Enviro - sherwood industries ltd. gas stove owner's manual

Advertisement

Quick Links

SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
OWNER'S MANUAL
WHAT TO DO IF YOU SMELL GAS
• Open windows/extinguish any open flame.
• Do not try to light any appliance.
• Do not touch any electrical switch or use any
phone in your building.
• Immediately call your gas supplier from a
neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire
department.
If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
Installation and service must be performed by a qualified installer, service
Massachusetts installations (Warning): This product must be installed by a licensed plumber or
gas fitter when installed within the Commonwealth of Massachusetts. Other Massachusetts code
requirements: Flexible connector must not be longer than 36in, shut off valve must be a "T" handle
gas cock; only direct vent sealed combustion products are approved for bedrooms/bathrooms;
fireplace dampers must be removed or welded in the open position prior to the installation of a
fireplace insert or gas log.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARNING
agency or the gas supplier.
Do not store or use gasoline or other flammable vapours and
liquids in the vicinity of this or any other appliance.
Sienna
B Y : S H E R W O O D I N D U S T R I E S L T D
FOR YOUR SAFETY
This appliance is
only for use with
the type of gas
indicated on the
rating plate. This
appliance is not
convertible for use
with other gases,
unless a certified
kit is used.
50-1096

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 50-1096 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Enviro 50-1096

  • Page 1 FOR YOUR SAFETY This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases, unless a certified kit is used. 50-1096...
  • Page 2: Safety Precautions

    Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • All ENVIRO gas-fired appliances must be installed in accordance with their instructions. Carefully read all the instructions in this manual first. Consult the building authority having jurisdiction to determine the need for a permit prior to commencing the installation.
  • Page 3: Table Of Contents

    Table of Contents Safety Precautions...2 Table of Contents...3 Codes And Approvals...4 Specifications...5 Rating Label Location...5 Dimensions...5 Operating Instructions...7 Pilot Lighting Instructions...7 Pilot Light...7 Burner Lighting...8 Turn Off Unit...8 Remote Controls - Optional...8 Blower Speed...8 Maintenance And Service...9 Cleaning The Glass...9 Cleaning The Firebox...9 Replacing The Glass...9 Cleaning The Plated Surfaces...9...
  • Page 4: Codes And Approvals

    TESTED TO: ANSI Z21.88a-2003/CSA 2.33a-2003 VENTED GAS FIREPLACE HEATERS CAN/CGA 2.17-M91 GAS FIRED APPLIANCES FOR HIGH ALTITUDES CSA P.4.1-02 TESTING METHOD FOR MEASURING ANNUAL FIREPLACE EFFICIENCY This ENVIRO SIENNA Fireplace: • Has been certified for use with either natural or propane gases. (See rating label.) •...
  • Page 5: Specifications

    ATING ABEL OCATION The rating label is located under the control panel and is attached to a rectangular metal sheet that is chained to the fireplace. IMENSIONS Table 1: Sienna exterior dimensions. (Shaded dimensions shown in Figure 1 & 2.) Surround Style Arched Surround 33”...
  • Page 6 21" (533 mm) With Trim 46 Without Trim 46" (1168 mm) " (775 mm) Figure 2: Sienna exterior dimensions; example 2. Specifications Sensor Flue (441 mm) " (333 mm) " (1171 mm) " (383 mm) Shown: B-Vent with 33" x 46" (84cm x 193 cm) surround panel with trim "...
  • Page 7: Operating Instructions

    Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OF LOSS OF LIFE. ILOT IGHTING NSTRUCTIONS Hot while operating.
  • Page 8: Burner Lighting

    After the unit has gone through the first burn, turn the unit OFF, including the pilot, and let the unit get completely cold. Then remove the glass and clean it with a good gas fireplace glass cleaner, available at your local Enviro dealer. See “D ” sections.
  • Page 9: Maintenance And Service

    Do not operate with the glass front removed, cracked or broken. Removal and replacement of the glass from the door must be done by a licensed or qualified service person. The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed.
  • Page 10: Fuel Conversion

    Maintenance And Service TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY ONVERSION Warning: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction.
  • Page 11: Initial Installation

    • If the unit is to be installed into a zero clearance fireplace the metal floor may be removed to facilitate the installation. The stove may be installed on a combustible material if a minimum 20-gauge piece of steel is installed under the unit. The sides and top of the structure can not be altered though baffles and dampers can be removed.
  • Page 12: Minimum Fireplace Size

    Initial Installation WARNING: Operation of this heater when not connected to a properly installed and maintained venting system can result in carbon monoxide (CO) poisoning and possible death. INIMUM IREPLACE Table 2: Minimum dimensions of fireplace for Sienna to be installed into. Description of Fireplace Dimension At Back Width...
  • Page 13: Direct Vent Model

    4. Remove the vent collar plate from the top of the stove by unscrewing the two (2) T-20 Torx screws located on the center top of the stove. Slide the collar plate backwards. If the fireplace that the unit is to be installed into is high, the collar plate does not need to be removed.
  • Page 14: Venting Fireplace Inserts

    IREPLACE NSERTS The ENVIRO SIENNA may be installed and vented into any solid fuel fireplace that has been installed in accordance with the National, Provincial/State and local building codes and has been constructed of non- combustible materials. Before starting refer to P...
  • Page 15: Electrical Requirements

