Operating Manual
VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2
EN-US
(Gigabit Ethernet / USB3.0)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCXG.2-13M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Baumer VCXG.2-13M

Summary of Contents for Baumer VCXG.2-13M

  • Page 1 Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 EN-US (Gigabit Ethernet / USB3.0)

  • Page 2: Table Of Contents

    List of contents Baumer List of contents 1 About this document ..........................11 Purpose............................... 11 Warnings in this manual........................11 Labels in this manual .......................... 11 Liability limitation ..........................12 Copyright............................. 12 2 General information ............................ 13 3 Description..............................14 VCXG.2 ...............................
  • Page 3 9 Troubleshooting ............................73 Support..............................73 Accessories............................73 10 Software ............................... 74 10.1 Baumer GAPI ............................74 10.2 Baumer neoAPI........................... 74 10.3 Baumer Camera Explorer ........................74 10.4 3 Party Software..........................74 Vp1.0 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 Operating Manual...
  • Page 4 List of contents Baumer 11 GenICam Camera Features ........................75 11.1 Category: AcquisitionControl....................... 75 11.1.1 AcquisitionAbort ........................75 11.1.2 AcquisitionFrameCount......................76 11.1.3 AcquisitionFrameRate......................76 11.1.4 AcquisitionFrameRateEnable ....................76 11.1.5 AcquisitionMode........................77 11.1.6 AcquisitionStart ........................77 11.1.7 AcquisitionStatus ........................77 11.1.8 AcquisitionStatusSelector .....................
  • Page 5 Baumer List of contents 11.4.12 ExposureAutoMinValue ......................102 11.4.13 GainAutoMaxValue ....................... 102 11.4.14 GainAutoMinValue ........................ 102 11.5 Category: ChunkDataControl ......................103 11.5.1 ChunkEnable ........................104 11.5.2 ChunkModeActive......................... 104 11.5.3 ChunkSelector ........................104 11.6 Category: ColorTransformationControl (color cameras only).............. 106 11.6.1 ColorTransformationAuto......................
  • Page 6 List of contents Baumer 11.9.15 DeviceSFNCVersionMajor ....................121 11.9.16 DeviceSFNCVersionMinor ....................122 11.9.17 DeviceSFNCVersionSubMinor....................122 11.9.18 DeviceScanType........................122 11.9.19 DeviceSensorType........................ 122 11.9.20 DeviceSerialNumber ......................123 11.9.21 DeviceStreamChannelCount ....................123 11.9.22 DeviceStreamChannelEndianness ..................123 11.9.23 DeviceStreamChannelSelector..................... 123 11.9.24 DeviceStreamChannelType ....................124 11.9.25 DeviceTLType........................
  • Page 7 Baumer List of contents 11.11.1 EventNotification ........................146 11.11.2 EventSelector........................146 11.11.3 LostEventCounter ......................... 147 11.12 Category: ImageFormatControl......................147 11.12.1 BinningHorizontal........................151 11.12.2 BinningHorizontalMode......................153 11.12.3 BinningSelector........................154 11.12.4 BinningVertical ........................154 11.12.5 BinningVerticalMode ......................156 11.12.6 Category: ImageFormatControl → CalibrationControl (MP cameras only)......156 11.12.6.1...
  • Page 8 List of contents Baumer 11.15.5 SequencerPathSelector ......................182 11.15.6 SequencerSetActive ......................182 11.15.7 SequencerSetLoad ....................... 183 11.15.8 SequencerSetNext........................ 183 11.15.9 SequencerSetSave ....................... 183 11.15.10SequencerSetSelector ......................183 11.15.11SequencerSetStart ....................... 184 11.15.12SequencerTriggerActivation ....................184 11.15.13SequencerTriggerSource...................... 184 11.16 Category: TestControl ......................... 185 11.16.1 TestPendingAck........................185 11.17 Category: TransportLayerControl......................
  • Page 9 Baumer List of contents 11.17.2.37 GevSCSP ......................196 11.17.2.38 GevSecondURL ....................196 11.17.2.39 GevStreamChannelSelector................196 11.17.2.40 GevSupportedOption..................196 11.17.2.41 GevSupportedOptionSelector ................197 11.17.2.42 InterfaceSpeedMode ..................197 11.17.3 PayloadSize .......................... 197 11.17.4 Category: TransportLayerControl → USB3Vision ..............198 11.17.4.1 InterfaceSpeedMode ..................198 11.17.4.2...
  • Page 10 List of contents Baumer 13.6 Packet Resend............................ 216 Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | Vp1.0...

  • Page 11: About This Document

    In addition, the local occupational health and safety regulations and general safety regulations apply. The illustrations in this manual are examples only. Deviations are at the discretion of Baumer at all times. Warnings in this manual Warnings draw attention to potential personal injury or material damage.

  • Page 12: Liability Limitation

    Any duplication or reprinting of this documentation, in whole or in part, and the reproduction of the illustrations even in modified form is permitted only with the written approval of Baumer. The information in this document is subject to change without notice.

  • Page 13: General Information

    Used electrical and electronic devices may not be disposed of in household waste. The product contains valuable raw materials that can be recycled. There- fore dispose of this product at the appropriate collection point. For additional in- formation visit www.baumer.com. Vp1.0 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 Operating Manual...

  • Page 14: Description

    Description Baumer Description VCXG.2 3.1.1 Conception Lens mount (C-mount) Power supply / Digital IO Network connection with LEDs 3.1.2 LED status indicator Signal Meaning green Connection active green flashing receiving data yellow Error yellow flashing Transmitting data Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | Vp1.0...

  • Page 15: Camera Models

    Baumer Description 3.1.3 Camera models Camera type Sensor size Resolution Max. FPS Monochrom VCXG.2-13M 1/2" 1280 × 1024 145 | 94 VCXG.2-15M 1/1.8" 1440 × 1080 120 | 79 VCXG.2-25M 2/3" 1920 × 1200 59 | 53 VCXG.2-32M 1/1.8" 2048 × 1536 55.5 | 39.5...

  • Page 16: Dimensional Drawing

    Description Baumer 3.1.4 Dimensional drawing 2 x M3 x 4 8 x M3 x 4 C-mount 48,9 6,6 ±0,35 4,45 Ill. 1: Dimensional drawing - VCXG.2 Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | Vp1.0...

  • Page 17: Vcxg.2.Xc

    Baumer Description VCXG.2.XC 3.2.1 Conception Lens mount (C-mount) Cooling channel (inlet) Cooling channel (outlet) Network connection Power supply / Digital IO 3.2.2 LED status indicator Signal Meaning green Connection active green flashing receiving data yellow Error yellow flashing Transmitting data Vp1.0 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2...

  • Page 18: Camera Models

    Description Baumer 3.2.3 Camera models Camera type Sensor size Resolution Max. FPS Monochrom VCXG.2-51M.XC 2/3" 2448 × 2048 35.5 | 23.5 VCXG.2-241M.XC 1.2" 5312 × 4592 5 | 5 3.2.4 Dimensional drawing 8 x M3 x 4,5 36,7 temperature ø...

  • Page 19: Vcxg.2.I

    Baumer Description VCXG.2.I 3.3.1 Conception Lens mount (C-mount) 4 x tube adapter with front mounting threads Power supply / Digital IO Network connection GigE status indicator 3.3.2 LED status indicator Signal Meaning yellow Error yellow flashing Transmitting data green Connection active...

  • Page 20: Camera Models

    Description Baumer 3.3.3 Camera models Camera type Sensor size Resolution Max. FPS Monochrom VCXG.2-15M.I 1/1.8" 1440 × 1080 120 | 79 VCXG.2-32M.I 1/1.8" 2048 × 1536 55.5 | 39.5 VCXG.2-51M.I 2/3" 2448 × 2048 35.5 | 23.5 VCXG.2-82M.I 2/3" 2848 × 2832 15 | 15 VCXG.2-127M.I...

  • Page 21: Dimensional Drawing

    Baumer Description 3.3.4 Dimensional drawing 38,4 8,33 2 x M3 x 5 8 x M3 x5 temperature measurement point Ø 28,7 18,6 10,7 12,9 10,2 50,8 6,95 Ill. 3: Dimensional drawing - VCXG.2.I Vp1.0 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2...

  • Page 22: Vcxu.2

    Description Baumer VCXU.2 3.4.1 Conception Lens connection (C-mount) Digital-IO USB3.0 3.4.2 LED status indicator Signal Meaning green flashing Power on green continuous Connection via USB 3.0 Connection via USB 2.0 yellow Data traffic red flashing Update Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | Vp1.0...

  • Page 23: Camera Models

    Baumer Description 3.4.3 Camera models Camera type Sensor size Resolution Max. FPS Monochrom VCXU.2-13.M 1/2" 1280 × 1024 VCXU.2-15.M 1/2.9" 1440 × 1080 VCXU.2-31.M 1/1.8" 2048 × 1536 VCXU.2-32.M 1/1.8" 2048 × 1536 55.5 VCXU.2-50.M 2/3" 2448 × 2048 VCXU.2-50.MP 2/3"...

  • Page 24: Dimensional Drawing

    Description Baumer 3.4.4 Dimensional drawing 2 x M3 x 4 8 x M3 x 4 C-mount 37,8 6,6 ±0,35 6,15 Ill. 4: Dimensional drawing - VCXU.2 Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | Vp1.0...

  • Page 25: Transport And Storage

    Baumer Transport and storage Transport and storage Transport NOTICE Material damage due to improper transport. a) Ensure maximum diligence when unloading the delivered packages as well as when trans- porting them inside the company. b) Note the information and symbols on the packaging.

  • Page 26: Installation

    Installation Baumer Installation Environmental requirements Storage temperature VCXG.2 -10 °C (+14 °F) ... +70 °C (+158 °F) VCXG.2.XC -10 °C (+14 °F) ... +70 °C (+158 °F) VCXG.2.I -10 °C (+14 °F) ... +70 °C (+158 °F) VCXU.2 -10 °C (+14 °F) ... +70 °C (+158 °F) Operating tempera- VCXG.2...

