Components And Specifications - Guardian Fall Protection Edge Angel SRL Instruction Manual

Compatibility: When making connections with Edge Angel SRL, eliminate all possibility of roll-out. Roll-out
occurs when interference between a hook and the attachment point causes the hook gate to unintentionally
open and release. All connections must be selected and deemed compatible with Edge Angel SRL by a
Competent Person. All connector gates must be self-closing and self-locking, and withstand minimum loads of
3,600 lbs. See the following for examples of compatible/incompatible connections:
Connector
closed and
locked to
D-ring. OK.
Two connectors
to same
D-ring. NO.
Incompatible
or irregular
application,
which may
increase risk
of roll-out. NO.
Two or more
snap hooks or
carabiners
connected to
each other. NO.

Components and Specifications

Materials: aluminum, galvanized steel, stainless steel, zinc-plated steel, polyester, and nylon.
Class B SRL.
Average arrest force: 900 lbs.
Maximum arrest force:1,800 lbs.
Maximum deceleration distance: 54".
Part # Length
10920 20'
10922 25'
10925 30'
3
3/16" HD Galvanized Cable SRL w/Carabiner, Swivel Top, Snap Hook, & Boot Cover
3/16" HD Galvanized Cable SRL w/Carabiner, Swivel Top, Snap Hook, & Boot Cover
3/16" HD Galvanized Cable SRL w/Carabiner, Swivel Top, Snap Hook, & Boot Cover
Description
Connector
to integral
lanyard.
NO.
Connector
directly to
webbing.
NO.
Connector
directly to
horizontal
lifeline. NO.
