Status Lights
The relay outputs in the DVR-LX can be programmed to provide several status
indications – 'Primary Light', 'VR On Light', 'LOC Mode Light', or 'SYS Mode Light'.
The DVR-LX then provides control input to an external switch which in turn toggles an
external light. The external switch and light are not included with the DVR-LX.
The light switch relay coil "+" must be wired to +12V DC and the "-" to the corresponding
relay output on the DB15 connector of the DVR-LX auxiliary cable (500mA Max).
Refer to the programming instructions for
Error! Reference source not found.
to enable
this functionality.
AVRA
The Automated VR Activation (AVRA) option enables automated DVR-LX ON/OFF
control triggered by an external switch – portable charger, door switch etc.
If this option is desired, the external switch (provided by others) needs to be wired to one
of the following:
7
Option 1: A dedicated VIP Input on the MSU Control Head or DEK
.
Option 2: 'Switch 1 Input' on the DB15 of the DVR-LX Auxiliary Cable.
Note: With an in-band configuration, the auxiliary cable is provided for use with AVRA.
For a cross-band configuration, the cable will need to be ordered separately- order
number: DDN9031.
Refer to the programming instructions for
Automated VR Activation (AVRA to enable this functionality.
7
For detailed instructions on VIP wiring, please refer to the MSU installation manuals available
from Motorola.
39
8M093X01 R1.0
