Electrical installation

6
Electrical installation
6.1

Pin assignment

teach in
2
2
1
1
+Vs
6.2

Connection diagram

Analog
Push-Pull
6.3

Connecting the sensor to electricity

Instruction:
a) Ensure that the system is disconnected from power.
b) Connect the sensor according to the pin assignment.
22
analog
4
4
3
3
0 V
BN (1)
+Vs
Z
WH (2)
analog
BK (4)
output / IO-Link
Z
Z
BU (3)
0 V
Operating Manual
1
+Vs
2
analog
3
0 V
4
output / IO-Link
1
BN – Brown
2
WH – White
3
BU – Blue
4
BK – Black
Baumer
OM20/OM30 IO-Link | V2
