Appendix D - DVR-LX ANTENNAS.
The MSU and DVR-LX antennas must be installed in such way as not to cause
interference. If an APX8500 installation kit is required to achieve this, please refer to
separate installation instructions provided by Futurecom (8J087X51).
Before installing an antenna on the trunk lid:
•
Ensure the distance from the antenna to the front surface of the rear back seat is
greater than the minimum distance specified in the DVRS RF Safety Booklet
specific DVRS model and frequency band.
•
Ensure the trunk lid is grounded by connecting grounding straps between the trunk
lid and the vehicle chassis.
To ensure compliance with RF energy safety standards, the antenna locations, gain and
maximum transmit power (for both the MSU and the DVR-LX) must be as specified in
the DVRS RF Safety Booklet
8
Refer to RF Safety Booklet located on the Futurecom Website
9
Refer to RF Safety Booklet located on the Futurecom Website
8M093X01 R1.0
9
.
8
for the
