Westport - Cast

F R E E S T A N D I N G G A S F I R E P L A C E

OWNER'S MANUAL

WARNING:

If the information in this manual is not followed exactly, a

fire or explosion may result causing property damage, personal injury

or loss of life. Installation and service must be performed by a qualified

installer, service agency or the gas supplier.

CERTIFIED TO: ANSI Z21.88 / CSA 2.33 VENTED GAS FIREPLACE HEATERS

C#4001609

CSA 2.17 GAS FIRED APPLIANCES FOR HIGH ALTITUDES

50-1033

Version Française: www.enviro.com/fr.html

Table of Contents

Need help?

Do you have a question about the Westport-Cast and is the answer not in the manual?

Questions and answers

Ernest Bizzell

February 21, 2025

installing westport **** kit

1 comments:

Mr. Anderson

February 21, 2025

To install the Enviro Westport Cast Iron stove:

1. Cut Openings: Cut a 10-inch (25.4 cm) hole in the ceiling and roof for the flue outlet.
2. Ceiling Support & Insulation Guard: Install the ceiling support and insulation guard.
3. Roof Flashing: Install the roof flashing under the roofing material to create a watertight seal.
4. Flue Pipe Installation: Install the flue pipe from the top of the stove through the roof, ensuring all clearances to combustibles are maintained.
5. Corner Installation (Optional): If installing in a corner with a 90° elbow in the horizontal plane, subtract 36 inches (91.4 cm) from the allowable horizontal run.
6. Drafthood Adaptor (For Vertical Venting): If using a vertical vent, install the Drafthood Adaptor (50-841) and wire it to the gas control valve.

Ensure compliance with local building codes and manufacturer guidelines.