    Initial Installation QUALIFIED INSTALLERS ONLY LECTRICAL EQUIREMENTS F (49 Temperature Sensor Fan Control CNT4 CNT1 Black Black Black CNT3 CNT2 Green/Yellow White Figure 13: Fan wiring diagram. Optional Remote Control 7 0 ° F Purple Blue BV Only 7 0 ° F F (149 Temperature Sensor...
  • Page 16: Gas Line Connection

    Initial Installation ONNECTION Warning: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. Gas Line Connection: •This fireplace is equipped with a certified flexible pipe located on the right side of the unit, terminating in a 3⁄8”...
  • Page 17: Converting A Direct Vent Fireplace To A B-Vent Fireplace

    Initial Installation QUALIFIED INSTALLERS ONLY ONVERTING IRECT 1. Remove Direct Vent chimney connector assembly by taking out the two (2) T-20 screws at the front of the unit. Push the assembly out from under the brackets at the back and remove (see Figure 16). 2.
  • Page 18: Secondary Installation

    Secondary Installation EPLACING THE LOWER 1. Turn the unit off and allow the unit to cool completely. 2. Remove the fascia or louvers, open the door (see “D 3. Remove the log support tray by lifting the back of the tray up and pull it out from under the lip. Take care to not knock the pilot and the side brick panels.
  • Page 19: Door Removal

    Secondary Installation EMOVAL Figure 19: Top bolts for glass door. NSTALLATION OF URROUND The Sienna must have one of the panels installed around the unit; the unit panel, the filler panel, or the filler panel with trim. If you have trim for your filler panel, the trim must be installed before installing the filler panel onto the unit.
  • Page 20: Log Set And Ember Installation

    Secondary Installation ET AND MBER NSTALLATION NOTE: The logs are fragile and should be handled gently. The placement of the logs is not arbitrary. If they are positioned incorrectly, the flames can be “pinched” and will not burn correctly. The burner, and a few of the logs come with locator pins, notches and ledges, which make alignment easier.
  • Page 21 Secondary Installation Figure 27: The front end of the right/center log has a notch in it that is to rest around the right/center post of the grate. The back end of the log rests on the burner tray (see Figure 26). Ensure the log does not block any burn ports.
  • Page 22: Adjusting Venturi Air Settings

    Secondary Installation Figure 30. Sienna complete log set-up with embers burning. NOTE: While the glass is still removed, it is recommended that the gas line be purged by lighting the pilot. When lighting the fireplace for the first time since the log set and embers have been installed/replaced, watch for ignition at ALL the burner ports.
  • Page 23: Removing The Brick Panel

    Secondary Installation EMOVING RICK ANEL The brick panel set is fragile, handle with extreme care. The brick panel set comes pre-installed. The centre and top panel are the only panels that need to be removed if the complete gas and electrical tray assembly must be removed.
  • Page 24: Trouble Shooting

    Trouble Shooting Problem Possible Cause Spark will not arc Defective piezo ignitor to the pilot after repeatedly pressing the spark ignitor Broken spark electrode Mis-aligned spark electrode Pilot will not remain Problem with thermocouple circuit Air in gas line (pilot dies while knob is depressed) Burners will...
  • Page 25: Parts List- Unit Components

    Conversion Kit from NG to LP Part Number EC-001 EC-003 EC-006 EC-007 EC-009 EC-011 EC-012 EC-019 EC-020 EC-021 EC-023 EC-026 EC-039 EC-042 EC-069 30-043 50-343 50-491 50-559 50-583 50-634 50-916 50-925 50-1089 50-1090 50-1091 50-1092 50-1093 50-1096 50-1112 50-1114 50-1115 50-1116 50-1117 50-1118 50-1119...
  • Page 26: Parts Diagram - Components

    Parts Diagram - Components...
  • Page 27: Parts Diagram - Burner

    Parts Diagram - Burner �� �� �� � � �� � �� � � � � SIENNA - Burner � October 2004...
  • Page 28: Parts List - Options

    Parts List - Options Reference Number Option Description The Cottage Trim Kit - Gold The Cottage Trim Kit - Pewter The Cottage Trim Kit - Antique Copper The Cottage Trim Kit - Painted Charcoal Cape Cod Doors Unit Panel & Keystone Cottage Filler Panel Louvers (set of 2)
  • Page 29: Parts Diagram - Options

    Parts Diagram - Options �� �� �� �� �� �� �� SIENNA - Options October 2004...
  • Page 30: Installation Data Sheet

    Warranty Sherwood Industries Ltd. offers a Limited Lifetime Warranty on this gas product. This Limited Lifetime Warranty covers the appliance for a period of seven years from the date of installation. This warranty applies only to the original owner in the original location. Covered under the lifetime warranty are: the surround, the chassis and the heat exchanger.
  • Page 31: Installation Data Sheet

    Installation Data Sheet The following information must be recorded by the installer for warranty purposes and future reference. NAME OF OWNER: _________________________________________ ADDRESS: _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ MODEL:___________________________________ SERIAL NUMBER:___________________________ DATE OF PURCHASE: _____________ DATE OF INSTALLATION:___________ � � DIRECT VENT �...
