UTC Fire and Security interlogix DI601AM Installation Sheet page 6

Figure 16
Event
TAMPER (SHORT)
STANDBY
ALARM
FAULT
ANTI MASK
TAMPER (OPEN)
Event
TAMPER (SHORT)
STANDBY
ALARM
TAMPER (OPEN)
Figure 17
1.
1.LED
LED
2.Button
2.
Button
Single zone TEOL Calculation
Default (Ohm)
EXAMPLE USING 4K7 TAMPER, 4K7 ALARM AND 10K FAULT/A-M
RESISTORS ALSO TEOL JUMPER SELECTED
REMOVE ALL JUMPERS FOR ISOLATED OUTPUTS
Single zone DEOL Calculation
Default (Ohm)
EXAMPLE USING 4K7 TAMPER AND 4K7 ALARM RESISTORS
REMOVE ALL JUMPERS FOR ISOLATED OUTPUTS
0
4K7
9K4
14K7
19K4
Inf.
0
4K7
9K4
Inf.
Figure 18
1.
CALCULATION
CLOSED CIRCUIT
Rt
Rt + Ra
Rt + Rf
Rt + Ra + Rf
OPEN CIRCUIT
CALCULATION
CLOSED CIRCUIT
Rt
Rt + Ra
OPEN CIRCUIT
2.
3.
