Summary of Contents for Deagostini MODEL SPACE FAST& FURIOUS DODGE CHARGER R/T

  • Page 1 pack...
  • Page 2 FCA US LLC and used under license by The left door window (II) Premium and Collectibles Trading Co. Ltd. ©2019 FCA US LLC. ©️ 2019 Editorial Planeta DeAgostini S.A.U. Todos los derechos reservados. Stage 88 The left and right doors ©️...
  • Page 3 THE LEFT DOOR STAGE WINDOW (I) In this assembly session you will be working on the left door window. Please follow our assembly instructions and accompanying illustrations carefully. PIECES FOR THIS STAGE 86A Chrome guide 86E Deflector mount bracket SP screws 1.2X3 mm (x 2) * 86B Chrome deflector trim Screwdriver TP screws 1.2X3 mm (x 5) *...
  • Page 4 STAGE 86 86.1 ttAch the chrome window guide 86A by aligning the holes with those on the inside of the left door 82A. Secure with four type CM screws. 86.2 ttAch the chrome deflector trim 86B to the corresponding guide on the inner section of the left door 84A.
  • Page 5 STAGE 86 86.3 rom the other side of the inner section of the left door 84A, insert two more type TP screws to finish securing the trim. 86.4 nsert the holed end of the knob 86D into the hole in the deflector glass 86C. The knob lever must be facing upwards.
  • Page 6 STAGE 86 86.6 the glass 86C in place and position the mount bracket 86E on the bottom linchpin. Secure the pieces to the left door 84A with a type DP screw. STAGE 86 FINAL RESULT You have finished working on the left door for now.
  • Page 7 THE LEFT DOOR STAGE WINDOW (II) In this assembly session you will continue working on the left door window. Please follow our assembly instructions and accompanying illustrations carefully. PIECES FOR THIS STAGE 87A Glass left door window 87F Window regulator cover plate BP screws 1.7X3X5 mm (x 3) * 87B Window crank 87G Window weatherstrips (x2)
  • Page 8 STAGE 87 87.1 the knob 87H to the left door window crank ttAch 87B and secure the pieces with a type GP screw. 87.2 the crank 87B into the hole on the inside of the nsert door, as shown in the illustration. From the outside of the 87.3 door, slide cog 1 87C onto the end of the handle.
  • Page 9 STAGE 87 87.5 a weatherstrip ttAch 87G to the window guide 86A. Attach the other weatherstrip to the top of the inner section of the door 84A. 87.6 the tab with the rectangular lign opening in the glass 87A with the linchpin on the end of cog 3 87E.
  • Page 10 STAGE 87 87.7 the two parts of the left door together, aligning the holes and linchpins. Secure the pieces with six type AM screws, and one type TP screw for the top of the window guide 86A. 87.8 ou cAn now test the window lift mechanism, which lifts and lowers the window by simply turning the crank.
  • Page 11 THE LEFT AND RIGHT STAGE DOORS In this assembly session you will mount the now complete left door on your model, and start assembling the right door. Follow our assembly instructions carefully. PIECES FOR THIS STAGE 88A Right door (outer panel) 88C Lock 88B Handle AP screws 1.7X4 mm (x 2) *...
  • Page 12 STAGE 88 88.1 the left door on the car body very osition carefully, aligning it with the hinge mount plate 83F and the hinge mounting bracket 63B.
  • Page 13 STAGE 88 88.2 ow AttAch the top and bottom hinges (parts 2 83C and 2 83E) with two type SM screws. 88.3 the right door, tArt Assembling by pressing the lock 88C into the hole in the outer panel of the door 88A, as shown in the illustration.
  • Page 14 STAGE 88 88.4 inAllY insert the handle 88B into the holes above the lock. From the inside of the door panel, secure the handle with a type AP screw. STAGE 88 FINAL RESULT You have now attached the left door to the body of your model, and started assembling the right door.
  • Page 15 MOUNTING THE RIGHT STAGE DOOR (I) In this assembly session you will continue to work on the right door. Please follow our assembly instructions and accompanying illustrations carefully. PIECES FOR THIS STAGE 89A Inner frame of the right door 89D Bottom hinge (part 1) AP screws 2X4 mm (x 13) * 89B Top hinge (part 1) 89E Bottom hinge (part 2)
  • Page 16 STAGE 89 89.1 lAce the inner frame 89A onto the left door 88A, making sure all the holes are aligned. Secure the two pieces with four type AM screws. 89.2 the two parts of the top hinge (89B and 89C) and join them together using a type TM screw.
  • Page 17 STAGE 89 89.4 assemble the bottom hinge by joining part 1 89D and part 2 89E with a type UM screw. 89.5 ttAch the bottom hinge to the inside of the right door with two type AM screws.
  • Page 18 STAGE 89 89.6 attach the hinge mount plate 89F to the middle inAllY section of the body 61A, as shown in the illustration, using three type AM screws. STAGE 89 FINAL RESULT You have now attached the hinges to the right door and the corresponding mount plate to the car body.
  • Page 19 THE RIGHT DOOR STAGE LOCK In this assembly session you will continue to work on the right door. Please follow our assembly instructions and the accompanying illustrations carefully. PIECES FOR THIS STAGE 90A Inner section of the right door 90D Lock 90B Lock stem 90E Lock mount bracket 90C Lock spring...
  • Page 20 STAGE 90 90.1 the door lock system by sliding the spring 90C onto tArt Assembling the shorter end of the stem 90B; hold the two components together with your hands and move on to the next step. 90.2 the free end of the stem 90B into the nsert hole in the middle of the concave side of the lock 90D.
  • Page 21 STAGE 90 90.3 the completed lock 90D into the housing in the inner section of the nsert door 90A, as shown in the illustration, making sure that the spring is facing the middle of the door.
  • Page 22 STAGE 90 90.4 over the lock and spring with the mount bracket 90E, as shown in the illustration, and attach the latter to the inner section of the door 90A with two type AP screws. STAGE 90 FINAL RESULT You have now installed the lock mechanism on the inner section of the right door.