  • Page 27: Mechanical Tests

    Baumer Installation Mechanical Tests Baumer cameras are tested towards the following standards to ensure industrial suitability. Test environment Standard Parameter Vibration, sinusoidal IEC 60068-2-6 Continuous oscillation 10-2000 Hz Amplitude underneath 1.5 mm crossover frequencies Acceleration 10 g Test duration 150 min (axis)

  • Page 28: Emergency Shutdown At Overtemperature

    Installation Baumer Emergency shutdown at Overtemperature To prevent damage on the hardware due to high temperatures, the camera features emergency shutdown. Function DeviceTemperatureStatusTransitionSelector (Category: DeviceControl) is to select temperature thresholds: NormalToHigh: freely programmable value HighToExeeded: fixed value (camera shutdown if exceeded)
  • Page 29 DeviceTemperatureExceeded is set to True and image acquisition stops. VCXG.2 Camera type max. temperature (internal sensor) Monochrom / Color VCXG.2-13M / VCXG.2-13C 75 °C (167 °F) VCXG.2-15M / VCXG.2-15C 75 °C (167 °F) VCXG.2-25M / VCXG.2-25C 75 °C (167 °F) VCXG.2-32M / VCXG.2-32C...

  • Page 30: Heat Dissipation

    Heat accumulation in the device Heat can damage the device. Provide adequate dissipation of heat. As there are numerous pos- sibilities for installation, Baumer recommends no specific method for proper heat dissipation, but suggest the following principle: a) Every form of convection around the device and mounting helps reduce temperature. Pre- vent heat from becoming trapped! b) Mounting in combination with forced convection may provide proper heat dissipation.
  • Page 31 Baumer Installation VCXG.2.I Temperature measuring point (T) / Maximum temperature 65 °C (149 °F) VCXU.2 Temperature measuring point (T) / Maximum temperature 65 °C (149 °F) 60 °C (140 °F) VCXU.2-201M.R/C.R Vp1.0 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2...

  • Page 32: Cooling Channel (Vcxg.2.Xc Only)

    Installation Baumer 5.4.1 Cooling channel (VCXG.2.XC only) The camera features a housing-integrated cooling channel. This is to feed compressed air or tempering fluid for camera temperature control. For compressed air / tempering fluid connection (inlet (1) / outlet (2)) use male threaded M3 push-in fittings and plastic hoses, e.g.
  • Page 33 Baumer Installation Class Particle Water ≤ 5 ≤ 10 > 10 > 10 > 5 Cooling with tempering fluid The tempering fluid efficiently takes the heat away from the camera. cold air Heat exchanger Tank Pump Cooling channel (inlet) Cooling channel (outlet)

  • Page 34: Lens Mount

    Installation Baumer Lens mount Avoid contamination of the sensor and the lens by dust and airborne particles when mounting the lens to the device! Therefore the following points are very important: Install the camera in an environment that is as dust free as possible! Keep the lens mount covered if no lens is attached Hold the camera downwards with unprotected sensor.

  • Page 35: Modular Tube System (Please Order Separately)

    Instruction: a) Mount the Modular Tube System as shown in the illustration below. b) Baumer recommends ELKALUB GLS 867 grease for easier installation of the sealing rings (5). c) Tighten the screws (3) with a torque wrench to 0.9 Nm.
  • Page 36 Installation Baumer Tube adapter M 47 M 62 3,25 3,25 2,75 2,75 5,25 5,25 Art. No.: 11185373 Art. No.: 11185377 M 92 3,25 2,75 5,25 11704311 Art. No.: Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | Vp1.0...
  • Page 37 Baumer Installation Spacer M 47 M 62 O-Ring O-Ring Art. No.: 11185376 Art. No.: 11185372 O-Ring O-Ring Art. No.: 11185375 Art. No.: 11185371 O-Ring O-Ring Art. No.: 11198906 Art. No.: 11211571 Vp1.0 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2...
  • Page 38 Installation Baumer M 92 O-Ring Art. No.: 11704395 7.25 O-Ring Art. No.: 11704397 7.25 O-Ring Art. No.: 11704394 Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | Vp1.0...
  • Page 39 Baumer Installation Tube M 47 M 62 54,5 40,5 Art. No.: 11185374 (Cover Glass: Acryl) Art. No.: 11185370 (Cover Glass: Acryl) Art. No.: 11195426 (Cover Glass: restistant laminated safety cover glass) Art. No.: 11195425 (Cover Glass: restistant laminated safety cover glass) M 92 66.5...
  • Page 40 Installation Baumer M 92 Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | Vp1.0...

  • Page 41: Optical Specification

    Baumer Optical specification Optical specification VCXG.2 6.1.1 Sensor position accuracy Typical precision under assumption of the average square root value is shown in the figure and table(s) below. ± XM ± XR photosensitive surface of the sensor front filter glass...

  • Page 42: Filter Glass Color Cameras

    1100 1000 1100 ON Semiconductor ® Python 1300 mono ON Semiconductor ® PYTHON 1300 color Wave Length [nm] Wave Length [nm] Spectral sensitivity VCXG.2-13M Spectral sensitivity VCXG.2-13C (PYTHON1300) (PYTHON1300) 1000 1000 Sony ® IMX 273 mono Sony ® IMX 273 mono...
  • Page 43 Baumer Optical specification 6000 6000 5000 5000 4000 4000 3000 3000 2000 2000 1000 1000 1000 1100 1000 1100 ® ® ON Semiconductor PYTHON 2000 mono ON Semiconductor PYTHON 2000 color Wave Length [nm] Wave Length [nm] Spectral sensitivity VCXG.2-25M Spectral sensitivity VCXG.2-25C...
  • Page 44 Optical specification Baumer 1000 ® Sony IMX 178 mono Wave Length [nm] Sony ® IMX 178 color Wave Length [nm] Spectral sensitivity VCXG.2-65M.R Spectral sensitivity VCXG.2-65C.R ® ® (Sony IMX178) (Sony IMX178) 1000 1000 ® ® Sony IMX 546 mono...
  • Page 45 Baumer Optical specification 1000 1000 ® ® Sony IMX 545 mono Sony IMX 545 color Wave Length [nm] Wave Length [nm] Spectral sensitivity VCXG.2-127M Spectral sensitivity VCXG.2-127C ® ® (Sony IMX545) (Sony IMX545) 1000 ® Sony IMX 183 mono Wave Length [nm] Sony ®...
  • Page 46 Optical specification Baumer 1000 1000 ® ® Sony IMX 540 mono Sony IMX 540 color Wave Length [nm] Wave Length [nm] Spectral sensitivity VCXG.2-241M Spectral sensitivity VCXG.2-241C ® ® (Sony IMX540) (Sony IMX540) Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | Vp1.0...

  • Page 47: Vcxg.2.Xc

    Baumer Optical specification VCXG.2.XC 6.2.1 Sensor position accuracy Typical precision under assumption of the average square root value is shown in the figure and table(s) below. ± XM ± XR photosensitive surface of the sensor front filter glass for color cameras thickness: 1 ±...
  • Page 48 Optical specification Baumer Cameras 1000 Sony ® IMX 264 mono Wave Length [nm] Spectral sensitivity VCXG.2-51M.XC ® (Sony IMX264) 1000 Sony ® IMX 540 mono Wave Length [nm] Spectral sensitivity VCXG.2-241M.XC ® (Sony IMX540) Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | Vp1.0...

  • Page 49: Vcxg.2.I

    Baumer Optical specification VCXG.2.I 6.3.1 Sensor position accuracy Typical precision under assumption of the average square root value is shown in the figure and table(s) below. ± XM ± XR photosensitive surface of the sensor front filter glass for color cameras thickness: 1 ±...

  • Page 50: Filter Glass Color Cameras

    Optical specification Baumer 6.3.2 Filter glass color cameras 100% 1000 1100 1200 Wavelength in nm Filter glass of color cameras Filter glass color cameras 6.3.3 Cover glasses Tubes 100% 100% 1000 1100 1200 1000 1100 1200 Wavelength in nm Wavelength in nm...
  • Page 51 Baumer Optical specification 1000 1000 ® Sony IMX 265 color Wave Length [nm] Sony ® IMX 250 mono Wave Length [nm] Spectral sensitivity VCXG.2-32M.I Spectral sensitivity VCXG.2-32C.I ® ® (Sony IMX265) (Sony IMX265) 1000 1000 Sony ® IMX 264 mono ®...
  • Page 52 Optical specification Baumer 1000 1000 ® ® Sony IMX 545 mono Sony IMX 545 color Wave Length [nm] Wave Length [nm] Spectral sensitivity VCXG.2-127M.I Spectral sensitivity VCXG.2-127C.I ® ® (Sony IMX545) (Sony IMX545) 1000 ® Sony IMX 183 mono Wave Length [nm] Sony ®...

  • Page 53: Vcxu.2

    Baumer Optical specification VCXU.2 6.4.1 Sensor position accuracy Typical precision under assumption of the average square root value is shown in the figure and table(s) below. ± XM ± XR photosensitive surface of the sensor front filter glass for color cameras thickness: 1 ±...

  • Page 54: Filter Glass Color Cameras

    Optical specification Baumer 6.4.2 Filter glass color cameras 100% 1000 1100 1200 Wavelength in nm Filter glass of color cameras Filter glass color cameras 6.4.3 Spectral sensitivity The following diagrams show the spectral sensitivity characteristics for this camera series. The characteristic curves for the sensors do not take the characteristics of lenses and light sources without filters into consideration.
  • Page 55 Baumer Optical specification 1000 1000 Sony ® IMX 252 mono Sony ® IMX 252 color Wave Length [nm] Wave Length [nm] Spectral sensitivity VCXU.2-31M Spectral sensitivity VCXU.2-31C ® ® (Sony IMX252) (Sony IMX252) 1000 1000 Sony ® IMX 265 color...
  • Page 56 Optical specification Baumer 1000 ® Sony IMX 250MZR-C Wave Length [nm] Spectral sensitivity VCXU.2-50MP ® (Sony IMX250MZR-C) 1000 1000 ® Sony IMX 264 mono Wave Length [nm] Sony ® IMX 264 color Wave Length [nm] Spectral sensitivity VCXU.2-51M Spectral sensitivity VCXU.2-51C ®...
  • Page 57 Baumer Optical specification 1000 1000 ® ® Sony IMX 253 mono Sony IMX 253 color Wave Length [nm] Wave Length [nm] Spectral sensitivity VCXU.2-123M Spectral sensitivity VCXU.2-123C ® ® (Sony IMX253) (Sony IMX253) 1000 ® Sony IMX 183 mono Wave Length [nm] Sony ®...

