Owner's Manual
SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
OWNER'S MANUAL
If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury or loss of life. Installation and
service must be performed by a qualified installer, service agency or the gas supplier.
Do not store or use gasoline or other Flammable vapours and liquids in the vicinity of
Massachusetts installations (Warning): This product must be installed by a licensed
plumber or gas fitter when installed within the Commonwealth of Massachusetts. Other
Massachusetts code requirements:-Flexible connector must not be longer than 36
inches, shut off valve must be a "T" handle gas cock, only direct vent sealed combustion
products are approved for bedroom/bathrooms, fireplace dampers must be removed or
welded in the open position prior to the installation of a fireplace insert or gas log.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Open windows/Extinguish any open flame.
• Do not try to light any appliance.
• Do not touch any electrical switch or use any phone in your
building.
• Immediately call your gas supplier from a neighbour's phone.
Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
This appliance may be installed in an after market permanently
located, manufactured (mobile) home, where not prohibited by
This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other
WARNING
FOR YOUR SAFETY
this or any other appliance.
EG40 BV
B Y : S H E R W O O D I N D U S T R I E S L T D
WHAT TO DO IF YOU SMELL GAS
local codes.
gases, unless a certified kit is used.
EG40-071
Advertisement
Table of Contents
Related Manuals for Enviro EG40 BV
Summary of Contents for Enviro EG40 BV
- Page 1 EG40 BV B Y : S H E R W O O D I N D U S T R I E S L T D WHAT TO DO IF YOU SMELL GAS •...
-
Page 2: Safety Precautions
Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • All ENVIRO gas-fired appliances must be installed in accordance with their instructions. Carefully read all the instructions in this manual first. Consult the building authority having jurisdiction to determine the need for a permit prior to commencing the installation. -
Page 3: Table Of Contents
Table of Contents Safety Precautions...2 Table of Contents...3 Codes And Approvals...4 Specifications...5 Dimensions...5 Clearances to Combustibles...5 Preparation For Installation...5 Initial Installation...6 Venting...6 Flue Gas Spill Switch...6 Manufacturer’s General Venting Guidelines...6 General Venting For The EG40...6 Termination...7 Installation Into An Existing Chimney...7 Straight Vertical Installation...8 Electrical Requirements...9 Replacing The Blower...10... -
Page 4: Codes And Approvals
This appliance has been tested by INTERTEK (Warnock Hersey) and found to comply with the established VENTED GAS FIREPLACE HEATER standards in CANADA and the USA as follows: VENTED GAS FIREPLACE HEATER (EG40 BV NG/LPG) TESTED TO: ANSI Z21.88a-2003/CSA 2.33a-2003 VENTED GAS FIREPLACE HEATERS CAN/CGA 2.17-M91 GAS FIRED APPLIANCES FOR HIGH ALTITUDES... -
Page 5: Specifications
WARNING: Operation of this heater when not connected to a properly installed and maintained venting system can result in carbon monoxide (CO) poisoning and possible death. IMENSIONS �� � � � � ���� ��� � � � � � ���� ��� ����... -
Page 6: Initial Installation
The ENVIRO incorporates its own internal draft hood, so no additional external draft hood is required. Check periodically that the vent is unrestricted and an adequate draught is present when the unit is in operation. -
Page 7: Termination
Initial Installation ERMINATION The bottom of the vent cap shall extend at least 2 feet (0.61 m) above the highest point of the roof where it passes through and at least 2 feet (0.61 m) higher than any portion of the roof within a horizontal distance of 10 feet (3.1 m). -
Page 8: Straight Vertical Installation
Initial Installation TRAIGHT ERTICAL NSTALLATION This basic venting configuration shown are rough guidelines only. Follow national and local codes for other installation options. For the best venting performance, we recommend a total vent height in the range of 10 feet (3.0 m) to 30 feet (9.1 m). -
Page 9: Electrical Requirements
LECTRICAL EQUIREMENTS The ENVIRO EG40 will operate without electrical power. This model has a millivolt gas control, which uses the pilot flame to generate enough electricity to operate the main burners. The appliance is equipped with a blower and must be electrically connected and grounded in accordance with local codes or in the absence of local codes, with the current CSA C22.1 CANADIAN ELECTRICAL CODE Part 1, SAFETY STANDARDS FOR ELECTRICAL INSTALLATIONS,... -
