Incoming And Outgoing Data Connection - SMA NET Piggy-Back Technical Description

SMA Solar Technology AG
Required parameter settings on the device:
• CO_NET-GSM PIN:
- The respective PIN number of the SIM card.
• CO_NET Auto Answer:
- Set a value greater than "0" here (recommendation: "2").
For information on configuring the device for e-mail transmission, see Section 6.

5.3.3 Incoming and Outgoing Data Connection

This data connection method is a combination of the two methods described above. This means that
the Sunny Boy Control can automatically send data at regular intervals and using your PC, you can
access the system to set the system parameters. The SIM card requires a data connection through
the CSD data service in order for the NET Piggy-Back to receive data. Other data services such as
GPRS are not available.
Prepaid Cards
In most cases, prepaid cards cannot be used for this purpose.
If in doubt, please consult your cell phone network provider.
Required parameter settings on the device:
• CO_NET-GSM PIN:
- The respective PIN number of the SIM card.
• CO_NET Auto Answer:
- Set a value greater than "0" here (recommendation: "2").
• FI_ISP Phone No:
- The access number of your Internet service provider (ISP).
• FI_ISP User ID:
- The user ID that you received from the Internet service provider (ISP).
• FI_ISP Password:
- The password that corresponds to the user ID.
Access Number of your Service Provider
The access number of your Internet service provider depends on the cell network
of your SIM card. You receive this telephone number from your Internet service provider.
For information on configuring the device for e-mail transmission, see Section 6.
Technical Description
Initial Start-up
NETPB-TEN081708 21