  • Page 58: Electrical Installation

    Electrical installation Baumer Electrical installation General instructions for electric installation NOTICE Device damage due to faulty power supply. The device can be damaged due to faulty power supply. a) Operate the device only with protected low voltage and safe electrical isolation of protection class III.
  • Page 59 Baumer Electrical installation NOTICE Ethernet interface damage by inappropriate connectors The camera features TYPE090 Ethernet interface. Using any other connector than TYPE090 could damage the connection. a) Only use cables with TYPE090 connector. Ground connection (1) TYPE090 TYPE110 (Do not use!) 9.0 mm (-0.50 + 0.00)

  • Page 60: Digital Io

    Electrical installation Baumer 7.2.2 Digital IO Camera Customer Device Camera Customer Device IO Power V CC IO Power V CC I OUT Out (n) I OUT IO GND IO GND Digital Output: Low Active Digital Output: High Active Customer Device...

  • Page 61: Gpio (General Purpose Input / Output)

    Baumer Electrical installation 7.2.3 GPIO (General Purpose Input / Output) Line1 and Line2 are GPIOs and can be both Input and Output. Input: (0 ..0.8 V low, 2.0 ... 30 V high). Output:(0 ..0.4 V low, 2.4 ... 3.3 V high), @ 1 mA load (high) / 50 mA sink (low)

  • Page 62: Vcxg.2.Xc

    Electrical installation Baumer VCXG.2.XC 7.3.1 Pin assignment Power supply / Digital IO GPIO (Line2) Power V (12 … 24 VDC ± 20%) IN1 (Line0) GND IN1 Power V (OUT1) OUT1 (Line3) GND (Power, GPIO) GPIO (Line1) Cable core colors (cable not included in delivery) WH –...
  • Page 63 Baumer Electrical installation Ground connection (1) TYPE090 TYPE110 (Do not use!) 9.0 mm (-0.50 + 0.00) 11.0 mm (-0.47 + 0.00) 4.25 mm (-1.00 + 0.25) 4.25 mm (-1.00 + 0.25) Ground female connector (2) TYPE090 9.0 mm (-0.00 + 1.00) 4.5 mm (-0.00 + 1)

  • Page 64: Digital Io

    Electrical installation Baumer 7.3.2 Digital IO Camera Customer Device Camera Customer Device IO Power V CC IO Power V CC I OUT Out (n) I OUT IO GND IO GND Digital Output: Low Active Digital Output: High Active Customer Device...

  • Page 65: Gpio (General Purpose Input / Output)

    Baumer Electrical installation 7.3.3 GPIO (General Purpose Input / Output) Line1 and Line2 are GPIOs and can be both Input and Output. Input: (0 ..0.8 V low, 2.0 ... 30 V high). Output:(0 ..0.4 V low, 2.4 ... 3.3 V high), @ 1 mA load (high) / 50 mA sink (low)

  • Page 66: Vcxg.2.I

    Electrical installation Baumer VCXG.2.I 7.4.1 Pin assignment Stromversorgung / Digital-IO Power V (12 … 24 VDC ± 20%) GND (Power) IN1 (Line0) OUT1 (Line4) IN2 (Line1) OUT2 (Line5) OUT3 (Line6) IN3 (Line2) OUT4 (Line7) IN4 (Line3) GND (IO) Power (IO) Cable core colors (cable not included in delivery) BN –...

  • Page 67: Digital-Io

    Baumer Electrical installation 7.4.2 Digital-IO Camera Pin 1 Power Vcc 12 – 24 V Pin 2 GND (Power) Line0 IN 1 Pin 3 current limiter cable termination Line1 IN 2 Pin 5 current limiter cable termination Pin 8 IN 3...

  • Page 68: Vcxu.2

    Electrical installation Baumer VCXU.2 7.5.1 Pin assignment Digital IO GPIO (Line2) not connected IN1 (Line0) GND IN1 Power V (OUT1) OUT1 (Line3) GND (Power, GPIO) GPIO (Line1) Cable core colors (cable not included in delivery) WH – White BN – Brown GN –...

  • Page 69: Digital Io

    Baumer Electrical installation 7.5.2 Digital IO Camera Customer Device Camera Customer Device IO Power V CC IO Power V CC I OUT Out (n) I OUT IO GND IO GND Digital Output: Low Active Digital Output: High Active Customer Device...

  • Page 70: Gpio (General Purpose Input / Output)

    Electrical installation Baumer 7.5.3 GPIO (General Purpose Input / Output) Line1 and Line2 are GPIOs and can be both Input and Output. Input: (0 ..0.8 V low, 2.0 ... 30 V high). Output:(0 ..0.4 V low, 2.4 ... 3.3 V high), @ 1 mA load (high) / 50 mA sink (low)

  • Page 71: Preventive Maintenance

    Baumer Preventive maintenance Preventive maintenance The sensor is maintenance-free. No special preventive maintenance is required. Regular clean- ing and regular checking of the plug connections are recommended. Cleaning Due to its compact design, the device is characterized by almost maintenance-free operation.
  • Page 72 Preventive maintenance Baumer Tube cover glass For cleaning, use a soft, lint-free cloth to clean the surface of the tube cover glass with a gentle pressure, without scratching. To clean stubborn dirt, commonly available window cleaning agent is recommended. Ensure that no residues of the cleaning agent or scratches remain on the glass. These can permanently damage the reproducibility of the results from the device.

  • Page 73: Troubleshooting

    Baumer Troubleshooting Troubleshooting Support In case of any questions please contact our Technical & Application Support Center. Worldwide Baumer Optronic GmbH Badstrasse 30 DE - 01454 Radeberg www.baumer.com Tel.: +49 (0)3528 4386 845 support.cameras@baumer.com Accessories You can find accessories at the website at: https://www.baumer.com...

  • Page 74: Software

    Baumer Camera Explorer Easy-to-use Baumer Camera Explorer allows for camera evaluation and configuration within the least amount of time. It helps get to know and try the diversified functions of the Baumer cam- eras for configuration to the application. ®...

  • Page 75: Genicam Camera Features

    Baumer GenICam Camera Features GenICam Camera Features A GenICam™-compliant XML-description file presents the camera's Features. The following chapter describes all included and accessible functions. Most of the camera's functions are standardized in GenICam™ SFNC and must use the name defined in there. Particular Fea- tures, which cannot be assigned to an existing GenICam™...

  • Page 76: Acquisitionframecount

    GenICam Camera Features Baumer 11.1.2 AcquisitionFrameCount Number of frames to acquire in MultiFrame Acquisition mode. Name AcquisitionFrameCount Category AcqusitionControl Interface IInteger Access Read / Write Unit Values 1 - 65535 (Increment: 1) 11.1.3 AcquisitionFrameRate Controls the acquisition rate (in Hertz) at which the frames are captured.

  • Page 77: Acquisitionmode

    Baumer GenICam Camera Features 11.1.5 AcquisitionMode Sets the acquisition mode of the device. It defines mainly the number of frames to capture dur- ing an acquisition and the way the acquisition stops. Name AcquisitionMode Category AcqusitionControl Interface IEnumeration Access Read / Write...

  • Page 78: Acquisitionstatusselector

    GenICam Camera Features Baumer 11.1.8 AcquisitionStatusSelector Selects the internal acquisition signal to read using AcquisitionStatus. Name AcquisitionStatusSelector Category AcqusitionControl Interface IEnumeration Access Read / Write Unit Values Acquisition Ac- Device is currently doing an acquisition of one or many frames.

  • Page 79: Exposuremode

    Baumer GenICam Camera Features 11.1.11 ExposureMode Defines the operation mode of Exposure. Name ExposureMode Category AcqusitionControl Interface IEnumeration Access Read / Write Unit Values Timed Time-controlled exposure. Exposure time is configured using the ExposureTime or ExposureAuto function and started with FrameStart or LineStart.
  • Page 80 GenICam Camera Features Baumer INFO Sequencer will not be accessible if function ShortExposureTimeEnable is enabled. VCXG.2 texposure min tnon-selectable [μsec] range1) texposure max [sec] Monochrom VCXG.2-13M VCXG.2-15M VCXG.2-25M VCXG.2-32M VCXG.2-51M VCXG.2-51MP VCXG.2-65M.R 110* / 21** VCXG.2-82M 4 - 22 μs VCXG.2-124M VCXG.2-127M...
  • Page 81 Baumer GenICam Camera Features VCXG.2.XC texposure min tnon-selectable [μsec] range1) texposure max [sec] Monochrom VCXG.2-51M.XC VCXG.2-241M.XC 4 - 38 μs Area (ExposureTimeGapMin – ExposureTimeGapMax) only relevant if ShortExposure- TimeEnable is enabled VCXG.2.I texposure min tnon-selectable [μsec] range1) texposure max [sec] Monochrom VCXG.2-15M.I...

  • Page 82: Exposuretimegapmax

    GenICam Camera Features Baumer texposure min [μsec] texposure max [sec] VCXU.2-50.MP VCXU.2-51.M VCXU.2-65.M.R 75* / 14** VCXU.2-123.M VCXU.2-201.M.R 29* / 29** Color VCXU.2-13.C VCXU.2-15.C VCXU.2-31.C VCXU.2-32.C VCXU.2-50.C VCXU.2-51.C VCXU.2-65.C.R 75* / 14** VCXU.2-123.C VCXU.2-201.C.R 29* / 29** *) Shutter Mode: Global Reset **)Shutter Mode: Rolling Shutter 11.1.13...

  • Page 83: Readoutmode

    Baumer GenICam Camera Features 11.1.15 ReadoutMode Specifies the operation mode of the readout for the acquisition. Image acquisition consists of two separate procedures carried out in succession. Exposing the pixels on the photosensitive surface of the sensor is only the first part of the image acquisition process.

  • Page 84: Triggeractivation

    GenICam Camera Features Baumer 11.1.17 TriggerActivation Specifies the activation mode of the trigger. Name TriggerActivation Category AcqusitionControl Interface IEnumeration Access Read / Write Unit Values FallingEdge Specifies that the trigger is considered valid on the falling edge of the source signal.

  • Page 85: Triggeroverlap

    Baumer GenICam Camera Features 11.1.20 TriggerOverlap Specifies the type trigger overlap permitted with the previous frame. Name TriggerOverlap Category AcqusitionControl Interface IEnumeration Access Read / Write Unit Values Read Out Trigger is accepted immediately after the exposure period. 11.1.21 TriggerSelector Selects the type of trigger to configure.

