERTY DAMAGE, PERSONAL I NJURY OF LOSS OF LI FE. ighting anD uRning nstRuctions...

  • Page 8: Air Shutter

    Proflame 2 is a modular remote control system that directs the functions of the Westley. The Proflame 2 TMFSLA is configured to control the on/off main burner operation, its flame levels and provides on/off and Smart thermostatic control of the appliance. The system also controls the fan speed through six (6)

  • Page 9: Tr An Sm I T T Er

    Operating Instructions ystem escRiption The Proflame 2 Remote Control System consists of two (2) elements: 1. Proflame 2 Transmitter. 2. Integrated Fireplace Controller (IFC) and a wiring harness to connect to the gas valve and stepper motor. ATTENTI ON! - TURN “OFF” THE MAI N GAS SUPPLY OF THE APPLI ANCE DURI NG I NSTALLATI ON OR MAI NTENANCE OF THE I FC.
  • Page 10 Operating Instructions Key Lock Transmission Low battery alarm Thermostat OFF/ Room ON/SMART Temperature CPI mode Set Point Aux ON Temperature/Level/State Flame ON Split Flow Dimmer ON Comfort fan Figure 5: Proflame 2 Transmitter LCD Screen. (ifc): ntegRateD iRepLace ontRoLLeR The Proflame 2 IFC (Figure 6) connects directly to the gas valve, stepper motor, pilot and covection fan with a wiring harness.

  • Page 11: Initializing The System For The First Time

    When the Westley is turned off press the mode key to index to the constant pilot (CPI) mode icon (see figure 8). Pressing the up arrow key will select Continuous Pilot Ignition (CPI) and pressing the down arrow key will return to IPI.

  • Page 12: Turn Off The Appliance

    Operating Instructions Turn off the Appliance Press the ON/ OFF Key on the Transmitter. The Transmitter LCD display will only show the room temperature and Icon (see Figure 8). A single “beep” from the IFC confirms reception of the command and both the pilot light (if the unit is not set to continuous pilot) and main burner will turn off.

  • Page 13: Fan Control

    Operating Instructions Split Flow Operation This function is not used on the Westley and can be disregarded. Figure 12: Split Flow Control (not used) Fan Control The Westley comes with a convection fan that can be controlled with the Transmitter. The fan speed can be adjusted thorugh six (6) speeds.

  • Page 14: Key Lock

    Operating Instructions Key lock This function will lock the keys to avoid unsupervised operation. To activate this function, press the Mode and UP keys at the same time and the a lock will appear (see Figure 16). To de-activate this function, press the Mode and UP Keys at the same time.

  • Page 15: Cleaning The Glass

    The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. Remove the door (see page 16). The replacement glass will come with a new gasket installed. Remove any silicone remnants from the door.

  • Page 16: Cast Door Removal

    Maintenance And Service emovaL The cast door on the Westley needs to be removed whenever access to the firebox is required. First the Westley must be turned Cast Top off and allowed to fully cool. Next, remove the Cast Top as shown in Figure 20 by simply lifting up.

  • Page 17: Burner Removal

    Maintenance And Service uRneR emovaL The burner may need to be removed for a few reasons, including cleaning under the burner, converting the unit to a different gas type, or to replace the burner altogether. Proceed only w hen the unit has completely cooled down.

  • Page 18: Fuel Conversion

    The installation is not proper or complete until the operation of the converted appliance is checked as specified in the manufacturer’s instructions supplied with the kit. Kit Parts List for all Westley models: 1- Steel Air Deflector (LP kits only 1 - Orifice (NG:...
  • Page 19 (page 42). Confirm the inlet and manifold pressures Figure 27. Correct Pilot are within the acceptable ranges as directed in section I ntIal I f the Westley has been installed at an altitude ntallatIon onnectIon anD estIng higher than 2000ft (610m) it is required to de-rate the unit accordingly: I n the USA: The appliance may be installed at higher altitudes.

  • Page 20: Initial Installation

    • Locate the stove in a large and open room that is centrally located in the house. This will optimize heat circulation and comfort. • As the Westley is equipped with a convection fan, ensure that an electrical outlet is within 6 ft (1.8 m) of the stove.

  • Page 21: Direct Vent

    The vent length for the Westley must be between 36” (91 cm) and 44ft (13.4 m). This model is vented with co-axial 4” intake, 6 5/8” exhaust aluminum or stainless steel approved rigid vent leading into a vertical or horizontal termination cap.
  • Page 22 Initial Installation QUALIFIED INSTALLERS ONLY WARNING: Do not mix parts from different vent manufacturers’ systems. EXCEPTION TO WARNING: This product has been evaluated by Intertek for using a DirectVent Pro starting collar in conjunction with other venting systems. Use of this system with the DirectVent Pro starting collar is deemed acceptable and does not affect the Intertek listing of the appliance.