This answer is automatically generated

Summary of Contents for Enviro Westport-Cast

Page 1 Installation and service must be performed by a qualified installer, service agency or the gas supplier. CERTIFIED TO: ANSI Z21.88 / CSA 2.33 VENTED GAS FIREPLACE HEATERS C#4001609 CSA 2.17 GAS FIRED APPLIANCES FOR HIGH ALTITUDES 50-1033 Version Française: www.enviro.com/fr.html...
Page 2: Safety Precautions
Safety Precautions WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
Page 3 Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • All ENVIRO gas-fired appliances must be installed in • A barrier designed to reduce the risk of burns from the accordance with their instructions. Carefully read all the hot veiwing glass is provided with this appliance and shall instructions in this manual first.
Page 4: Table Of Contents
Table of Contents Safety Precautions �� 2 Table of Contents �� 4 Codes And Approvals �� 6 Specifications �� 7 Dimensions: ..........................7 Rating Label Location: ........................7 Operating Instructions �� 8 Pilot Lighting Instructions: ......................8 Pilot Light:............................. 9 Air Shutter: ...........................
Page 5 Table of Contents Secondary Installation �� 35 Installation of Optional Blower: ......................35 Installation of Log Set and Embers: ....................35 Installation of Panel Set: .......................38 Installation of Safety Screen: ......................39 Trouble Shooting �� 40 Parts List - Cast �� 41 Parts List - Components �� 42 Parts Diagram - Components ��...
Page 6: Codes And Approvals
After the unit has gone through the first burn, turn the unit off including the pilot, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local ENVIRO dealer.
Page 7: Specifications
Specifications WARNING: Operation of this heater when not connected to a properly installed and maintained venting system can result in carbon monoxide (CO) poisoning and possible death. imensions " 25 ¾" (39.0cm) (65.3cm) 27" 27" (68.5cm) (68.6cm) 15 ¾" 25 ¾" (40.0cm) (65.4cm) "...
Page 8: Operating Instructions
Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OF LOSS OF LIFE� iLot ighting nstRuctions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING :If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life...
Page 9: Pilot Light
Operating Instructions iLot ight 1. Turn off the gas to the fireplace. If not recently done, remove the glass and let the unit air out for at least five (5) minutes to clear out any gas. Turn on gas to the heater. Leak test all joints with soapy water.
Page 10: Remote Controls (Optional)
Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating emote contRoLs PtionaL This fireplace can use an optional remote control or an optional cordless wall thermostat. If either of these are to be used to control the fireplace for the majority of the time, leave the ON/OFF switch (on the control panel) in the remote/thermostat position.
Page 11: Maintenance And Service
Replace the logs and embers as in the l et and Mber section. If new/more embers and rock wool are required, contact your nearest ENVIRO dealer. nstallatIon hange atteRy in...
Page 12: Burner Removal
Do not operate with the glass front removed, cracked or broken. Removal and replacement of the glass from the door must be done by a licensed or qualified service person. The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed�...
Page 13: Fuel Conversion
Maintenance And Service onveRsion TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY Please read and understand these instructions before installing. Warning: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction.
Page 14 Maintenance And Service 7. Convert the SIT gas valve: a) Remove the black protection cap from the HI/LO knob by hand shown in Figure 11. b) Insert a ” or 4 mm Allen wrench into the hexagonal key-way of the screw (see Figure 12), rotate it counter-clockwise until it is free and extract it.
Page 15 Maintenance And Service 12. Relight the pilot and confirm the flame properly covers both the thermocouple and thermopile (see Figure 3). Should the pilot require adjustment, turn the adjustment screw (see Figure 48 on page 33) clockwise to increase or counterclockwise to decrease until the correct flame is achieved. 13.
Page 16: Initial Installation
Initial Installation QUALIFIED INSTALLERS ONLY WARNING: Operation of this heater when not connected to a properly installed and maintained venting system can result in carbon monoxide (CO) poisoning and possible death. RePaRation nstaLLation • Remove the packaging from the appliance, and check to make sure there is no damage. If damage is found, please report it to both the carrier and your dealer as soon as possible.
Page 17 Initial Installation QUALIFIED INSTALLERS ONLY Your total vent pipe length must be within the shaded area of Figure 22 and Figure 23. If a 90° Round Support Box/Wall Thimble elbow is used in the horizontal plane, 36” (91.4 cm) must be subtracted from the allowable horizontal run.
