Installation Planning

FILTER LIMITS: The DVR-LX is shipped equipped with custom filters tuned to the
specified frequency range provided by the customer. Programming the DVR-LX /
MSU to operate on frequencies outside of the original specified bands may result in
intermittent or complete loss of communications. Frequency changes may require
filter retuning or replacement.
TRANSMIT POWER (CROSS-BAND): The cross-band DVR-LX can be interfaced to
a high power MSU, however, the transmit power of the MSU must be reduced to
comply with the maximum power restrictions described in the DVRS RF Safety
3
Booklet .
TRANSMIT POWER (IN-BAND): In all in-band DVRS configurations, the MSU
transmit power must not exceed 50 Watts on DVRS Enabled MSU Modes due to the
in-band filters' power rating. The in-band filters connected to the MSU have typical
insertion loss of 1.5dB.

Tools Required

Description
Drill
Center Punch
(Optional)
4mm Allen Key
Wire Cutters and
Crimping Tool
3/16" Flat Screwdriver

Programming Details

This section will detail programming information needed to enable certain installation
options. For full instructions on how to program the DVR-LX, please refer to the VR
4
Programming Guide .

Bypass Switch

RF Bypass Switch with non-APX8500 MSU
If installing an in-band DVR-LX, it comes equipped with an internal RF bypass switch.
This switch bypasses the filtering at the output of the MSU as required to allow access to
3
Refer to RF Safety Booklet available on the Futurecom website.
4
Refer to VR Programming Guide available on the Futurecom website.