  • Page 23: Vent Termination Restrictions

    Initial Installation QUALIFIED INSTALLERS ONLY eRmination estRictions Fixed Closed Fixed Openable Closed Openable Termination Cap Air Supply I nlet Restriction Zone Gas Meter (Termination not allowed) Figure 30. Vent Termination Restrictions, refer to Table 5. Table 5: Vent termination clearances. Description Letter Canadian I nstallation...

  • Page 24: Exhaust Restrictor Setting

    The Westley has an internal exhaust restrictor that can adjusted externally while the fireplace is in operation. Depending on the length of venting required for installation this may need to be adjusted. The restrictor is accessed from the front of the fireplace through the discharge opening as shown below (Figure 30).

  • Page 25: Horizontal Termination - Minimum Vent

    Refer to Table 6 and Figure 32 below for the minimum allowable venting setup for the Westley. Note, when installing at minimum vent length only the following horizontal terminations are approved for use: Table 6: Approved Minimum Vent Terminations...

  • Page 26: Allowable Vent Configurations

    Initial Installation QUALIFIED INSTALLERS ONLY LLowabLe onfiguRations The following charts show the range of venting options available using either vertical or horizontal terminations in conjunction with 0 - 3 90° elbows in the vertical plane. Any planned layout that remains within the shaded areas is acceptable.
  • Page 27 Initial Installation QUALIFIED INSTALLERS ONLY - 1 e oRizontaL eRmination Lbow Restrictor Setting #1 No Restriction (0) Propane [LP] INSTALLATION PROHIBITED Min. 3’ Section Required 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 HORIZONTAL RUN Figure 34: Horizontal Termination - 1 Elbow [LP]...
  • Page 28 Initial Installation QUALIFIED INSTALLERS ONLY & v (0 - 3 e oRizontaL eRticaL eRminations Lbows Natural Gas [NG] Restrictor Setting #3 INSTALLATION PROHIBITED Restrictor Setting #2 Restrictor Setting #1 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 HORIZONTAL RUN INSTALLATION Figure 35: Allowable Venting - [NG]...
  • Page 29 Initial Installation QUALIFIED INSTALLERS ONLY & v (0 - 3 e oRizontaL eRticaL eRminations Lbows Propane [LP] INSTALLATION PROHIBITED Restrictor Setting #2 Restrictor Setting #1 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 HORIZONTAL RUN INSTALLATION Figure 36: Allowable Venting - [LP]...

  • Page 30: Horizontal Termination

    Initial Installation QUALIFIED INSTALLERS ONLY oRizontaL eRmination NOTES: 1. Horizontal pipes must not be level. For every 12 inches (305 mm) of horizontal travel (away from the stove), there should be at least ¼ inch (6.4 mm) of vertical travel. Never allow the vent to run downward, as this could cause high temperatures or even present the possibility of a fire.

  • Page 31: Vertical Termination

    Initial Installation QUALIFIED INSTALLERS ONLY Step 4. With the hole now framed, the wall thimble installed, and the pipe extending into the wall, proceed to the outside. Attach the termination to the pipe using RTV and Mil-Pac or Rutland No 78 Stove and Gasket Cement to seal joints.
  • Page 32 Initial Installation QUALIFIED INSTALLERS ONLY STEP 5. Cut hole in the roof centered on the small hole placed in the roof from Step 2. The hole should be of sufficient size to meet minimum requirements for Clearance to Combustibles, as specified. Continue to assemble lengths of pipe and elbows necessary to reach from the ceiling support box up through the roof line.
  • Page 33 Initial Installation QUALIFIED INSTALLERS ONLY NOTES: (1) If an offset is necessary in the attic to avoid obstructions, it is important to support the vent pipe every 3 feet (914 mm), to avoid excessive stress on the elbows, and possible separation. Wall straps are available for this purpose (see Figure 40).