Page 10: Replacing The Blower
Initial Installation EPLACING LOWER Figure 8: Blower (Fan) Removal. DJUSTING ENTURIES • There is a separate venturies for each burner, see Figure 9. • Remove one screw from the cover plate located below the ash shelf and loosen the other screw (do not remove) swing the cover plate out of the way and tighten screw down to hold it in place. -
Page 11: Fuel Conversion
Initial Installation ONVERSION WARNING: This conversion kit shall be installed by a qualified service technician in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion or CO poisoning may result. The qualified service agency is responsible for the proper installation of this kit. -
Page 12: Gas Line Connection And Testing
Initial Installation ONNECTION AND WARNING: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. GAS LINE CONNECTION • This stove is equipped with a certified flexible pipe located on the right side of the unit terminating in a 3⁄8” male NPT fitting. -
Page 13: Secondary Installation
If over time, through cleaning and servicing, these embers require replacement, contact nearest ENVIRO dealer replacement embers. 1. The embers can be place before or after the logs are placed. A bag of ceramic fiber embers and rock wool embers is provided gently remove the ember material from the plastic bag. - Page 14 ENVIRO dealer. See Routine Maintenance And Service on how to remove door to clean glass.
-
Page 15: Operating Instructions
Operating Instructions FOR YOUR SAFETY READ COMPLETELY BEFORE OPERATING. WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OR LIFE. A) This appliance is equipped with a pilot that must be lit by hand by following these instructions exactly. B) BEFORE LIGHTING smell all around the appliance area for gas, and next to the floor because some gas is heavier than air and will settle on the floor. -
Page 16: Routine Maintenance And Service
Depending upon the amount of use, cleaning should be required no more than two or three times per season. To clean the door, use a mild glass cleaner and a soft cloth or a glass cleaner available from your Enviro dealer. -
Page 17: Trouble Shooting
Trouble Shooting Problem Possible Cause Spark will not light the Defective piezo ignitor. pilot after repeatedly pressing the spark ignitor Broken spark electrode. Misaligned spark electrode. Pilot will not remain lit Problem with thermocouple circuit. Air in gas line (pilot dies while knob is depressed). -
Page 18: Parts List
Reference Part Description Number 120 °F (49 °C) Ceramic Temperature Sensor 220 °F (104 °C) Ceramic Spill Switch S.I.T. NOVA Valve NG (50% turn down) S.I.T. NOVA Valve LP (50% turn down) Thermocouple Spark Electrode with Ignitor Cable Thermopile Fully Assembled Pilot NG Fully Assembled Pilot LP Pilot Orifice NG Threaded Pilot Orifice LP Threaded... - Page 19 Parts List Reference Part Description Number BV Owner’s Manual Pedestal Side Panel BV Stove Top Firebox Baffle Stove Top Baffle BV Venturi Cover Plate Front Venturi Bar Set - Painted (3 pieces) Bar Set - Gold (3 pieces) Bar Set - Nickel (3 pieces) Burner Gasket Steel Brick Liner Brick Liner Backing...
-
Page 20: Parts Diagram - Chassis
Parts Diagram - Chassis �� � � �� �� � �� �� �� �� �� �� �� EG 40 Body (Chassis) July 2004... -
Page 21: Parts Diagram - Gas Tray & Door
Parts Diagram - Gas Tray & Door... -
Page 22: Warranty
Warranty Sherwood Industries Ltd. offers a Limited Lifetime Warranty on this gas product. This limited lifetime warranty covers the appliance for a period of seven years from the date of installation. This warranty applies only to the original owner in the original location Covered under the lifetime warranty are Cabinet Sides, Tops, Pedestals, Surround Panels and Chassis and Heat Exchanger. -
Page 23: Installation Data Sheet
Installation Data Sheet The following information must be recorded by the installer for warranty purposes and future reference. NAME OF OWNER: _________________________________________ ADDRESS: _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ MODEL:___________________________________ SERIAL NUMBER:___________________________ DATE OF PURCHASE: _____________ DATE OF INSTALLATION:___________ � � NATURAL GAS (NAT) INLET GAS PRESSURE:_________in wc MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam.
