UTC Fire and Security interlogix DI601AM Installation Sheet page 3

Figure 9
Figure 10
Figure 11
TOP
Long range 30m section
Short/ medium range
6m to 20m section
3m
0 2 4
TOP
6m
0 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30m
TOP
MASK THIS SECTION
OFF FOR PET ALLEY
APPLICATIONS UP
TO 30m
1.5m
0 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30m
0°
6 8 10 12 14 16 18 20 22
9°
-2°
Note: EN50131-2-2 Grade 3
compliance requires 3m mounting
height and 0º adjustment, or 1.5m
mounting height and -2º adjustment.
10m
8m
6m
4m
2m
0m
24 26 28 30m
Note: This setup has not been tested
to EN50131-2-2
10m
8m
6m
4m
2m
0m
10m
8m
6m
4m
2m
0m