  • Page 86: Triggersource

    GenICam Camera Features Baumer 11.1.23 TriggerSource Specifies the internal signal or physical input Line to use as the trigger source. The selected trigger must have its TriggerMode set to On. Name TriggerSource Category AcqusitionControl Interface IEnumeration Access Read / Write...

  • Page 87: Actiondevicekey

    Baumer GenICam Camera Features Example: Triggering multiple cameras The following illustration shows three cameras with synchronous trigger by software application. 11.2.1 ActionDeviceKey Provides the device key that allows the device to check the validity of action commands. The device internal assertion of an action signal is only authorized if the ActionDeviceKey and the action device key value in the protocol message are equal.

  • Page 88: Actiongroupmask

    GenICam Camera Features Baumer 11.2.3 ActionGroupMask Provides the mask that the device will use to validate the action on reception of the action proto- col message. Name ActionGroupMask Category ActionControl Interface IInteger Access Read / Write Unit HexNumber Values 0 - 4294967295 (Increment: 1) 11.2.4...

  • Page 89: Blacklevel

    Unit Values see table(s) below VCXG.2 Camera type BlackLevel Monochrom / Color VCXG.2-13M / VCXG.2-13C 0 ... 63 DN10 VCXG.2-15M / VCXG.2-15C 0 ... 255 DN12 VCXG.2-25M / VCXG.2-25C 0 ... 63 DN10 VCXG.2-32M / VCXG.2-32C 0 ... 255 DN12 VCXG.2-51M / VCXG.2-51C...

  • Page 90: Blacklevelselector

    GenICam Camera Features Baumer Camera type BlackLevel VCXG.2-201M.R.I / VCXG.2-201C.R.I 0 ... 255 DN12 VCXG.2-241M.I / VCXG.2-241C.I 0 ... 255 DN12 VCXU.2 Camera type BlackLevel Monochrom / Color VCXU.2-13.M / VCXU.2-13.C 0 ... 63 DN10 VCXU.2-15.M / VCXU.2-15.C 0 ... 255 DN12 VCXU.2-31.M / VCXU.2-31.C...
  • Page 91 Baumer GenICam Camera Features VCXG.2 Camera type Gain [db] Monochrom / Color VCXG.2-13M / VCXG.2-13C 0 ... 18 / 0 ... 12 VCXG.2-15M / VCXG.2-15C 0 ... 48 VCXG.2-25M / VCXG.2-25C 0 ... 18 / 0 ... 12 VCXG.2-32M / VCXG.2-32C 0 ...

  • Page 92: Gainauto

    GenICam Camera Features Baumer Camera type Gain [db] VCXU.2-50.M / VCXU.2-50.C 0 ... 48 VCXU.2-50.MP 0 ... 48 VCXU.2-51.M / VCXU.2-51.C 0 ... 48 VCXU.2-65.M.R / VCXU.2-65.C.R 0 ... 48 VCXU.2-123.M / VCXU.2-123.C 0 ... 48 VCXU.2-201.M.R / VCXU.2-201.C.R 0 ... 20 11.3.5...

  • Page 93: Gamma

    Baumer GenICam Camera Features 11.3.7 Gamma This function compensates any nonlinearity in human eye light perception. For this correction, the corrected pixel intensity (Y') is calculated from the original intensity of the sensor's pixel (Y ) and correction factor ɣ using the following formula (in oversimplified ver- original ɣ...

  • Page 94: Category: Autofeaturecontrol

    GenICam Camera Features Baumer 11.4 Category: AutoFeatureControl Category containing the functions for automatic adjustment. General Information Various auto functions are available to affect the automatic adjustment of image brightness. Two methods are described below. BrightAutoPriority = ExposureAuto Example 1 Brightness...
  • Page 95 Baumer GenICam Camera Features AutoFeature ROI – General Information Function AutoFeature Region of Interest (ROI) is used to define a so-called Region of Interest ROI. The ROI is a defined range of sensor pixels. This function is used if only the image data (e.g. brightness) of a particular region of the image is of interest.
  • Page 96 GenICam Camera Features Baumer AutoFeature ROI in an ROI INFO AutoFeature ROI can be set in ROI (Category: ImageFormatControl). The settings permitted for AutoFeature ROI are adjusted accordingly. Starting point for AutoFeatureOffsetX and AutoFeatureOffsetY is defined by ROI (Category: Im- ageFormatControl).

  • Page 97: Autofeatureheight

    Baumer GenICam Camera Features 11.4.1 AutoFeatureHeight Height of the selected Auto Feature Region (in pixels). Start AutoFeature ROI End AutoFeature ROI Name AutoFeatureHeight Category AutoFeatureControl Interface IInteger Access Read / Write Unit Values Height [} 158] 11.4.2 AutoFeatureOffsetX Horizontal offset from the origin to the Auto Feature Region (in pixels).

  • Page 98: Autofeatureoffsety

    GenICam Camera Features Baumer 11.4.3 AutoFeatureOffsetY Vertical offset from the origin to the Auto Feature Region (in pixels). Start AutoFeature ROI End AutoFeature ROI Name AutoFeatureOffsetX Category AutoFeatureControl Interface IInteger Access Read / Write Unit Values 0 - depends on AutoFeatureHeight 11.4.4...

  • Page 99: Autofeatureregionselector

    Baumer GenICam Camera Features 11.4.6 AutoFeatureRegionSelector Selects which Region of Interest to be controlled. Function RegionSelector enables devices ca- pable of extracting multiple ROI from a frame out of an image, to configure the functions of those individual regions independently.

  • Page 100: Balancewhiteautostatus

    GenICam Camera Features Baumer 11.4.8 BalanceWhiteAutoStatus Status of BalanceWhiteAuto. Name BalanceWhiteAutoStatus Category AutoFeatureControl Interface IEnumeration Access Read only Unit Values ColorGainsTooHigh The BalanceWhiteAuto calculation failed since at least one of the calculated color gains exceeds the maximum value. Initial BalanceWhiteAuto has never been started.
  • Page 101 Baumer GenICam Camera Features BrightAutoPriority = ExposureAuto Example 1 Brightness GainAutoMaxValue For image 1, increasing bright- Gain ness using ExposureTime will BrightnessAutoNominalValue suffice to achieve the value in BrightnessAutoNominalValue. GainAutoMinValue Example 2 For image 2, increasing bright- ness using ExposureTime will...

  • Page 102: Exposureautomaxvalue

    GenICam Camera Features Baumer 11.4.11 ExposureAutoMaxValue Maximal value of ExposureTime calculable by exposure auto algorithm. Name ExposureAutoMaxValue Category AutoFeatureControl Interface IFloat Access Read / Write Unit µs Values ExposureTime [} 79] 11.4.12 ExposureAutoMinValue Minimal value of ExposureTime calculable by exposure auto algorithm.

  • Page 103: Category: Chunkdatacontrol

    Chunk is camera-generated data packet which is integrated into the Payload every image with m Chunk ode being enabled. This integrated data packet contains different image settings. Baumer GAPI can read out Chunk (Image Info Header). There are three modes: Image Data Only image data is transferred, no Chunk data.

  • Page 104: Chunkenable

    GenICam Camera Features Baumer 11.5.1 ChunkEnable Enables the inclusion of the selected Chunk data in the Payload of the image. INFO The camera must be stopped before this feature can be edited. INFO Use ChunkSelector to select the required Chunk.
  • Page 105 Baumer GenICam Camera Features VCXG.2 Values (Features) Binning (BinningHorizontal, BinningHorizon- ImageControl (BrightnessCorrection, Defect- talMode, BinningSelector, BinningVertical, Bin- PixelCorrection, LUTSelector, LUTEnable, Re- ningVerticalMode) verseX, ReverseY) BlackLevel LineStatusAll CounterValue OffsetX DeviceTemperature OffsetY ExposureTime PixelFormat FrameID SequencerSetActive Gain Timestamp Height Width Image VCXG.2.XC...

  • Page 106: Category: Colortransformationcontrol (Color Cameras Only)

    GenICam Camera Features Baumer VCXU.2 Values (Features) Binning (BinningHorizontal, BinningHorizon- ImageControl (BrightnessCorrection, Defect- talMode, BinningSelector, BinningVertical, Bin- PixelCorrection, LUTSelector, LUTEnable, Re- ningVerticalMode) verseX, ReverseY) BlackLevel LineStatusAll CounterValue OffsetX DeviceTemperature OffsetY ExposureTime PixelFormat FrameID SequencerSetActive Gain Timestamp Height Width Image 11.6 Category: ColorTransformationControl (color cameras only) Category that contains the color transformation control functions.

  • Page 107: Colortransformationauto

    Baumer GenICam Camera Features 11.6.1 ColorTransformationAuto Controls the mode for automatic adjusting the gains of the active transformation matrix. INFO Function ColorTransformationAuto can always be enabled which will make the camera calculate appropriate color matrices. If the range of the estimated illumination to the measured reference illuminations exceeds a cer- tain threshold, a white balance is triggered even if BalanceWhiteAuto = off.

  • Page 108: Colortransformationfactorylistselector

    GenICam Camera Features Baumer 11.6.3 ColorTransformationFactoryListSelector Selects the OptimizedMatrix for the desired color temperature. All calculated color values are based on the sRGB color space. OptimizedMatrix parameterization will also set ColorGains for the light-matching white point. INFO We recommend to carry out a white balance after setting a matrix.

  • Page 109: Colortransformationvalue

    Baumer GenICam Camera Features 11.6.6 ColorTransformationValue Represents the selected Gain within the Transformation matrix. Name ColorTransformationValue Category ColorTransformationControl Interface IFloat Access Read only Unit Values -8.0 – 8.0 (Increment: 1.00) 11.6.7 ColorTransformationValueSelector Selects Gain of Transformation matrix to be accessed to within the selected Color Transforma- tion module.

  • Page 110: Countereventactivation

    GenICam Camera Features Baumer 11.7.2 CounterEventActivation Selects the activation mode for the Event Source signal. Name CounterEventActivation Category CounterAndTimerControl Interface IEnumeration Access Read / Write Unit Values RisingEdge Counts on the rising edge of the signal. FallingEdge Counts on the falling edge of the signal.

