Enviro Westport Owner's Manual
Hide thumbs Also See for Westport:

Advertisement

SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
OWNER'S MANUAL
WHAT TO DO IF YOU SMELL GAS
• Open windows/Extinguish any open flame.
• Do not try to light any appliance.
• Do not touch any electrical switch or use any phone in your
building.
• Immediately call your gas supplier from a neighbour's phone.
Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life. Installation and service must be performed by a
Massachusetts installations (Warning): This product must be installed by a licensed plumber or gas fitter when
installed within the Commonwealth of Massachusetts. Other Massachusetts code requirements:-Flexible connector
must not be longer than 36 inches, shut off valve must be a "T" handle gas cock, only direct vent sealed combustion
products are approved for bedroom/bathrooms, fireplace dampers must be removed or welded in the open position
prior to the installation of a fireplace insert or gas log.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARNING
qualified installer, service agency or the gas supplier.
Do not store or use gasoline or other Flammable vapours and liquids in the
vicinity of this or any other appliance.
Westport
B Y : S H E R W O O D I N D U S T R I E S L T D
This appliance may be installed in an after
market permanently located, manufactured
(mobile) home, where not prohibited by local
This appliance is only for use with the type of
gas indicated on the rating plate. This appliance
is not convertible for use with other gases, unless
FOR YOUR SAFETY
codes.
a certified kit is used.
50-1033
