MANUAL MODE

1. Switch the line laser ON. Auto leveling function is activated. Press but-
ton (6) to switch on the auto manual mode. LED indicator (7) will be ON
constantly.
2. It is possible to set the inclination of the laser beams along the axis
X and Y in the range of ±3º.
3. Press and hold button H (1) or V(3) to set the tilt angle along the axis X.
4. Press button (3) to set the tilt angle along the axis Y. Press and hold but-
ton H (1) or V (3) to set the tilt angle along the axis Y.
5. Laser lines begin to flash when reaching the full distance position. Press
button (6) to exit from the full tilt distance position or switch off the tilt
mode.
TO CHECK THE ACCURACY OF LINE LASER
5
(SLOPE PLANE)
Set up the line laser between two walls, the distance is 5 m.Turn
on the Line Laser and mark the point of cross laser line on the wall.
Set up the line laser 0,5-0,7m away from the wall and make, as described
above, the same masrks. If the difference {a1-b2} and {b1-b2} is less then
the value of "accuracy" (see spesifications), there is no need in calibration.
Example: when you check the accuracy of Line Laser the difference
is {a1-a2}=5 mm and {b1-b2}=7 mm. The instrument's error: {b1-b2}-
{a1-a2}=7-5=2 mm. Now you can compare this error with standard error.
If the accuracy of Line Laser isn't corresponding with claimed accuracy,
contact the authorized service center.