  • Page 111: Counterreset

    Baumer GenICam Camera Features 11.7.4 CounterReset Executes software reset and start of the selected Counter. Counter starts counting events im- mediately after reset unless Counter Trigger trigger is active. CounterReset is to reset Counter independently of CounterResetSource. To disable Counter temporarily, set Coun- terEventSource = Off.

  • Page 112: Counterselector

    GenICam Camera Features Baumer VCXG.2 CounterResetSource Counter1End Line1 Counter2End Line2 Line0 VCXG.2.XC CounterResetSource Counter1End Line1 Counter2End Line2 Line0 VCXG.2.I CounterResetSource Counter1End Line2 Counter2End Line3 Line0 Line1 VCXU.2 CounterResetSource Counter1End Line1 Counter2End Line2 Line0 11.7.7 CounterSelector Selects which Counter to configure.

  • Page 113: Countervalue

    11.7.10 FrameCounter FrameCounter is part of Chunk (Baumer Image Info Header) and added to every frame if Chunk Mode is enabled. It is generated by the hardware and can be used to verify that each of the camera's images is transmitted to the PC and received in the right order.

  • Page 114: Timerdelay

    GenICam Camera Features Baumer 11.7.11 TimerDelay Defines the delay time (in microseconds) to be applied at trigger reception prior to starting the Timer. Name TimerDelay Category CounterAndTimerControl Interface IFloat Access Read / Write Unit µs Values 0 ... 2,000,000.000000 (Increment: 1.00) 11.7.12...

  • Page 115: Timertriggeractivation

    Baumer GenICam Camera Features 11.7.14 TimerTriggerActivation Selects the trigger activation mode to start the Timer. Name TimerTriggerActivation Category CounterAndTimerControl Interface IEnumeration Access Read / Write Unit Values RisingEdge Starts counting on the rising edge of the selected trigger sig- nal.

  • Page 116: Category: Customdatacontrol

    GenICam Camera Features Baumer VCXG.2.I TimerTriggerSource Action1 Line2 ExposureEnd Line3 ExposureStart FrameTransferSkipped Software Line0 TriggerSkipped Line1 VCXU.2 TimerTriggerSource ExposureEnd ExposureStart Software FrameTransferSkipped TriggerSkipped Line0 11.8 Category: CustomDataControl The category contains the custom data specific features. 11.8.1 CustomData The feature holds one byte of custom special data.

  • Page 117: Customdataselector

    Baumer GenICam Camera Features 11.8.3 CustomDataSelector The feature selects the index of the custom data byte array. Name CustomData Category CustomDataControl Interface IInteger Access Read / Write Unit Values 0 ... 127 (Increment: 1) 11.9 Category: DeviceControl Category for device information and control.

  • Page 118: Devicefamilyname

    GenICam Camera Features Baumer 11.9.3 DeviceFamilyName Identifier of the product family of the device. Name DeviceFamilyName Category DeviceControl Interface IString Access Read only Unit Values device family name 11.9.4 DeviceFirmwareVersion Version of the firmware in the device. Name DeviceFirmwareVersion Category...

  • Page 119: Devicelinkselector

    Baumer GenICam Camera Features 11.9.7 DeviceLinkSelector Selects which Link of the device to control. Generally, a device has only one Link that can be composed of one or many connections. But if there are many, this selector can be used to target a particular Link of the device with certain functions.

  • Page 120: Devicemanufacturerinfo

    GenICam Camera Features Baumer 11.9.10 DeviceManufacturerInfo Manufacturer information about the device. The content might look as follows: Firmware (F) / FPGA (C) / BL3-Version (BL) Name DeviceManufacturerInfo Category DeviceControl Interface IString Access Read only Unit Values e. g. F:00007F9A/C:0180802D/BL3.8:00000081 11.9.11 DeviceModelName Model name of the device.

  • Page 121: Devicereset

    Baumer GenICam Camera Features 11.9.13 DeviceReset Resets the device to its power up state. INFO The execution of this feature may take several seconds. Name DeviceReset Category DeviceControl Interface IComand Access Write only Unit Values 11.9.14 DeviceResetToDeliveryState By executing this feature, the camera is set to the factory settings.

  • Page 122: Devicesfncversionminor

    GenICam Camera Features Baumer 11.9.16 DeviceSFNCVersionMinor Minor version of Standard Features Naming Convention used to create the device GenICam XML(x.X.x.). Name DeviceSFNCVersionMinor Category DeviceControl Interface IInteger Access Read only Unit Values 0 ... 9223372036854775807 (Increment: 1) 11.9.17 DeviceSFNCVersionSubMinor Sub version of Standard Features Naming Convention, used to create the device GenICam XML(x.x.X).

  • Page 123: Deviceserialnumber

    Baumer GenICam Camera Features 11.9.20 DeviceSerialNumber Device`s serial number. This string is a unique identifier of the device. Name DeviceSerialNumber Category DeviceControl Interface IString Access Read only Unit Values e.g. 1117281217 11.9.21 DeviceStreamChannelCount Indicates the number of streaming channels supported by the device.

  • Page 124: Devicestreamchanneltype

    GenICam Camera Features Baumer 11.9.24 DeviceStreamChannelType Reports the type of the Stream Channel. Name DeviceStreamChannelType Category DeviceControl Interface IEnumeration Access Read only Unit Values Receiver Data stream receiver channel. Transmitter Data stream transmitter channel. 11.9.25 DeviceTLType Transport Type of the device.

  • Page 125: Devicetlversionsubminor

    Baumer GenICam Camera Features 11.9.28 DeviceTLVersionSubMinor ® Minor version of the Transport Layer (GigE Vision version) of the device. Name DeviceTLVersionSubMinor Category DeviceControl Interface IInteger Access Read only Unit Values ≥ 0 (x.x.X) 11.9.29 DeviceTemperature Device temperature in degrees Celsius (°C). Measured at the location selected by DeviceTem- peratureSelector.

  • Page 126: Devicetemperaturestatus

    GenICam Camera Features Baumer 11.9.32 DeviceTemperatureStatus Returns the current temperature status of the device. Name DeviceTemperatureStatus Category DeviceControl Interface IEnumeration Access Read only Unit Values Exceeded Device operates in critical temperature range. High Device operates in increased temperature range. Normal Device operates in normal temperature range.

  • Page 127: Devicetype

    Baumer GenICam Camera Features Values ExceededToNor- Temperature threshold for transition when going back from status Exceeded to Normal. HighToExceeded Temperature threshold for transition from status High to status Exceeded. NormalToHigh Temperature threshold for transition from status Normal to status High.

  • Page 128: Deviceversion

    GenICam Camera Features Baumer 11.9.38 DeviceVersion Version of the device. Name DeviceVersion Category DeviceControl Interface IString Access Read only Unit Values e.g. R2.0.0 11.9.39 ReadOutTime Readout time of one image from the sensor in µs, with the current image settings.

  • Page 129: Timestamplatchvalue

    Baumer GenICam Camera Features 11.9.41 TimestampLatchValue Returns the saved value of counter Timestamp. Name TimestampLatchValue Category DeviceControl Interface IInteger Access Read only Unit Values 0 ... 9223372036854775807 (Increment: 8 (GigE) / 10 (USB)) 11.9.42 USB2SupportEnable (USB cameras only) Enable or disable the streaming support for USB 2.0.

  • Page 130: Category: Digitaliocontrol

    GenICam Camera Features Baumer 11.10 Category: DigitalIOControl Category that contains the digital input and output control functions. Trigger – General Information Trigger signals are used to synchronize the camera exposure and a machine cycle or, in case of a software trigger, to take images at predefined time intervals. Different trigger sources can be used here.
  • Page 131 Baumer GenICam Camera Features Trigger Source (examples of possible trigger sources) Each trigger source must be activated separately. When the trigger mode (TriggerMode) is acti- vated, the hardware trigger is activated by default. Debouncer (LineDebouncerHighTimeAbs / LineDebouncerLowTimeAbs) The basic idea behind this functions was to separate interfering signals (short peaks) from valid square wave signals, which can be important in industrial environments.

  • Page 132: Linedebouncerhightimeabs

    GenICam Camera Features Baumer Incoming signals (valid and invalid) high 4.5V ∆t ∆t ∆t ∆t ∆t ∆t Debouncer DebounceHigh DebounceLow Filtered signal high 4.5V ∆t - high time of the signal - user-defined debouncer delay for state high DebounceHigh - user-defined debouncer delay for state low DebounceLow 11.10.1...

  • Page 133: Lineformat

    Baumer GenICam Camera Features 11.10.3 LineFormat Controls the current electrical format of the selected physical Input or Output. LineFormat switchover will adapt the output behavior to the respective system. INFO In all modes the supply voltage for the Outputs (Pin 11, 12) must to be connected for function!

  • Page 134: Lineinverter

    GenICam Camera Features Baumer Line Format Description Circuit Power (IO) Tri-State In this mode, the output is disabled. Camera Output GND (IO) 11.10.4 LineInverter Controls signal inversion of the selected line Input or Output. Name LineInverter Category DigitalIOControl Interface IBoolean...
  • Page 135 Baumer GenICam Camera Features Function Pulse Width Modulated Outputs (PWM) is for lighting system control or control of any illumination directly connected to the camera. The set LineSource serves as controller signal. NOTICE Erroneous settings can destroy the illumination! The outputs of the camera are protected against destruction. Please follow the information in the data sheets for your illumination.

  • Page 136: Linepwmduration

    GenICam Camera Features Baumer 11.10.7 LinePWMDuration Sets the pulse time in μs, with which the illumination is pulsed. Name LinePWMDuration Category DigitalIOControl Interface IInteger Access Read / Write Unit µs Values 1 - 5000 (Increment: 1) 11.10.8 LinePWMDutyCycle Sets the duty cycle (ratio of pulse duration to period time duration) in %. This value is specified by the connected illumination.

  • Page 137: 11Linepwmmode

    Baumer GenICam Camera Features 11.10.11 LinePWMMode Selects the PWM mode of the selected Output line. Name LinePWMMode Category DigitalIOControl Interface IEnumeration Access Read / Write Unit Values Fixed Frequency The selected Output generates a permanent pulse fre- quency beginning with every transition from 0 to 1 and end- ing with every transition from 1 to 0.