Page 18: Vent Termination Restrictions
Initial Installation QUALIFIED INSTALLERS ONLY eRmination estRictions Fixed Closed Fixed Openable Closed Openable Termination Cap Air Supply Inlet Gas Meter Restriction Zone (Termination not allowed) Figure 20: Vent Termination Restrictions, refer to Table 3� Table 3: Vent termination clearances, refer to Figure 20. Letter Canadian Installation US Installation...
Page 19 Initial Installation QUALIFIED INSTALLERS ONLY WARNING: Do not mix parts from different vent manufacturers’ systems. EXCEPTION TO WARNING: This product has been evaluated by Intertek for using a DirectVent Pro starting collar in conjunction with other venting systems. Use of this system with the DirectVent Pro starting collar is deemed acceptable and does not affect the Intertek listing of the appliance.
Page 20: Vent Configurations And Restrictor Settings
Using 45˚ elbows is preferable to using 90˚ elbows. Also, a shorter vent system will perform better than a longer one. The ENVIRO WESTPORT has been designed with a built in restrictor plate. The restrictor is designed to enhance flame appearance when installing this unit with vertical chimneys as well as installations with longer horizontal vent applications.
Page 21: Horizontal Installation
Initial Installation QUALIFIED INSTALLERS ONLY oRizontaL nstaLLation 1� Set the appliance in the desired location. Check to determine if wall studs or roof rafters are in the way when the venting system is attached. If this is the case, you may want to adjust the location of the appliance.
Page 22 Initial Installation QUALIFIED INSTALLERS ONLY 7� Slide the decorative wall thimble up to the wall surface and attach with the screws provided. Apply decorative brass or chrome trim if desired (see right image in Figure 25). NOTES: a. The four (4) wood screws provided should be replaced with the appropriate fasteners for stucco, brick, concrete, or other types of siding.
Page 23: Vertical Installation
Initial Installation QUALIFIED INSTALLERS ONLY eRticaL nstaLLation 1� Check the instructions for required clearances (air spaces) to combustibles when passing through ceilings, walls, roofs, enclosures, attic rafters, or other nearby combustible surfaces. Do not pack air spaces with insulation. 2. Set the gas appliance in the desired location. Drop a plumb bob down from the ceiling to the position of the appliance flue exit, and mark the location where the vent will penetrate the ceiling.
Page 24 Initial Installation QUALIFIED INSTALLERS ONLY 7� Slip the flashing over the pipe section protruding through the roof. Secure the base of the flashing to the roof with roofing nails. Use a non-hardening sealant between the uphill edge of the flashing and the roof. Insure the roofing material overlaps the top edge of the flashing as shown in Figure 29.
Page 25: Cathedral Ceiling Installation
Initial Installation QUALIFIED INSTALLERS ONLY Nails Ceiling firestop plumber’s tape connected to wall strap Ceiling Wall strap Use clearances to as defined by appliance and vent pipe manufacturers. 45° elbows (x2) Second floor Figure 32: Multi-Story Vent Pipe Installation Figure 31: Use of Wall Straps atheDRaL eiLing nstaLLation...
Page 26: Corner Installations
Initial Installation QUALIFIED INSTALLERS ONLY 5� Using tin snips, cut the “Support Box” from the top corners down to the roof line, and fold the resulting flaps over the roof sheathing (Figure 34). Before nailing it in to the roof, run a bead of non-hardening mastic around the top edges of the “Support Box”, to make a seal between the box and the roof.
Page 27: Converting Top Vented Into Rear Vented
Initial Installation QUALIFIED INSTALLERS ONLY onveRting enteD into enteD This unit has been shipped as a 30,000 Btu/hr top-vented freestanding unit. This unit can be converted to a rear vented unit with a 36” (915 mm) snorkel for some installation applications.To convert this unit to a rear vented model you must remove the flue pipe adapter and turn to the rear vent position.
Page 28: Installation Of Rear Vented Appliance
Initial Installation QUALIFIED INSTALLERS ONLY Firebox Top Flue Collar Adapter Undo four ¼" screws that hold flue collar elbow to unit. Figure 39: Step 4 of Converting Top Figure 38: Step 3 of Converting Top Vented into Vented into Rear Vented� Rear Vented�...
Page 29: Installation Of Top Vented; Horizontal Termination
Initial Installation QUALIFIED INSTALLERS ONLY nstaLLation oF enteD oRizontaL eRmination This is the most common type of installation style. Set the unit in place. Termination Install a minimum 24” (61 cm) vertical chimney. Inside finished collar Install a 90° elbow, and mark the exterior wall where the vent would pass through.
Page 30: Freestanding Drafthood Adaptor - 50-841
