2. MEET THE TORRENT™ KEYFRAME 600

Main Features

• 600W, 6500K white LED light source
• 4 blade framing shutter system with rotation (+/- 45°)
• Rotating gobo wheel with 6 gobos (2 glass & 4 metal) +open
• Fixed gobo wheel with 8 metal gobos +open
• 6 color wheel + white (open)
• CMY + CTO color mixing system
• Variable CRI filter (71 ~ 91)
• P/T ranges: 540°, 360°, 180° pan / 270°, 180°, 90° tilt
• 16-bit smooth dimming + 4 selectable dimming curves
• 7-40° linear motorized zoom
• Frost, iris, and continuous animation effect wheel
• 3-facet circular + 4-facet linear rotating prisms
• 0-25Hz strobe + variable, pulse, and random effects
• Flicker-free + 6 PWM setting options
• 8-16 bit focus (1M to infinite + auto)
• 6-button control panel with touchscreen LCD display
• Protocol: USITT DMX-512, Art-Net, sACN, RDM

DMX Quick Reference (36/52-Channel Modes)

36CH 52CH What It Does
1 1 Pan
2 2 Pan (fine)
3 3 Tilt
4 4 Tilt (fine)
5 5 Pan/Tilt Speed
6 6 Dimmer
-- 7 Dimmer (fine)
7 8 Strobe
8 9 Cyan
9 10 Magenta
10 11 Yellow
11 12 CTO
12 13 Color Wheel
13 14 Gobo Wheel #1
14 15 Gobo Rotation
-- 16 Gobo Rotation (fine)
15 17 Gobo Wheel #2
16 18 Animation Wheel
17 19 Animation Wheel Rotate
18 20 Blade 1, Motor 1
-- 21 Blade 1, Motor 1 (fine)
19 22 Blade 1, Motor 2
-- 23 Blade 1, Motor 2 (fine)
20 24 Blade 2, Motor 1
-- 25 Blade 2, Motor 1 (fine)
21 26 Blade 2, Motor 2
Torrent™ Keyframe 600 - Rev. A
36CH 52CH What It Does
-- 27
22 28
-- 29
23 30
-- 31
24 32
-- 33
25 34
-- 35
26 36
-- 37
27 38
-- 39
-- 40
28 41
-- 42
29 43
30 44
31 45
32 46
33 47
34 48
35 49
-- 50
-- 51
36 52
Page 5
Blade 2, Motor 2 (fine)
Blade 3, Motor 1
Blade 3, Motor 1 (fine)
Blade 3, Motor 2
Blade 3, Motor 2 (fine)
Blade 4, Motor 1
Blade 4, Motor 1 (fine)
Blade 4, Motor 2
Blade 4, Motor 2 (fine)
Frame Rotation
Frame Rotation (fine)
Focus
Focus (fine)
Auto Focus
Zoom
Zoom (fine)
Prism 1
Prism 1 Rotation
Prism 2
Prism 2 Rotation
Iris
Frost Filter
CRI Filter
CMY Macros
CMY Macro Speed
Control Functions