  • Page 138: 13Linepwmperiodtime

    GenICam Camera Features Baumer 11.10.13 LinePWMPeriodTime Entire period duration in μs. Name LinePWMPeriodTime Category DigitalIOControl Interface IInteger Access Read only Unit µs Values PWM setting -specific. 11.10.14 LineSelector Selects the physical line (or pin) of the external device connector to configure.

  • Page 139: 15Linesource

    Baumer GenICam Camera Features 11.10.15 LineSource Selects which internal signals are output at the selected Line. Name LineSource Category DigitalIOControl Interface IEnumeration Access Read / Write Unit Values see table(s) below Linesource VCXG.2 VCXG.2XC VCXG.2.I VCXU.2 ExposureActive ■ ■ ■...
  • Page 140 GenICam Camera Features Baumer ExposureActive This signal is managed by exposure of the sensor. Furthermore, the falling edge of the ExposureActive signal can be used to trigger a movement of the inspected objects. Due to this fact, the span time used for the sensor readout treadout can be used optimally in industrial environments.

  • Page 141: 16Linestatus

    Baumer GenICam Camera Features 11.10.16 LineStatus Returns the current status of the selected Input or Output. Name LineStatus Category DigitalIOControl Interface IBoolean Access Read only Unit Values true = 1 (On) false = 0 (Off) 11.10.17 LineStatusAll Returns the current status of all available Line signals at time of polling in a single bitfield.

  • Page 142: 19Useroutputvalue

    GenICam Camera Features Baumer 11.10.19 UserOutputValue Sets the value of the bit selected by UserOutputSelector. Name UserOutputValue Category DigitalIOControl Interface IBoolean Access Read / Write Unit Values true = 1 (On) false = 0 (Off) 11.10.20 UserOutputValueAll Sets the values of all bits under the User Output register.

  • Page 143: Category: Eventcontrol

    Baumer GenICam Camera Features 11.11 Category: EventControl This chapter describes how to control the Events generation for host application. Event is a message sent to the host application to notify the presence of an internal event. General Information ® The asynchronous message channel is described in the GigE Vision standard and can option- ally be used to signal events.
  • Page 144 GenICam Camera Features Baumer Event: TriggerOverlapped This Event is active as long as the sensor is under exposure with parallel read out, i.e. camera operation utilizes Overlapped. A valid trigger signal event outside a sensor readout operation will change the TriggerOver- lapped signal to Low.
  • Page 145 Baumer GenICam Camera Features Event: TransferBufferReady Event is only output at TriggerMode. Signals buffer availability. Trigger exposure(n) exposure(n+1) Exposure readout(n) readout(n+1) Readout notready TriggerReady Event: TransferBufferReady BufferReady Transmission Event: DeviceTemperaturStatusChanged To prevent damage on the hardware due to high temperatures, the camera features emergency shutdown.

  • Page 146: Eventnotification

    GenICam Camera Features Baumer temperature curve Event:DeviceTemperature- StatusChanged HighToExceed fixed value (camera shutdown if exceeded) Cooling measures recommended Event:DeviceTemperature- StatusChanged NormalToHigh Event:DeviceTemperature- freely programmable value StatusChanged ExceedToNormal (Device Temperature < ExceededToNormal) freely programmable value Time 11.11.1 EventNotification Activate or deactivate the notification to the host application of the occurrence of the selected Event.

  • Page 147: Losteventcounter

    Baumer GenICam Camera Features EventSelector VCXG.2 VCXG.2XC VCXG.2.I VCXU.2 GigEVisionHeartbeatTime- ■ ■ ■ □ Line0..3 FallingEdge ■ ■ ■ (0..7) ■ Line0..3 RisingEdge ■ ■ ■ (0..7) ■ TransferBufferFull ■ ■ ■ ■ TransferBufferReady ■ ■ ■ ■ TriggerOverlapped ■...
  • Page 148 GenICam Camera Features Baumer Start ROI End ROI ROI Readout In the illustration below, the readout time would decrease to 40% of a full frame readout. Readout lines Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | Vp1.0...
  • Page 149 Higher sensi- tivity enables shorter exposure times. Baumer cameras support three types of Binning - vertical, horizontal and bidirectional. In unidirectional Binning, vertically or horizontally neighboring pixels are clustered and reported to the software as a single "superpixel".
  • Page 150 GenICam Camera Features Baumer Color Binning Color Binning is calculating on the camera (no higher frame rates) – The sensor does not sup- port this binning operation. Color calculated pixel formats In pixel formats other than RAW formats (e.g. RGB8), binning will add the three calculated pixel color values (R, G, B) to those of the corresponding neighbor pixel.

  • Page 151: Binninghorizontal

    Baumer GenICam Camera Features RAW Pixel formats RAW pixel formats (e.g. of BayerRG8) cluster the color values of neighboring pixels of the same color. Binning Illustration without 11.12.1 BinningHorizontal Number of horizontal photo-sensitive cells to combine together. This increases the intensity (or signal to noise ratio) of the pixels and reduces the horizontal resolution (width) of the image.
  • Page 152 GenICam Camera Features Baumer BinningSelector BinningSelector Camera type [Region0] [Sensor] Monochrom VCXG.2-13M 1 ... 2 1 ... 1 VCXG.2-15M 1 ... 2 1 ... 2* VCXG.2-25M 1 ... 2 1 ... 1 VCXG.2-32M / .I 1 ... 2 1 ... 1 VCXG.2-51M / .XC / .I...

  • Page 153: Binninghorizontalmode

    Baumer GenICam Camera Features VCXU.2 INFO With VCXU.2-15M, VCXU.2-123M binning Binning is calculated in the sensor. In contrast to Bin- ning in the FPGA, sensor Binning enables higher frame rates. BinningSelector BinningSelector Camera type [Region0] [Sensor] Monochrom VCXU.2-13.M 1 ... 2 1 ...

  • Page 154: Binningselector

    With VCXG.2-15M,Binning is calculated in the sensor. In contrast to Binning in the FPGA, sen- sor Binning allows for higher frame rates. BinningSelector BinningSelector Camera type [Region0] [Sensor] Monochrom VCXG.2-13M 1 ... 2 1 ... 1 VCXG.2-15M 1 ... 2 1 ... 2* VCXG.2-25M 1 ... 2 1 ...
  • Page 155 Baumer GenICam Camera Features BinningSelector BinningSelector Camera type [Region0] [Sensor] VCXG.2-204M 1 ... 2 1 ... 2 VCXG.2-241M / .XC / .I 1 ... 2 1 ... 2 Color VCXG.2-13C 1 ... 2 1 ... 1 VCXG.2-15C 1 ... 2 1 ...

  • Page 156: Binningverticalmode

    That is the category that contains functions to control the calibration of the four polarized light channels. Baumer polarization cameras feature a metal grid-coated sensor filtering the polarization infor- mation onto 4 neighboring pixels. The polarization angle is filtered with an alignment of 0°, 45°, 90°...

  • Page 157: Calibrationangleofpolarizationoffset

    Baumer GenICam Camera Features Baumer GAPI Baumer GAPI Baumer GAPI Baumer GAPI v2.9 v2.10 v2.11 v2.12 UNPOL 11.12.6.1 CalibrationAngleOfPolarizationOffset Adds a calibration offset to compensate for an individual "roll" angle of the camera, introduced by mounting tolerances. The offset is added to all type of output data that incorporates an angle, like false color representation and angle of polarization data.

  • Page 158: Calibrationmatrixvalueselector

    Unit Values see table(s) below VCXG.2 / VCXG.2 / VCXG.2.I Camera type Values [Pixel] Monochrom VCXG.2-13M 1 ... 1024 (Increment: 1) VCXG.2-15M 1 ... 1080 (Increment: 1) VCXG.2-25M 1 ... 1200 (Increment: 1) VCXG.2-32M / .I 1 ... 1536 (Increment: 1) VCXG.2-51M / .XC / .I...
  • Page 159 Baumer GenICam Camera Features Camera type Values [Pixel] VCXG.2-82M / .I 1 ... 2832 (Increment: 1) VCXG.2-124M 1 ... 3000 (Increment: 1) VCXG.2-127M / .I 1 ... 2992 (Increment: 1) VCXG.2-201M.R / .I 2 ... 3648 (Increment: 2) VCXG.2-204M 1 ... 4496 (Increment: 1) VCXG.2-241M / .XC / .I...

  • Page 160: Heightmax

    ImageFormatControl Interface IInteger Access Read only Unit Values see table(s) below VCXG.2 / VCXG.2 / VCXG.2.I Camera type Values [Pixel] Monochrom VCXG.2-13M 1024 VCXG.2-15M 1080 VCXG.2-25M 1200 VCXG.2-32M / .I 1536 VCXG.2-51M / .XC / .I 2048 VCXG.2-51MP 2048 VCXG.2-65M.R 2048 VCXG.2-82M / .I...
  • Page 161 Baumer GenICam Camera Features Camera type Values [Pixel] VCXG.2-201C.R / .I 3648 VCXG.2-204C 4496 VCXG.2-241C / .I 4592 VCXU.2 Camera type Values [Pixel] Monochrom VCXU.2-13.M 1024 VCXU.2-15.M 1080 VCXU.2-31.M 1536 VCXU.2-32.M 1536 VCXU.2-50.M 2048 VCXU.2-50.MP 2048 VCXU.2-51.M 2048 VCXU.2-65.M.R 2048 VCXU.2-123.M...

  • Page 162: Offsetx

    GenICam Camera Features Baumer 11.12.9 OffsetX Horizontal offset from the origin to the region of interest (in pixels). INFO The sum of OffsetX and Width must be smaller or equal than WidthMax. Start ROI End ROI Name OffsetX Category ImageFormatControl...

  • Page 163: 11Pixelformat

    Two bytes are needed for transmitting more than 8 bits per pixel - even if the second byte is not completely filled with data. In order to save bandwidth, the packed formats were introduced to Baumer cameras. In this formats, the unused bits of one pixel are filled with data from the next pixel.
  • Page 164 The camera must be stopped before this feature can be edited. Name PixelFormat Category ImageFormatControl Interface IEnumeration Access Read / Write Unit Values see table(s) below VCXG.2 / VCXG.2 / VCXG.2.I Camera type Monochrome VCXG.2-13M ■ ■ □ □ □ □ □ □ □ □ VCXG.2-15M ■ ■ ■...
  • Page 165 Baumer GenICam Camera Features Camera type Color VCXG.2-13C ■ ■ □ □ ■ ■ □ □ ■ ■ VCXG.2-15C ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ VCXG.2-25C ■ ■ □ □ ■ ■ □ □ ■ ■...