Initial Installation QUALIFIED INSTALLERS ONLY - 50-841: ReestanDing RaFthooD DaPtoR This Drafthood Adaptor is a complete assembly and is ready to fit onto your Westport in a vertical vent application only. With the Drafthood Adaptor correctly installed and wired to the gas control valve. Your Direct Vent Fireplace can be vented like a B-Vent Fireplace.
Page 31 Initial Installation QUALIFIED INSTALLERS ONLY The minimum clearance to combustibles is 6” (150 mm) when using single wall venting and 1” (25 mm) when using “B-vent” venting. We strongly recommend installing an approved chimney liner in an existing brick chimney. This will maximize the potential draft of the chimney and lessen the effects of slow chimney start-up.
Page 32 Initial Installation QUALIFIED INSTALLERS ONLY AUTOMATIC SAFETY SHUT DOWN: If the spill switch is activated and shuts off the main burner the following procedure should be followed. • Is the pilot flame still on? If not, the reason for the fireplace shut down is not the spill switch. •...
Page 33: Gas Line Connection And Testing
Initial Installation QUALIFIED INSTALLERS ONLY onnection anD esting WARNING: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. GAS LINE CONNECTION • This stove is equipped with a certified flexible pipe located on the right side of the unit terminating in a ⅜”...
Page 34: Electrical Requirements For Gas Valve And Optional Blower
PtionaL LoweR The ENVIRO WESTPORT will operate without electrical power. This model has a millivolt gas control, which uses the pilot flame to generate enough electricity to operate the main burners. The appliance when equipped with an optional blower must be electrically connected and grounded in accordance with local codes or in the absence of local codes, with the current CSA C22.1 CANADIAN ELECTRICAL CODE Part 1, SAFETY...
Page 35: Secondary Installation
Ledge for Left Rear Log create dangerous conditions. If over time, through cleaning and Placement Pin for Left Rear Log servicing, these embers require replacement, contact the nearest ENVIRO dealer replacement embers. Figure 53: Step 2 of Log Placement.
Page 36 Secondary Installation 1. Carefully remove logs from box. Check to ensure there is no damage. It is very important Ledge for Center Log to install all logs in their proper position to insure safe, optimum Placement Pin operating conditions. for Center Log 2.
Page 37 ENVIRO dealer. See M on how to remove...
Page 38: Installation Of Panel Set
Secondary Installation nstaLLation oF aneL Do not install when the unit is hot� The brick panel set is fragile. Handle panels with care and avoid knocking them on the placement pins or any other object. 1. Remove the two (2) screws from the rear of the baffle, use a ¼”...
Page 39: Installation Of Safety Screen
Secondary Installation nstaLLation oF aFety cReen The safety screen supplied with the Wesport simply clips onto the outside cast doors when they are closed. Please note that the safety screen cannot be used when the cast doors are open. To install and remove the safety screen follow the steps below: Safety Screen Installation Align the spring clips on the side of...
Page 40: Trouble Shooting
Trouble Shooting Problem Possible Cause Solution The main burner does not The gas valve may not be on. • Check that the gas control knob is in the “ON” position. ignite when called for. Thermostat is not calling for • Adjust the thermostat several degrees above ambient heat.
Page 41: Parts List - Cast
Parts List - Cast Reference Part Description Part Number Number Top Vent Insert Piece - Painted EGWP-503 Top Vent Insert Piece - Antique Chestnut 50-870 Top Grate - Painted EGWP-502 Top Grate - Antique Chestnut 50-869 Top Only (No Grate Or Vent Insert) - Painted 50-368 Top Only (No Grate Or Vent Insert) - Antique Chestnut 50-906...
Page 42: Parts List - Components
Parts List - Components Reference Part Description Part Number Number 120° Ceramic Fan Temperature Sensor EC-001 S.I.T. Nova Valve Convertible 50-1421 Thermocouple EC-009 Spark Electrode with Ignitor Cable EC-011 Thermopile EC-012 Pilot Orifice NG Threaded EC-019 Pilot Orifice LP Threaded EC-020 Pilot Gasket EC-021...
Page 43 Parts List - Components Reference Part Description Part Number Number Fan Kit 180 C.F.M. 50-3621 Door Knob - Brushed Nickel 50-262 Electronic Ignition Module Switch 50-329 Blank Orifice #73 - All Gas Models 50-343 Wiring Harness 50-348 Pressure Relief Door With Gasket 50-3369 Control Panel Decal 50-461...
Page 44: Parts Diagram - Components
Parts Diagram - Components WESTPORT - Components January 2005...
Page 45 Sherwood Industries Ltd. (“Sherwood”) hereby warrants, subject to the terms and conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail.
Page 46: Installation Data Sheet
� _________________________________________ NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in wc PHONE:___________________________________ MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com October 2022 C-14514...
