Specifications

Detection range
Coverage
Adjustment
Fresnel lens
Customized optics
LEDs
Top PCB
Sensor PCB
Outputs
NO
NC
Fault/Mask
Power input
Current
Pulse count
Temperature
compensation
Control
Walk test
Operating temperature
Housing
Dimensions W x H x D
Weight
Mounting height
Programmable: 10 m, 20 m
or 30 m
10 to 70° detection angle, 30
x 24 m coverage max.
-60° to +60° pan, tilt +45°
28 zones for each detection
element, which can be
masked with the curtain
sliders
Double silicon shielded quad
element eliminates 50,000
Lux of white light
Red: Programming LED
Blue: Detection alarm
Red(small): Anti-mask alarm
Infrared: Walk tester
communication
Silent, solid state,
magnetically immune.
Volt free relay, signal contact
24 VAC/DC at 50 mA with an
integral 25 Ω series resistor.
Alarm time 5 seconds.
Volt free relay, signal contact
24 VAC/DC at 50 mA with an
integral 25 Ω series resistor.
Alarm time 5 seconds.
Volt free relay, signal contact
24 VAC/DC at 50 mA with an
integral 25 Ω series resistor
10 to 15 V DC
16 mA (12 V nominal)
Standby 27 mA MAX
1 or 2
Analogue (thermistor) and
digital sensitivity adjustment
Digital microprocessor with
non-volatile memory
Output test mode with LED
indication. Option to disable
LEDs.
−30 to +65°C
High impact ABS plastic with
HDPE cover, UV stabilized
125 x 175 x 130 mm
348g Net, 534 g Gross
Variable up to 6 m
Optimum height 3 m for full
range

Regulatory information

Manufacturer UTC Fire & Security Americas
Corporation, Inc.
1275 Red Fox Rd., Arden Hills, MN
55112-6943, USA
Authorized EU manufacturing
representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert,
Netherlands
Certification
EN50130 EN50130-5
EN50131 EN50131-2-2, Grade 3, Class IV
Certified by Telefication B.V
Note: EN50131-2-2 compliant only
when mounted at 1.5m and 3m.
Environmental class IP65
This product meets the
environmental requirements of
EN50130-5.
2002/96/EC (WEEE directive):
Products marked with this symbol
cannot be disposed of as unsorted
municipal waste in the European
Union. For proper recycling, return
this product to your local supplier
upon the purchase of equivalent
new equipment, or dispose of it
at designated collection points.
For more information see: www.
recyclethis.info.

Contact information

www.utcfireandsecurity.com or www.interlogix.com.
For customer support, see www.interlogix.com/customer-
support