  • Page 34: B-Vent Drafthood Adaptor (50-3667)

    RafthooD DaptoR This Drafthood Adaptor is a complete assembly and is ready to fit onto the Westley in a vertical vent application only. With the Drafthood Adaptor correctly installed and wired to the IFC the Westley may be vented like a B-Vent Fireplace.
  • Page 35 Initial Installation QUALIFIED INSTALLERS ONLY DRAFTHOOD WI RI NG: In order to connect the Drafthood Adaptor to the IFC the spill switch wires must first be modified as instructed below. Step 1: Cut off the connectors from the one end of the wires.
  • Page 36 Initial Installation GENERAL VENTI NG I NFORMATI ON: Canadian I nstallations The venting system must be installed in accordance with the current CSA B149.1 installation code and/or local codes having jurisdiction. U.S.A. I nstallations The venting system must be installed in accordance with the current National Fuel Gas Code, ANSI Z223.1/ NFPA 54, and/or local codes having jurisdiction.
  • Page 37 Initial Installation AUTOMATI C SAFETY SHUT DOWN: If the spill switch is activated and shuts off the fireplace the following procedure should be followed. • Turn off all controls and let the fireplace cool down. • Check for blockages or restrictions in the flue and venting components. •...

  • Page 38: Gas Line Connection And Testing

    Initial Installation QUALIFIED INSTALLERS ONLY onnection anD esting WARNI NG: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. GAS LI NE CONNECTI ON • This stove is equipped with a certified flexible pipe located on the left side of the unit terminating in a 3/8”...

  • Page 39: Electrical Requirements

    Initial Installation QUALIFIED INSTALLERS ONLY LectRicaL equiRements The fireplace must be electrically connected and grounded in accordance with local codes or, in the absence of local codes, with the current CSA C22.1 Canadian Electrical Code Part 1, Safety Standards For Electrical I nstallations, or The National Electrical Code ANSI / NFPA 70 in the US.

  • Page 40: Secondary Installation

    Secondary Installation nstaLLation The placement of the logs is not arbitrary. If they are positioned incorrectly, the flames can be “pinched” and will not burn correctly. All of the logs either locate on burner pins or a notch, which make alignment easier.
  • Page 41 Secondary Installation Figure 54. Log #2 & #3 Placement Figure 55. Log #1 Placement 5. Next, spread the supplied vermiculite around the perimeter of the burner only. The vermiculite is not intended for use on the burner pan. Place the provided coals on the burner pan in front of the air do not block them (figure 56).
  • Page 42 A small amount on the bottom side of the logs is normal. Remove and replace the logs in the same manner described above. If new logs are required, contact your nearest ENVIRO dealer. Never operate the fireplace with the glass door removed.

  • Page 43: Safety Screen Replacement

    The Westley is supplied with safety screens already installed on the back of the cast front and sides. If a safety screen becomes damaged must it be replaced with either part number 50-3715 (front) or 50-371 (side) by...

  • Page 44: Trouble Shooting

    Trouble Shooting iagnostic Lash oDes 1. Fail to ignite: If there is no positive ignition, the board will go into lock out and the LED will blink 3 times in intervals until the system is reset. 2. Low battery condition (<4V): the LED indicator will blink one (1) time in intervals. 3.
  • Page 45 Trouble Shooting Problem Possible Cause Solution The pilot flame has gone out Thermostat · Turn it ON The On/Off switch is turn to OFF does not work · Set the thermostat to a lower temperature The thermostat is set too high ·...
  • Page 46 Trouble Shooting Problem Possible Cause Solution · Turn the system off by pressing the ON/OFF button on the transmitter · After approximately 2 seconds press the ON/OFF button on the transmitter again. · In the manual flame control mode, use the down arrow button to reduce the flame to off, indicated by the word OFF displayed on Locking the transmitter LCD screen.

  • Page 47: Parts List

    Replacement Safety Screen - Front 50-3715 50-3728 Ceramic Log Set (8 pieces) 50-3736 Ceramic Fluted Liner (1 piece) Westley-IPI Owners Manual 50-3737 NG to LP Stepper Motor Only 50-3753 LP to NG Stepper Motor Only 50-3870 12 oz. Can of Matallic Black Touch Up Paint...
  • Page 48 Parts List...
  • Page 49 Parts List Part Description Reference Part Number Number Cast Top - Painted 50-3717 Cast Top - Antique Bronze 50-3718 Cast Front - Painted 50-3719 Cast Front - Antique Bronze 50-3720 Cast Skirt - Painted 50-3721 Cast Skirt - Antique Bronze 50-3722 Cast Right Side - Painted 50-3723...

  • Page 50: Notes

    Notes...

  • Page 51: Warranty

    Wa rra nty fo r Enviro Gas Pro duc ts Sherwood Industries Ltd. (“Sherwood”) hereby warrants, subject to the terms and Exclusions conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail.

  • Page 52: Installation Data Sheet

    MAI N BURNER ORI FI CE: __________# DMS PI LOT ORI FI CE # _________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD I NDUSTRI ES LTD. 6782 OLDFI ELD RD. SAANI CHTON, BC, CANADA V8M 2A3 www.enviro.com Summer 2021 C-15626...