  • Page 166: 12Reversex (Mono Cameras / Pixel Formats Only)

    GenICam Camera Features Baumer Camera type VCXU.2-65.C.R ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ VCXU.2-123.C ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ VCXU.2-201.C.R ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ 11.12.12 ReverseX (mono cameras / pixel formats only) Flips the image in horizontal direction.

  • Page 167: 14Sensorheight

    Baumer GenICam Camera Features 11.12.14 SensorHeight Effective height of the sensor in pixels. Name SensorHeight Category ImageFormatControl Interface IInteger Access Read only Unit Values 0 ... 65535 (Increment: 1) 11.12.15 SensorName Product name of the imaging sensor. Name SensorName Category...

  • Page 168: 18Sensorshuttermode

    GenICam Camera Features Baumer 11.12.18 SensorShutterMode Sets the sensor shutter mode of the camera. The sensor shutter mode depends on the Trigger- Mode. Name SensorShutterMode Category ImageFormatControl Interface IEnumeration Access Read / Write Unit Values GlobalReset The shutter opens at the same time for all pixels but ends in a sequential manner.

  • Page 169: 19Sensorwidth

    Baumer GenICam Camera Features Rolling Shutter - General Information INFO Due to technical issues of Rolling Shutter, flash control related to ExposureTime does not make sense. Such cameras should be used in a continuously illuminated environment. Cameras with Rolling Shutter sensor and enabled shutter mode RollingShutter start exposure at an offset which corresponds to the readout time of each frame line.

  • Page 170: 20Testpattern

    GenICam Camera Features Baumer 11.12.20 TestPattern Selects the type of test pattern that is generated by the device as image source. Name TestPattern Category ImageFormatControl Interface IEnumeration Access Read / Write Unit Values see table(s) below GreyDiagonalRamp Image is filled diagonally with an image that goes from the darkest possible value to the brightest.

  • Page 171: 21Testpatterngeneratorselector

    Unit Values see table(s) below VCXG.2 / VCXG.2 / VCXG.2.I Camera type Values [Pixel] Monochrom VCXG.2-13M 24 ... 1280 (Increment: 8) VCXG.2-15M 16 ... 1440 (Increment: 32) VCXG.2-25M 48 ... 1920 (Increment: 16) VCXG.2-32M / .I 16 ... 2048 (Increment: 16) VCXG.2-51M / .XC / .I...
  • Page 172 GenICam Camera Features Baumer Camera type Values [Pixel] VCXG.2-82M / .I 32 ... 2848 (Increment: 32) VCXG.2-124M 16 ... 4096 (Increment: 16) VCXG.2-127M / .I 32 ... 4096 (Increment: 32) VCXG.2-201M.R / .I 32 ... 5472 (Increment: 32) VCXG.2-204M 32 ... 4480 (Increment: 32) VCXG.2-241M / .XC / .I...

  • Page 173: 23Widthmax

    ImageFormatControl Interface IInteger Access Read only Unit Values see table(s) below VCXG.2 / VCXG.2 / VCXG.2.I Camera type Values [Pixel] Monochrom VCXG.2-13M 1280 VCXG.2-15M 1440 VCXG.2-25M 1920 VCXG.2-32M / .I 2048 VCXG.2-51M / .XC / .I 2448 VCXG.2-51MP 2448 VCXG.2-65M.R 3072 VCXG.2-82M / .I...

  • Page 174: Category: Lutcontrol

    GenICam Camera Features Baumer Camera type Values [Pixel] VCXG.2-127C / .I 4096 VCXG.2-201C.R / .I 5472 VCXG.2-204C 4480 VCXG.2-241C / .I 5312 VCXU.2 Camera type Values [Pixel] Monochrom VCXU.2-13.M 1280 VCXU.2-15.M 1440 VCXU.2-31.M 2048 VCXU.2-32.M 2048 VCXU.2-50.M 2448 VCXU.2-50.MP 2448 VCXU.2-51.M...
  • Page 175 „Cold Pixel“ Correction Algorithm (Pixel Correction) On Baumer cameras the problem of defect pixels is solved as follows: Possible defect pixels are identified during the production process of the camera. The coordinates of these pixels are stored in the factory settings of the camera.

  • Page 176: Defectpixelcorrection

    GenICam Camera Features Baumer Add Defect Pixel to Defect Pixel List with Baumer Camera Explorer INFO The addition of defect pixels must be done in full frame (without Binning / Width / Height / Off- setX / OffsetY), in raw data format and without activated color calculation.

  • Page 177: Defectpixellistentryposx

    Baumer GenICam Camera Features 11.13.3 DefectPixelListEntryPosX X position of the defect pixel. Name DefectPixelListEntryPosX Category LUTControl Interface IInteger Access Read / Write Unit Values 0 ... Resolution of the sensor in X-direction (Increment: 1) 11.13.4 DefectPixelListEntryPosY Y position of the defect pixel.

  • Page 178: Lutcontent

    GenICam Camera Features Baumer 11.13.7 LUTContent Describes the content of the selected LUT. Name LUTContent Category LUTControl Interface IEnumeration Access Read / Write Unit Values Gamma The content of the selected LUT is defined by the parameter in the Gamma feature.

  • Page 179: 10Lutselector

    Baumer GenICam Camera Features 11.13.10 LUTSelector Selects which LUT to control. Name LUTSelector Category LUTControl Interface IEnumeration Access Read / Write Unit Values Luminance Select Luminance LUT. 11.13.11 LUTValue Returns the value at entry LUTIndex of the LUT selected by LUTSelector.

  • Page 180: Category: Sequencercontrol

    GenICam Camera Features Baumer 11.15 Category: SequencerControl Category for the Sequencer Control functions. The Sequencer enables acquisition of an image series with automated camera re-parameteriza- tion based on events and signals. For doing so, the camera parameterization of each step is stored in so called Sequencer Sets.

  • Page 181: Sequencerconfigurationmode

    Baumer GenICam Camera Features Sequencer configuration In order to avoid overwriting current camera settings during Sequencer configuration, the cam- era requires reparameterization to SequencerConfigurationMode. If camera is set to SequencerConfigurationMode, individual Sequencer Sets can be selected via SequencerSetSelector for configuration and saved by executing SequencerSetSave.

  • Page 182: Sequencermode

    GenICam Camera Features Baumer Values (Features) CounterEventSource OffsetY CounterResetActivation TriggerMode CounterResetSource UserOutputValue ExposureMode UserOutputValueAll ExposureTime Width Gain 11.15.4 SequencerMode Controls if Sequencer is enabled. INFO To use this feature, the features BalanceWhiteAuto (color cameras only) and SequencerConfig- urationMode must be = off.

  • Page 183: Sequencersetload

    Baumer GenICam Camera Features 11.15.7 SequencerSetLoad Loads the Sequencer Set selected with SequencerSetSelector. Name SequencerSetLoad Category SequencerControl Interface ICommand Access Write only Unit Values 11.15.8 SequencerSetNext Specifies the next Sequencer Set. Name SequencerSetNext Category SequencerControl Interface IInteger Access Read / Write...

  • Page 184: 11Sequencersetstart

    GenICam Camera Features Baumer 11.15.11 SequencerSetStart Sets the start Sequencer Set, which is the first set used. Name SequencerSetStart Category SequencerControl Interface IInteger Access Read / Write Unit Values 0 ... 127 (Increment: 1) 11.15.12 SequencerTriggerActivation Defines the signals edge to trigger Sequencer.

  • Page 185: Category: Testcontrol

    Baumer GenICam Camera Features Values Line1 Specifies Line1 as external trigger source. Line2 Specifies Line2 as external trigger source. Line3* Specifies Line3 as external trigger source. ExposureActive Starts receiving Exposure Active. ReadOutActive Starts receiving Read Out Active. Timer1End Starts receiving Timer End.

  • Page 186: Category: Transportlayercontrol → Gigevision

    GenICam Camera Features Baumer 11.17.2 Category: TransportLayerControl → GigEVision Category that contains the features pertaining to the GigE Vision transport layer of the device. 11.17.2.1 GVSPConfigurationBlockID64Bit Enables the 64 bit block ID length. Name GVSPConfigurationBlockID64Bit Category TansportLayerControl → GigEVision Interface...

  • Page 187: Gevcurrentipaddress

    Baumer GenICam Camera Features 11.17.2.4 GevCurrentIPAddress Reports the IP address for the given logical link. Name GevCurrentIPAddress Category TansportLayerControl → GigEVision Interface IInteger Access Read only Unit Values IP address 11.17.2.5 GevCurrentIPConfigurationDHCP Controls whether the DHCP IP configuration scheme is activated on the given logical link.

  • Page 188: Gevcurrentsubnetmask

    GenICam Camera Features Baumer 11.17.2.8 GevCurrentSubnetMask Reports the subnet mask of the given logical link. Name GevCurrentSubnetMask Category TansportLayerControl → GigEVision Interface IInteger Access Read only Unit Values IP address 11.17.2.9 GevFirstURL Indicates the first URL to the GenICam XML device description file. The First URL is used as the first choice by the application to retrieve the GenICam XML device description file.

  • Page 189: Gevgvcppendingack

    Baumer GenICam Camera Features 11.17.2.12 GevGVCPPendingAck Enables the generation of PENDING_ACK. Name GevGVCPPendingAck Category TansportLayerControl → GigEVision Interface IBoolean Access Read / Write Unit Values true = 1 (On) false = 0 (Off) 11.17.2.13 GevIPConfigurationStatus Reports the current IP configuration status.

  • Page 190: Gevmacaddress

    GenICam Camera Features Baumer 11.17.2.15 GevMACAddress MAC address of the logical link. Name GevMACAddress Category TansportLayerControl → GigEVision Interface IInteger Access Read only Unit Values ≥ 0 11.17.2.16 GevMCDA Controls the destination IP address for the message channel. Name GevMCDA Category TansportLayerControl →...

