DMX Values In-Depth (36/52-Channel Modes)

36CH 52CH
1 1
2 2
3 3
4 4
5 5
6 6
-- 7
7 8
8 9
9 10
10 11
11 12
12 13
13 14
14 15
-- 16
Torrent™ Keyframe 600 - Rev. A
Value What It Does
000 <-> 255 Pan
000 <-> 255 Fine Pan (16-bit)
000 <-> 255 Tilt
000 <-> 255 Fine Tilt (16-bit)
000 <-> 255 Pan/Tilt Speed (fast <-> slow)
000 <-> 255 Dimmer
000 <-> 255 Fine Dimmer (16-bit)
Strobe
000 <-> 003 Closed
004 <-> 007 Open
008 <-> 076 Strobe
077 <-> 145 Pulse (slow <-> fast)
146 <-> 215 Random (slow <-> fast)
216 <-> 255 Open
000 <-> 255 Cyan (0% <--> 100%)
000 <-> 255 Magenta (0% <--> 100%)
000 <-> 255 Yellow (0% <--> 100%)
000 <-> 255 CTO (0% <--> 100%)
Color Wheel
000 <-> 007 Open
008 <-> 015 Red
016 <-> 023 Green
024 <-> 031 Blue
032 <-> 039 Yellow
040 <-> 047 Orange
048 <-> 059 Magenta
060 <-> 187 Index Rotation (0-360º)
188 <-> 219 Forward Scroll (fast <-> slow)
220 <-> 223 Stop
224 <-> 255 Backwards Scroll (slow <-> fast)
Gobo Wheel #1 (Rotating)
000 <-> 008 Open
009 <-> 017 Gobo 1 - Red Gatling Gun
018 <-> 026 Gobo 2 - Blue Sun
027 <-> 035 Gobo 3 - Quarter Circle
036 <-> 044 Gobo 4 - Waves
045 <-> 053 Gobo 5 - Vortex
054 <-> 063 Gobo 6 - Dotted Bar
064 <-> 073 Gobo 6 Shake - Dotted Bar
074 <-> 082 Gobo 5 Shake - Vortex
083 <-> 091 Gobo 4 Shake - Waves
092 <-> 100 Gobo 3 Shake - Quarter Circle
101 <-> 109 Gobo 2 Shake - Blue Sun
110 <-> 118 Gobo 1 Shake - Red Gatling Gun
119 <-> 127 Open
128 <-> 191 Counterclockwise Scroll (slow <-> fast)
192 <-> 255 Clockwise Scroll (slow <-> fast)
Gobo Rotation
000 <-> 063 Gobo Index
064 <-> 145 Counterclockwise Rotation (fast <-> slow)
146 <-> 149 Stop
150 <-> 231 Clockwise Rotation (fast <-> slow)
232 <-> 255 Gobo Rotation (bi-directional rainbow effect)
000 <-> 255 Fine Gobo Rotation (16-bit)