  • Page 191: Gevmcsp

    Baumer GenICam Camera Features 11.17.2.19 GevMCSP This feature indicates the source port for the message channel. Name GevMCSP Category TansportLayerControl → GigEVision Interface IInteger Access Read only Unit Values ≥ 0 11.17.2.20 GevMCTT Provides the transmission timeout value in milliseconds.

  • Page 192: Gevpersistentdefaultgateway

    GenICam Camera Features Baumer 11.17.2.23 GevPersistentDefaultGateway Controls the persistent default gateway for this logical link. It is only used when the device boots with the Persistent IP configuration scheme. Name GevPersistentDefaultGateway Category TansportLayerControl → GigEVision Interface IInteger Access Read / Write...

  • Page 193: Gevprimaryapplicationsocket

    Baumer GenICam Camera Features 11.17.2.27 GevPrimaryApplicationSocket Returns the UDP source port of the primary application. Name GevPrimaryApplicationSocket Category TansportLayerControl → GigEVision Interface IInteger Access Read only Unit Values ≥ 0 11.17.2.28 GevPrimaryApplicationSwitchoverKey Controls the key to use to authenticate primary application switchover requests.

  • Page 194: Gevscpd

    GenICam Camera Features Baumer 11.17.2.31 GevSCPD Controls the delay (in timestamp counter unit) to insert between each packet for this stream channel. This can be used as a crude flow-control mechanism if the application or the network infrastructure cannot keep up with the packets coming from the device.

  • Page 195: Gevscpsdonotfragment

    Baumer GenICam Camera Features 11.17.2.34 GevSCPSDoNotFragment The state of this feature is copied into the "do not fragment" bit of IP header of each stream packet. It can be used by the application to prevent IP fragmentation of packets on the stream channel.

  • Page 196: Gevscsp

    GenICam Camera Features Baumer 11.17.2.37 GevSCSP Indicates the source port of the stream channel. Name GevSCSP Category TansportLayerControl → GigEVision Interface IInteger Access Read / Write Unit Values ≥ 0 (Increment: 1) 11.17.2.38 GevSecondURL Indicates the second URL to the GenICam XML device description file. This URL is an alterna- tive if the application was unsuccessful to retrieve the device description file using the first URL.

  • Page 197: Gevsupportedoptionselector

    Baumer GenICam Camera Features 11.17.2.41 GevSupportedOptionSelector Selects the GEV option to interrogate for existing support. Name GevSupportedOptionSelector Category TansportLayerControl → GigEVision Interface IEnumeration Access Read / Write Unit Values camera dependent values 11.17.2.42 InterfaceSpeedMode Show the interface speed mode as string.

  • Page 198: Category: Transportlayercontrol → Usb3Vision

    GenICam Camera Features Baumer 11.17.4 Category: TransportLayerControl → USB3Vision Category that contains the features pertaining to the USB3 Vision transport layer of the device. 11.17.4.1 InterfaceSpeedMode Show the interface speed mode as string. Name InterfaceSpeedMode Category TansportLayerControl → USB3Vision Interface...

  • Page 199: Sipayloadfinaltransfer2Size

    Baumer GenICam Camera Features 11.17.4.4 SIPayloadFinalTransfer2Size Size of second final Payload Transfer. Name SIPayloadFinalTransfer2Size Category TansportLayerControl → PtpControl Interface IInteger Access Read only Unit Values 0 - 4294967295 (Increment: 1) 11.17.4.5 SIPayloadTransferCount Expected number of Payload Transfers. Name SIPayloadTransferCount Category TansportLayerControl →...

  • Page 200: Category: Usersetcontrol

    GenICam Camera Features Baumer 11.18 Category: UserSetControl Category including features for User Sets control. It allows loading or saving factory or user-de- fined settings. Loading the factory default User Sets guarantees a state enabling continuous acquisition start by the mandatory features only.
  • Page 201 Baumer GenICam Camera Features Values see table(s) below VCXG.2 / VCXG.2.I / VCXG.2.XC. Features AcquisitionFrameCount DeviceLinkThroughputLimit OffsetY AcquisitionFrameRate DeviceTemperatureStatus- PixelFormat Transition AcquisitionFrameRate-Enable EventNotification ReadoutMode AcquisitionMode ExposureAuto ReverseX ActionDeviceKey ExposureAutoMaxValue ReverseY ActionGroupKey ExposureAutoMinValue SensorShutterMode ActionGroupMask ExposureMode SequencerSetNext AutoFeatureHeight ExposureTime SequencerSetStart AutoFeatureOffsetX...

  • Page 202: Usersetload

    GenICam Camera Features Baumer Features AcquisitionFrameRate-Enable EventNotification ReadoutMode AcquisitionMode ExposureAuto ReverseX AutoFeatureHeight ExposureAutoMaxValue ReverseY AutoFeatureOffsetX ExposureAutoMinValue SensorShutterMode AutoFeatureOffsetY ExposureMode SequencerSetNext AutoFeatureWidth ExposureTime SequencerSetStart BinningHorizontal FrameCounter SequencerTrigger-Activation BinningHorizontalMode Gain SequencerTriggerSource BinningVertical GainAuto TestPattern BinningVerticalMode GainAutoMaxValue TimerDelay BlackLevel GainAutoMinValue TimerDuration BrightnessAutoNominalValue Gamma...

  • Page 203: Usersetsave

    Baumer GenICam Camera Features 11.18.5 UserSetSave Save the UserSetSelector specified by User Set to the non-volatile device memory. INFO Default settings are stored in User Set: Default. This is the only User Set that cannot be edited. To save the configuration select at UserSetSelector (UserSet1, UserSet2 or UserSet3).

  • Page 204: Category: Bocalibrationdata

    GenICam Camera Features Baumer 11.19 Category: boCalibrationData Category for functions of calibration data. INFO Calibration setting Calibration is not performed in the camera neither via the Camera Explorer. Enter here the cate- gory parameters to be determined in the application environment by external software (e.g.

  • Page 205: Bocalibrationdataversion

    Baumer GenICam Camera Features 11.19.4 boCalibrationDataVersion Version of the optical controller. Name boCalibrationDataVersion Category boCalibrationData Interface IString Access Read only Unit Values 11.19.5 boCalibrationFocalLength Focal length in millimeters (mm). Name boCalibrationFocalLength Category boCalibrationData Interface IFloat Access Read / Write Unit Values 0.000000 …...

  • Page 206: Bocalibrationmatrixvalueselector

    GenICam Camera Features Baumer 11.19.8 boCalibrationMatrixValueSelector Value selector of the calibration matrix. Name boCalibrationMatrixValueSelector Category boCalibrationData Interface IEnumeration Access Read / Write Unit Values Value 11 Selects the matrix value in row 1 column 1. Value 12 Selects the matrix value in row 1 column 2.

  • Page 207: 11Bocalibrationvectorvalueselector

    Baumer GenICam Camera Features 11.19.11 boCalibrationVectorValueSelector Selects value selector for calibration vector. Name boCalibrationVectorValueSelector Category boCalibrationData Interface IEnumeration Access Read / Write Unit Values Value 1 Selects vector value 1. Value 2 Selects vector value 2. Value 3 Selects vector value 3.

  • Page 208: Usb Interface Functionality

    This device information is part of the camera's USB-Descriptors. Included information: Manufacturer ID (VID) Product ID (PID) General unique identifier (GUID) Name of device manufacturer (Manufacturer) Serial number (iSerialNumber) Baumer USB Vendor ID Baumer USB Product ID Camera type [Hexadecimal] [Hexadecimal] VCXU.2 2825...

  • Page 209: Gige Interface Functionality

    When starting image transfer at a camera, data packets are transferred with maximum transfer speed. In compliance with the network standard, Baumer cameras operate on a 12-byte mini- mum distance between every packet. This gap is referred to as Inter Packet Gap (IPG). Further ®...
  • Page 210 GigE interface functionality Baumer Example 1: Multicamera operation - Minimum IPG A minimum IPG will have images transmitted at maximum speed. This means full network load, even at a frame rate of 1 fps. Such "bursts" may cause overload to individual network compo- nents which results into packet loss.

  • Page 211: Frame Transmission Delay

    Baumer GigE interface functionality 13.3 Frame Transmission Delay Another approach to packet management in multicamera operation is the so-called Frame Transmission Delay. Saving the currently acquired image to the camera and starting transfer at the predefined delay enables transfer of all frames at once to the PC.
  • Page 212 GigE interface functionality Baumer Time savings in multi-camera operation As already mentioned, the Frame Transmission Delay feature is particularly intended for opera- tion of multiple cameras of different models. This would particularly speed up image transmis- sion of individual cameras: In the above example, time savings can amount to 45% (for transmission of all three images) compared to Inter Packet Gap.
  • Page 213 Baumer GigE interface functionality Trigger exposure(Camera 1) Camera 1 readout(Camera 1) transfer(Camera 1)* exposure(Camera 2) Camera 2 readout(Camera 2) transferGigE(Camera 2) exposure(Camera 3) Camera 3 readout(Camera 3) transferGigE(Camera 3) TransmissionDelay Camera 2 TransmissionDelay Camera 3 A Exposure start for all cameras...

  • Page 214: Multicast

    In the below example illustration, multicast is used for separate processing of image and mes- sage data at two individual PCs. INFO For multicasting, Baumer suggests an address range from 232.0.1.0 to 232.255.255.255. Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | Vp1.0...

  • Page 215: Ip-Konfiguration

    Baumer GigE interface functionality 13.5 IP-Konfiguration The device applies IP address according to the priorities shown. This function (GevCurrentIPConfigurationPersistentIP) is deactivated by default. 13.5.1 Persistent IP A persistent IP is permanently assigned. Validity unlimited. This function is disabled by default.

  • Page 216: Force Ip (Static Ip)

    GigE interface functionality Baumer 13.5.4 Force IP (Static IP) Faults in operation can lead to connection errors between PC and camera. In this case,Force IP (Static IP) may present a final solution. The Force IP feature will transmit IP address and subnet mask to the camera's MAC address. These settings are sent without ver- ification and immediately applied by the client.
  • Page 217 Baumer GigE interface functionality In our example, the packets from No. 3 to No. 5 are lost. This error is detected after the prede- fined time has elapsed and the retransmission request (A) is triggered. The camera then sends packets No. 3 to No. 5 (B) again to complete the image transfer.
  • Page 218 Baumer Optronic GmbH Badstrasse 30 DE - 01454 Radeberg www.baumer.com...
